Weslo Cadence E-20 Treadmill User Manual

English manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Model No. WATL27105.1

Serial No.

Write the serial number in the

space above for future reference.

QUESTIONS?

If you have questions, or if there

are missing or damaged parts,

we will guarantee complete sat-

isfaction through direct assis-

tance from our factory.

TO AVOID DELAYS, PLEASE

CALL DIRECT TO OUR TOLL-

FREE CUSTOMER HOT LINE.

The trained technicians on our

Customer Hot Line will provide

immediate assistance, free of

charge to you.

CUSTOMER HOT LINE:

800-820-0915

E-mail:

newlife@vip.163.com

ICON's Web site:

www.iconfitness.com

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

Serial

Number

Decal

Newlife is an authorized dealer of this treadmill in the territory

of mainland China. This treadmill is designed and manufac-

tured by ICON Health & Fitness, Inc.

USER'S MANUAL

Table of Contents

Need help?

Do you have a question about the Cadence E-20 Treadmill and is the answer not in the manual?

Questions and answers

Summary of Contents for Weslo Cadence E-20 Treadmill

Page 1 Model No. WATL27105.1 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing or damaged parts, we will guarantee complete sat- isfaction through direct assis- tance from our factory.
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover Note: A PART IDENTIFICATION CHART, an EXPLODED DRAWING, and a PART LIST are attached in the center of this manual. WESLO is a registered trademark of ICON IP, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Keep the power cord away from heated sur- that all users of this treadmill are adequately faces.
Page 4 DANGER: other than the procedures in this manual Always unplug the power should be performed by an authorized ser- cord immediately after use, before cleaning vice representative only. the treadmill, and before performing the maintenance and adjustment procedures 24. This treadmill is intended for in-home use described in this manual.
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new WESLO ® E-20 tread- ing this manual, see the front cover of this manual. To mill. The E-20 treadmill offers an impressive array of help us assist you, please note the product model features designed to help you achieve your fitness number and serial number before calling.
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
Page 7 3. Hold a Frame Spacer (27) against the right side of the Frame (79) as shown. Insert a 4” Bolt (70) into the indi- cated hole in the Frame Spacer and the Frame. Next, tighten a 3/4” Tek Screw (3) into the Frame Spacer and the Frame.
Page 8 6. Carefully pull the opposite end of the tape to pull the Wire Harness (60) up through the Right Handrail (59) and out of the hole in the side of the Right Handrail. Remove the tape from the Wire Harness (60). Tape 7.
Page 9 9. Insert the excess Wire Harness (60) into the large hole in the side of the Right Handrail (59). Securely tighten Opening Ties the plastic ties on the bottom of the Console Base (52) to prevent the Wire Harness from slipping. Then, cut off the ends of the plastic ties.
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or other substances to the walking belt or the walking platform. Such substances will deteri- orate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD This product must be earthed.
Page 11 CONSOLE DIAGRAM Clip FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER The treadmill console offers a selection of features Plug in the power cord (see page 10). designed to make your workouts more effective. When the manual mode of the console is selected, the Locate the on/off switch on speed and incline of the treadmill can be changed with the treadmill frame near the...
Page 12 The Speed zone of the Insert the key into the console. display will show the speed of the walking See HOW TO TURN ON THE POWER on page belt. Select the manual mode. The Distance zone of the display will show the When the key is insert- distance you have ed, the manual mode...
Page 13 The Time/Pace zone of appear, and then your heart rate will be shown. the display will show For the most accurate heart rate reading, continue the total number of to hold the contacts for about 15 seconds. hours that the treadmill has been used.
Page 14 Press the Start button or the Speed increase When the program ends, remove the key from button to start the program. the console. A moment after the button is pressed, the tread- When the program ends, see step 7 on page 13. mill will automatically adjust to the first speed set- ting for the program.
Page 15: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower or move the treadmill. 1.
Page 16 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the lock knob to the left and hold it. Pivot the frame down until it is past the lock pin.
Page 17: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
Page 18 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- 2”–3”...
Page 19: Conditioning Guidelines
CONDITIONING GUIDELINES begin to use stored fat calories for energy. If your goal WARNING: is to burn fat, adjust the speed and incline of the Before beginning treadmill until your heart rate is near the lowest num- this or any exercise program, consult your ber in your training zone.
Page 20 Handrail Bolt (20)–4 Frame Bolt (32)–2 PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Silver Ground 1/2” Silver Screw 3/4” Screw (2)–8 1”...
Page 21: Ordering Replacement Parts
PART LIST—Model No. WATL27105.1 R1105A Key No. Qty. Description Key No. Qty. Description Motor Hood Console 3/4” Screw Motor Pivot Nut 3/4” Tek Screw Handrail Foam 8” Cable Tie Belly Pan Grommet 1” Tek Screw Right Handrail Warning Decal, Console Wire Harness Cable Tie Clamp 5/16”...
Page 22 EXPLODED DRAWING—Model No. WATL27105.1 R1105A...
Page 23 Before calling, please note the following information: • the MODEL NUMBER of the product (WATL27105.1) • the NAME of the product (WESLO E-20 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the EXPLODED DRAWING and the PART...
