Page 1: Operation Manual
RF-525 LCD PROFESSIONAL 2-WAY LCD 6 CHANNEL SECURITY SYSTEM With Two-way Serial Port Data Link Compatible Please see page 19 of this manual for more details OPERATION MANUAL Please register your product at: www.autopageusa.com THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY... -
Page 2: Table Of Contents
Trunk Release Output Channel 3 Auxiliary Co ntrol Channel 4 Auxiliary Control Channel 5 Auxiliary Control Channel 6 Auxiliary Control Second Vehicle Operation LCD Remote Control LCD Battery Replaceme LCD Icons Programmi ng LCD Transmitter Timer Setting Autopage Warr anty... - Page 3 Congratulations on your purchase of the RF-525LCD vehicle security system. We sincerely hope the purchase of the RF-525 security system gives you peace of mind. The RF-525 LCD is a state-of-the-art two-way communication system. Please take the time to read over this manual to thoroughly familiarize your self with the many features and options of the RF-525.
-
Page 4: Remote Transmitter Operation
OPERATION: REMOTE TRANSMITTER OPERATION: Transmitter System Function Remark Button Lock Doors & Arm System Panic function Press and Hold for 3 seconds. Car Locator Under armed mode Arm and Delete The 2 Stage Shock Press twice within 3 seconds Sensor. Silent Arming / Disarming Ignition in "off"... -
Page 5: Led Display
This is useful if you want to disable the transmission function of the LCD remote control to temporarily prevent from any inadvertent pressing of buttons by others. The 2-way remote control transmitter: Press the button first, within 3 seconds press and hold the ( ) button for 2 seconds to activate or cancel the button lock function. -
Page 6: Ajar Warning
Press button on the transmitter. The siren will chirp once and parking light will flash once indicating that the system is now armed. The vehicle door will lock upon arming when interfaced with the security system. System Arm Door Ajar Trunk / Hood Ajar Clear The Flashing Icon: Pressing the... -
Page 7: Passive Arming B Y-Pass
The vehicle doors will automatically lock after passive arming cycle has been completed. PASSIVE ARMING BY-PASS: While the system disarmed, Press the button twice, the security will respond with [1] chirp and LED will turn “ON”. The security system will remain in this temporally state for as long as you wish. To exit passive by-pass, press the transmitter button and the system will return to normal status. -
Page 8: Valet
The alarm will stop sounding and enter the disarm mode, release the valet switch. You can now start and operate the vehicle normally. VALET MODE: (System in Disarm or Valet mode) The valet switch allows you to temporarily bypass all alarm function, eliminating the need to hand your transmitter to parking attendants or garage mechanics. - Page 9 The starter disable relay (if installed) prevents the vehicle’s starter from cranking. The siren, horn, parking lights, and dome light will turn on to alerting of an intrusion for 30 seconds. Then it will stop and automatic reset and re-arm. If the one of sensors or detectors still active, the alarm system will sound a maximum of 3 times of 30 second cycles.
-
Page 10: System Status Check
SYSTEM’S STATUS CHECK (For two-way transceiver operation only) When you want to check the system’s present status through the LCD screen, Press the transceiver button twice, within 3 seconds press (C) button. It responds with one melody sound, the LCD screen should be illuminated. Note: If it has no responds then you are out of range. -
Page 11: Channel 6 Auxiliary Control
Press the transmitter button to active Channel 5 function. Channel 5 is a programmable output. This feature, when installed with optional accessories, may be used to operate power windows, sunroofs, etc. from your remote transmitter. CHANNEL 6 AUXILIARY CONTROL OUTPUT (Available Option) Press the transmitter button to active Channel 6 function. -
Page 12: Lcd Icons
Note: If the system is interfered by stronger radio frequency around, sources of high voltage electric power or such Obstacles like tall buildings and so on, the transmission range may get shorter as the system uses low out put powered frequency. BATTERY REPLACEMENT: A 1.5V type AAA Alkaline battery powers the Remote Transmitter. - Page 13 Door Open Warning Trunk/Hood Trigger Doors are illegally opened Trunk or Hood is illegally (Zone 3) opened (Zone 2) Shock Sensor Trigger Warn Away trigger Trigger on Shock Sensor Trigger on Shock Sensor (Zone 4) (Zone 1) Time Monitor Alert Alarm You have set morning call alarm Count Down Timer...
- Page 14 Screen Lamp ON: Press and hold the button one second, with one melody sound and the LCD screen lamp will turns on for 5 sec. Power Save Mode: While the power save mode, the LCD remote transceiver uses “0” current to save the battery power. Entry: Press &...
-
Page 15: Timer Setting
Set Up Fixed Count Down Timer: 1. Press the button first, within 3 seconds press and hold the ) button for two seconds, the LCD screen will shows icon and timer (ie. 0:10), 2. Press the ) button again showing next order time on the screen ( ie.0:20), press them again (ie.0:30)…..and so on. - Page 16 Timer Setting: Example to AM10:30 Press & hold the button for 3 seconds, with two-melody sound and the “Hours” digit flashes for adjusting. Press the button to decrease or increase the “Hour” digit until AM10: xx Press the button once again then the “Minute” digit flashes for adjusting. Press the button to decrease or increase the “Minutes”...
- Page 17 LIMITED LIFETIME WARRANTY PROVISIONS ( U.S. ,Continental U.S. and Canada Only) Auto Page, Inc. WARRANTS that this new unit has been thoroughly inspected and tested at the factory prior to delivery. Your Auto Page equipment is guaranteed for “life” to the original purchaser/user of the equipment and the original vehicle in which it was installed by an authorized installer under the following conditions: If the product proves defective (according to Auto Page's testing) within the first year, the defective unit may be exchanged or repaired free of charge.
- Page 18 Auto Page Warranty: You must register your product online at http://www.autopageusa.com to receive any warranty service. Please go to the customer service tab and select product registration. It is the purchaser’s responsibility to register this product for any future warranty service. Warning: Some batteries may contain Perchlorate What is Perchlorate? Perchlorate is both a naturally occurring and manmade contaminant increasingly found in groundwater, surface water and soil.
- Page 19 Your RS-525 is CI3 compatible and will open your world to the true power of two way communication. Complete tracking and full cell phone functionality can be added to your system. For more information please visit your local authorized Autopage dealer or go to www.autopageusa.com...
- Page 20 Compatible 2-Way Communication to the Power of 3 960 Knox Street Unit B, Torrance, CA 90502 Tel: (310) 323-1800 or (800) 262-2527 www.autopageusa.com...
