INSTRUCTION
MANUAL
Model GCE 5005DVD
In Car DVD/CD Player with
Monitor
023286
Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCE 5005DVD and is the answer not in the manual?

Questions and answers

Related Manuals for Goodmans GCE 5005DVD

Summary of Contents for Goodmans GCE 5005DVD

  • Page 1 INSTRUCTION MANUAL Model GCE 5005DVD In Car DVD/CD Player with Monitor 023286 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 2: Important Safeguards

    FAILED OR DEFEATED. AVOID DIRECT EXPOSURE TO THE LASER This unit employs a laser. Only a qualified service person should remove the cover or attempt to service. CAUTION No user serviceable parts inside. Refer servicing to qualified service personnel. Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 3: Important Notes

    Pneumatic drill, chain saw, garbage truck, discotheque night- club 120dB Rock band concert, thunderclap fast train passing by. PERMANENT LOSS OF HEARING 140dB THRESHOLD OF PAIN Gunshot 2 feet away, jetplane taking off. Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 4: Use This Product Safely

    Service Center list included with this product for service assistance. Installation The unit should be installed in a horizontal position with the front end up at a convenient angle, but not more than 30˚. P. 4 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 5: Table Of Contents

    Disc (DVD/CD/MP3) Operation..............28 Setup ......................32 Initial Setup ....................32 General Setup ....................32 Speaker Setup ....................34 Audio Setup ....................34 Preferences Setup ..................35 Defaults Table ....................37 Trouble Shooting..................38 Specifications....................39 TFT Monitor ....................41 P. 5 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 6: Safety Information

    Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. P. 6 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 7: Disc Notes

    Note: A disc may become scratched (although Rough spots not enough to make it unusable) on inside edge P. 7 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 8: Installation

    “Front” (conventional DIN Front- mount) or “Rear” (DIN Rear-mount installation, utilizing threaded screw holes at the sides of the unit chassis). For details, refer to the following illustrated installation methods. P. 8 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 9 Note to install the short threading terminal of the mounting bolt to the back of the unit and the other long threading terminal to the dashboard. P. 9 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 10 (5x5mm) on each side. Note: the outer trim ring, sleeve and the metal strap are not used for method B installation. P. 10 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 11: Using The Detachable Front Panel

    To install the front panel, insert the panel into the housing and make sure the panel is properly installed. Otherwise, abnormality may occur on the display and some keys may not function properly. P. 11 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 12: Wiring Connection

    Try the unit again it should power up and can be used normally. Note this phenomenon is most frequent in Volkswagen/Audi vehicles. P. 12 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 13: The Player

    20. 1~6 preset buttons 21. SHF 10. MANU/SKIP 22. MOD (SW) 11. AF/REG 23. MANU/SKIP 12. PTY ( When the front panel is removed: 24. LED 25. RESET button P. 13 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 14: Location And Function Of Keys

    CHOKE BLACK GROUND (B-) (8) BLACK DC OUT (BLACK) GREY WHITE FRONT Rch FRONT Lch SPEAKER SPEAKER GREY/BLACK WHITE/BLACK BROWN YELLOW REAR Lch REAR Rch SPEAKER SPEAKER BROWN/BLACK YELLOW/BLACK P. 14 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 15: Remote Control

    LOCATION AND FUNCTION OF KEYS REMOTE CONTROL P. 15 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 16 19. SEL Press to select the desired adjustment mode (Bass, treble, balance, fader, volume). Then use VOL+/-to change settings. 20. VOL- Press VOL- button to decrease the volume level. P. 16 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 17: Remote Control

    (2). 4. The player starts playback automatically. Ejecting a Disc Press button (3) on the front panel or (EJECT) button on the remote control to eject the disc. P. 17 Goodmans Product Information Helpline (0870) 873 0080...

  • Page 18: Operation

    P. 18 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 19: Radio Operation

    ) (10) or MANU/SKIP DOWN ( ) (23) until “MANUAL” is shown on the display. Repeatedly press MANU/SKIP UP ) (10) or MANU/SKIP DOWN ( ) (23) to tune to the required station. P. 19 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 20 The station has now been entered/memorised into the selected preset position. To Hear a Preset Station Select desired band and press the appropriate preset button (20) 1-6 into which the station has previously been stored. P. 20 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 21: Overview Of The Rds Function

    When using this function, the unit automatically monitors the station and changes its mode to the station that is broadcasting the traffic information even whilst listening to CD playback. P. 21 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 22 MONO reception. The station will then only be heard in mono but the reception will normally improve. To return to STEREO reception, press the ST/TITL button again. P. 22 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 23 After 5 seconds the display will revert to station name display. Note: Some stations do not transmit a PTY or CT information and therefore the clock or programme type display may not be available. P. 23 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 24: Traffic Information Reception

    TA button, until EON TA LO shows in the display for local + long distance press and hold until EON TA DX shows in the display. P. 24 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 25 “TA” appears on the display window, while playback continues. When a traffic information broadcast starts. “TA” starts blinking. The CD playback stops and the traffic information will be heard. P. 25 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 26 RELIGION PHONE IN TRAVEL LEISURE DOCUMENT Figure 4 PTY code is always enabled. The radio will always respond to a PTY message even when the PTY is not selected. P. 26 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 27 3. CD Repeat (repeat 1 track) Press the RPT button (19) to repeat one track continuously, RPT will show in display. Press RPT button again to return the player to normal operation. P. 27 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 28: Disc (Dvd/Cd/Mp3) Operation

    DVD): seconds of each tack on the current disc. Normal Playback SF2X SF4X SF8X Press again to stop SCAN and listen to SR8X SR4X SR2X the track. P. 28 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 29 The on screen display will be cleared. shown: CHAPTER REMAIN 00:01:39 (5) Press DISP for the fifth time: The on screen display will be cleared. P. 29 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 30 (FOR DVD ONLY) If the DVD has multiple titles recorded on the disc; they will be displayed in the title menu. 1. Press ST/TITL button on the front panel P. 30 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 31 (Stop) button pressed. control to select the item or folder (such as CD01, CD02...), and press button on unit or ENTER button the remote control to confirm, then select P. 31 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 32: Setup

    Wide (For 16:9 TV) d/.PREFERENCES SETUP Select when a wide-screen TV set is This setup menu includes all the connected. configuration of support feature. Please refer to PREFERENCES SETUP MENU. P. 32 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 33 OFF and the angles are available; if is set to OFF, the captions will not appear. mark will not appear. P. 33 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 34: Speaker Setup

    Select the preferred SPEAKER It is recommended to select LINE OUT connection by using the cursor buttons. mode. - Select the LT/RT to activate the Dolby surround compatible output. P. 34 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 35: Preferences Setup

    Select the default AUDIO language by The higher the sampling frequency is, the using the cursor buttons. better the output audio quality is. Therefore, it is recommended to select LPCM 96K. P. 35 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 36 Type the old password (The initial factory code is 3308) and then enter a new 4 character password and enter it once again to confirm the new password. P. 36 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 37: Defaults Table

    If NO MENU mode is selected, when Password 3308 playing an MP3 disc, no menu will be shown and playback will start Smart NAV With Menu automatically. Logo ORIG Logo P. 37 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 38: Trouble Shooting

    TV-set used (PAL/NTSC). DISC DOES NOT PLAY • Ensure the disc label is upwards. • Clean the disc. • Check if the disc is defective by trying another disc. P. 38 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 39: Specifications

    : 530 to 1620 KHz : 450 KHz Sensitivity (S/N = 20 dB) : 36 dBu Frequency Coverage : 144 to 288KHz : 450 KHz Sensitivity (S/N = 20 dB) : 38 dBu P. 39 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 40 Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. P. 40 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 41: Tft Monitor

    TFT MONITOR 022929 P. 41 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...

  • Page 42: Electrical Connection

    CHOKE BLACK GROUND (B-) (8) BLACK DC OUT (BLACK) GREY WHITE FRONT Lch FRONT Rch SPEAKER SPEAKER GREY/BLACK WHITE/BLACK BROWN YELLOW REAR Lch REAR Rch SPEAKER SPEAKER BROWN/BLACK YELLOW/BLACK P. 42 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 43 10. VOLUME CONTROL KNOB Rotate the knob (10) to change the volume. 11. SOCKET FOR EARPHONE Insert earphones to the earphone socket, the sound to the speakers will be cut. P. 43 Goodmans Product Information Helpline: (0870) 873 0080 website: www.goodmans.co.uk...
  • Page 44 TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, call the Goodmans product information helpline Tel: 0870 873 0080 Website: www.goodmans.co.uk NO POWER • Check if the power of the monitor is turned on.
