Summary of Contents for Leadtek WinFast TV Pro II
- Page 1 WinFast TV Pro II TV to VGA Converter User’s Manual CODE: LR6019 P/N: W05G0063...
- Page 2 No part of this document may be copied or reproduced in any form or by any means without the prior written consent of Leadtek Research Inc. Leadtek makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability, quality, or fitness for any particular purpose. The information in this document is subject to change without notice.
-
Page 3: Table Of Contents
CONTENTS Chapter 1 Introduction........1 1.1 Features ..................1 1.2 Specification ................2 1.3 System Requirement ..............2 1.4 Package Checklist ..............3 Chapter 2 Hardware Installation ....3 2.1 Front Panel ................. 3 2.2 Back Panel .................4 Chapter 3 Operating Instruction ....5 3.1 Functions of Control Panel............5 3.2 Functions of Remote Control ............6 3.3 How to Operate this Machine............7 Chapter 4 Menu Setting .........9... -
Page 5: Chapter 1 Introduction
Thing’s nicely changed! With the new generation of TV Box, WinFast TV Pro II, you could use your CRT, LCD, plasma or even projection monitor to watch the full-screen TV program, up to a sky-high resolution of 1280*1024 in 24-bit color. -
Page 6: Specification
1.2 Specification TV Input RF Jack VGA Input 9-pin Mini-Din Jack (pass through) Composite Video RCA Jack Video Input S-Video 4-pin Mini-Din Jack Audio (R) RCA Jack Audio Input Audio (L) RCA Jack 3.5 mm Stereo Jack (connected to PC Audio Line Out) Audio Output 3.5 mm Stereo Jack (connected to Speaker) VGA Output... -
Page 7: Package Checklist
1.4 Package Checklist Before operating this machine, please check and identify the supplied items shown below. If finding any shortage or damage, please contact the dealer as soon as possible 1. WinFast TV Pro II Unit 2. Stand 3. IR-Remote Control 4. -
Page 8: Back Panel
2.2 Back Panel Connection Ports (from right to left) Functions TUNER IN Input of Air/Cable TV Signals Video-Out Output of Video Signals Line-In Audio Input connected to PC’s Line-Out Speaker Audio Output connected to Speaker VGA-IN VGA Input connected to PC’s VGA-Out Monitor VGA Output connected to Monitor +5V DC... -
Page 9: Chapter 3 Operating Instruction
Chapter 3 Operating Instruction When the LED light of the TV Box is on, it means that the TV Box is powered up. NOTE: Menu Setting Before Using This Machine Before using this machine, please make sure that you have got into the MENU and completed the following menu settings. -
Page 10: Functions Of Remote Control
3.2 Functions of Remote Control ● Power: Power On/Off Switch ● Resolution: Select the Resolution and the Corresponding Refresh Rate ● Number Keys: Numbers for Channel Selection ● Enter: Confirm the Channel Selection ● CH RTN: Return to Previous Channel ●... -
Page 11: How To Operate This Machine
3.3 How to Operate this Machine 1. Power Switch Press the [POWER] button of the control panel or the remote control to power up the TV Box. 2. Video Source Selection Press the [Video] button of the control panel or the remote control to select the video sources between TV, Composite Video, S-Video and PC. - Page 12 6. Bilingual Sound (Optional Function for the Advanced Version) Press the [Audio] button of the remote control to switch the audio modes. The sequence of the audio mode switch: Mono Stereo Mono SAP may not be offered by every TV program so that you may not be able to watch the bilingual program all the time.
-
Page 13: Chapter 4 Menu Setting
Chapter 4 Menu Setting Press the [MENU] button of the control panel or the remote control to get into the menu in which you can do all the possible settings. Press the [VOL] button of the control panel or the remote control to select the setting item, and press the [ENTER] button of the control panel or the remote control to confirm your selection. -
Page 14: Sleep Setting
4.4 Sleep Setting: Get into the menu and use the [VOL] “Sleep button to select the item of Setting” . Press the [Enter] button to Sleep Setting confirm this selection. Press the [VOL] button to select the sleep time between 10 to 90 minutes. -
Page 15: Channel Edit
4.7 Channel Edit: Get into the “Channel Edit” and use the [Enter] button to make the selection. Then “1. Current CH” will show you the number Channel Edit of channel you’re watching. Use the [CH] Current CH- button to select the“2. Expect CH-” and Expect CH- Switch Key-in the channel number which you... -
Page 16: Screen Position
4.10 Screen position: Use the [CH+] or [CH-] button to select the sub-item such as “H-position” or H-Position “V-position”. Press [Vol+] or [Vol-] to move the OSD. V-Position 4.11 TV Source: Use the [CH+] or [CH-] button to select between air or cable TV source. TV Source Then press [Enter] to confirm your 1. -
Page 17: Favorite Channel
4.13 Favorite Channel: On the channel you’d like to set into your favorite channel list, press the [Menu] button to get into the menu setting. Use the Favorite CH [Vol] button to select the item of “Favorite CH”. Press [Enter] to confirm your 1. -
Page 18: Recycling Information
Such disposal is free-of-charge to you. Together with the management of the local collection site, Leadtek will then take care of the efficient recycling and treatment of the electric and electronic waste.
