SPECIFICATION
807... - 110
110V
807... - 220
220/230V
807... - 230
230V
807... - 240
230V U.K.
A1/223
24V 250W
919... - 110
110V
919... - 220
220/230V
919... - 230
230V
919... - 240
230V U.K.
DISTANCE FROM SCREEN CHART
3.0m
1.5m
FEATURES
J
K
A
Mirror
B
Lamp Removal Cover
C
Head Unit
D
Varifocal Lens
E
Column
3.15A
3
324×416×445mm
5 x 20mm
1.0m
Vari-focal
A
D
F
G
F
On/Off Switch
G
Lamp Change Slider
H
Reflective Fresnel Lens
J
Column Release Catch
K
Euro Plug Socket
REFLECTIVE
REFLECTIVE
OVERHEAD
OVERHEAD
Kg
PROJECTOR
PROJECTOR
4.9Kg
OPERATING INSTRUCTIONS
7.9Kg
Thank you for purchasing our Overhead Projector.
Please read these instructions carefully before use.
Lens
B
C
E
H
Part No.- 21076/1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Acco Europe 21076/1
Summary of Contents for Acco Europe 21076/1
- Page 1 Please read these instructions carefully before use. DISTANCE FROM SCREEN CHART 3.0m 1.5m 1.0m Vari-focal Lens FEATURES Mirror On/Off Switch Lamp Removal Cover Lamp Change Slider Head Unit Reflective Fresnel Lens Varifocal Lens Column Release Catch Column Euro Plug Socket Part No.- 21076/1...
- Page 2 UNPACKING & ASSEMBLY UNPACKING, ASSEMBLY & SET UP Carefully remove OHP from packaging. (Complete and return guarantee card. UK only). Unfold OHP from flat position by lifting and rotating column (E) towards the vertical and rotating head unit (C). (Refer to Diagram 2). Rotate Column (E) until fully vertical ensuring column release catch (J) engages.
