Assembly Instructions
RS 750 / RS 550
Rocket Riser
©™
Tools you will need:
Large Philips Screwdriver
Small Philips Screwdriver
(6) 2" Wood Screws (included)
(6) 1.25" Machine Screws (included)
STEP 1: Remove all packing material from included (4) Riser platforms.
STEP 2: With small Philips head screwdriver, attach the included 2" dowels to
small Riser (top) platforms using (3) 2" wood screws. Angled dowel forms the
front Riser support, straight dowels form rear Riser supports. See Figure 1.1.
NOTE: Angled dowel should "point" forward when right-side up. See Figure
1.2.
Figure 1.1
Page 1
