- Page 1 £ ¨ V8 Model£ © Tianjin Jinke Electronics Co.,LTD. Address: No.15,Keyandong Road, Nankai District, Tianjin, PRChina Postal Code: 300192 Tel.:86-22-87892853 Fax:86-22-23509146 86-22-87891459 Website:www.jinke.com.cn E-mail:service@jinke.com.cn sales@jinke.com.cn Version: 05/2006 3rd version...
-
Page 2: Safety Notice
Safety Notice Please strictly abide the rules, otherwise the danger will happen. For safely and efficiently use the product, you should read the following information before firstly use the product. Do not put the product under the hot sunshine and use or put it in the extra high and low temperature environment. - Page 3 Do not bend it, carefully protect the metal part of the card. ¡ ù Keep the metal part clean, prevent it from dust or chemical articles. ¡ ù For protecting the metal part, please avoid regularly pulling out the copyright card ¡...
-
Page 4: Components Guide
Components Guide Stylus Slot Indicator Reset Display Copyright Card Battery Bookshelf Page turning knob Touch panel Stylus Port Earphone jack SD card slot Buttons: Number Key 0~9: you can input number under the select page performance; under the bookshelf interface, press number 0 can enter into online help (The "DIC" folder of SD card should contain help.wol file.) Under bookshelf and catalog interfaces, press the number key (1~8) can select the corresponding item;... -
Page 5: Installing The Battery
Select Page: Choose the page you want to read under the text and bookshelf interface. Shift: Reading/Writing mode Instructions Installing the Copyright Card Installing the Battery Insert the copyright card with the Insert the battery correctly as label facing up and arrow pointing in. shown. -
Page 6: Installing A Sd Card
After insert SD card, bookshelf Installing a SD Card interface will be automatically displayed. To remove the SD card, Insert the SD card with push in the SD card until you hear the label facing up and it click, then release it. arrow pointing in. - Page 7 Online help Bookshelf Bookshelf bookshelf Sub bookshelf Third bookshelf Under any interface of Under any interface of bookshelf, turn bookshelf£ ¬ press selecting page-turning knob to When the main screen page key to start this display previous page and displays the bookshelf function.
- Page 8 HTML files.) etc. For more details, please refer to “reading method”. Press number key 1~8 under the bookshelf Pressing bookshelf button, interface Reading returning to bookshelf interface. Methods Shift return to bookshelf interface functions of the number Catalog keys will be different Press number key 1~8 according...
-
Page 9: Assistant Tools
Support MP3 playing; please put the files in the music folder under the root catalog. During playing, click the corresponding keys, you can do the various performances, including pause, play/stop, volume up/down, adjusting circle mode, play previous/next song etc. The second screen and main screen will display the same interface. -
Page 10: System Setting
System Setting If without any operation within the setting time, it will automatically power off. The system default time is 10 minutes. Click the central part of the icon “ ”for positioning the touch panel. After finish positioning performance, the touch panel can work. Note: Without inserting the SD card, pressing the “Shift”... -
Page 11: Product Specifications
Product Specifications Dimensions: 194mm (L)*133.6mm (W)*13.4mm (H) Weight: About 300g (Including battery) Main Display: ePaper display (E Ink technology); 6 Inches; 800*600 Pixels; 4-level greyscale Slave Display: STN 254*96 Pixels Input: Buttons, Touch Panel (only slave display) Storage: SD/MMC card (expandable to 1GB) Power Supply: Li-ION 3.7V 760mAh Operating Temperature: 0¡... - Page 12 Jinke can check the warranty service card of customer. (Which filled in by customer, and send it to Jinke) If after repair, the products still appear the same fault, which can be exchanged (not including accessories and present). If you have any questions, please contact service department of Jinke.
- Page 13 If the warranty period expires, the expenses of maintenance and service will be ¡ ù charged according to the general service policy of Jinke, and provide a 90 days warranty period after the paid repair. And the product will enjoy the policy of after-sales-service for life.
