ProForm 500 Zlt Cwl Treadmill Manual page 6

M8 Star
1/4" Star M10 Star
3/8" Locknut
Washer (10)–8 Washer (9)–4
Washer (73)–2 Base Foot Spacer
(6)–3
(94)–2
M4 x 13mm M4 x 16mm
M4.2 x 25mm
M5 x 16mm Bolt
Screw (116)–8 Screw (124)–4 Tek Screw (3)–4
(108)–2
M8 x 25mm
5/16" x 5/8"
Bolt Spacer (90)–4
Patch Bolt (113)–4 Patch Bolt (5)–6
3/8" x 2"
M10 x 68mm Patch Bolt (114)–2
Bolt (37)–2
3/8" x 1 3/4"
M10 x 95mm Patch Bolt (8)–2
Patch Bolt (7)–1
