How to Use your New
Noise Cancelling Headphones
C
D
B
Headset Operation:
1. Open battery door (A) and insert 2 "AAA" Batteries as indicated and replace battery door.
2. Insert one of the two 3.5mm male ends of the cable in to the audio jack (B). Insert the other end in to the
audio output jack of the audio device. For compatible devices use the Dual Mono Adapter (E).
3. Turn the power switch to the ON position (C).
4. Adjust the volume using the volume knob (D).
Specifications:
NOISE CANCELING HEADPHONES
• Frequency Response: 20~20K Hz
• Sensitivity: 105dB ± 2dB/mW
• THD: less than 1%
• Cable Length: 1.2m
• Power Source: 2 x AAA batteries
A
H E A D S E T
• Impedance: 32 Ohms
• Speaker Size: 40mm
• Noise Rejection: 15 dB
• Plug: 3.5mm stereo + dual mono adapter
• Foldable design
E
D U A L M O N O A D A P T O R
C A B L E
