Weslo Cadence 90 Treadmill User Manual

User manual

Hide thumbs Also See for Cadence 90 Treadmill:

Manual (29 pages)

Table Of Contents

Quick Links

Model No. WETL28130

Serial No.

QUESTIONS?

As a manufacturer, we are com-

mitted to providing complete

customer satisfaction. If you

have questions, or if there are

missing or damaged parts,

please call:

08457 089 009

or write:

ICON Health & Fitness, Ltd.

Customer Service Department

Unit 4

Revie Road Industrial Estate

Revie Road

Beeston

Leeds, LS118JG

email: csuk@iconeurope.com

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

Serial

Number

Decal

USER'S MANUAL

Class HC Fitness Product

Table of Contents

Need help?

Do you have a question about the Cadence 90 Treadmill and is the answer not in the manual?

Questions and answers

Summary of Contents for Weslo Cadence 90 Treadmill

Page 1 Model No. WETL28130 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 or write: ICON Health &...
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the centre of this manual. WESLO is a registered trademark of ICON Health & Fitness, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure No other appliance should be on the same cir- that all users of this treadmill are adequately cuit.
Page 4 21. Inspect and properly tighten all parts of the this manual. Never remove the motor hood un- treadmill regularly. less instructed to do so by an authorised ser- vice representative. Servicing other than the 22. Never insert any object into any opening. procedures in this manual should be performed by an authorised service representative only.
Page 5: Before You Begin
And when you’re not exercising, is WETL28130. The serial number can be found on a the CADENCE 90 treadmill can be folded up, requiring decal attached to the treadmill (see the front cover of less than half the floor space of other treadmills.
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
Page 7 3. Open part bag B. Hold an Upright Spacer (59) against one side of the Frame (96) as shown. Insert a 3 1/2” Bolt (54) into the indicated hole in the Upright Spacer and the Frame. Next, tighten a 3/4” Tek Screw (9) into the Upright Spacer and the Frame.
Page 8 6. Attach the end of the ground wire to the small hole in the side of the Right Handrail (41) with a Silver Ground Ground Wire Screw (66). Hole Open part bag C. Attach the Crossbar (39) to the Right Handrail (41) and the Left Handrail (40) with two Crossbar Screws (37).
Page 9: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
Page 10 Clip FEATURES OF THE CONSOLE CAUTION: Before operating the The treadmill console offers a selection of features de- console, read the following precautions. signed to help you get the most from your workouts. • Do not stand on the walking belt when turn- When the manual mode of the console is selected, the ing on the power.
Page 11 HOW TO TURN ON THE POWER Press the Start button or the Speed increase button to start the walking belt. Note: If there is a sheet of clear plastic on the face of the console, remove the plastic. A moment after the but- ton is pressed, the walk- Plug in the power cord (see page 9).
Page 12 Incline display—This burned (see FAT BURNING on page 18). The dis- display shows the incline play will alternate between one number and the level of the treadmill. other every few seconds, as shown by the indica- tors in the display. Heart Rate display—...
Page 13 When the first period of the program ends, a se- HOW TO USE A PRESET PROGRAM ries of tones will sound and all speed settings will move one column to the left. If the speed and/or incline of the treadmill is about to change, the Insert the key into the console.
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill.
Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.
Page 16: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a.
Page 17 Locate the Reed Switch (16) and the Magnet (10) on the left side of the Pulley (101). Turn the Pulley until View the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 3 mm (1/8 in.).
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES begin to use stored fat calories for energy. If your goal WARNING: is to burn fat, adjust the speed and incline of the tread- Before beginning this mill until your heart rate is near the lowest number in or any exercise program, consult your physi- your training zone.
Page 19 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 20: Ordering Replacement Parts
Fax: 0 (444) 113 387 7125 To help us assist you, please be prepared to give the following information: • The MODEL NUMBER of the product (WETL28130) • The NAME of the product (WESLO ® CADENCE 90 treadmill) • The SERIAL NUMBER of the product (see the front cover of this manual) •...
Page 21 PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Crossbar Screw 3/4” Screw (38)–10 3/4” Tek Screw (9)–2 1 1/4” Tek Screw (60)–4 (37)–2 Silver Ground 1/2”...
Page 22 PART LIST—Model No. WETL28130 R0803A No. Qty. Description No. Qty. Description No. Qty. Description Hood Left Upright Right Endcap Hood Screw Latch Knob Roller Adj. Washer Left Foot Rail Latch Pin Collar Roller Adj. Bolt Belt Guide Spring Frame 1/2” Screw Latch Pin Clip Rear Roller Isolator...
Page 23 EXPLODED DRAWING—Model No. WETL28130 R0803A...

This manual is also suitable for:
