GE ASQ12DL Dimensions And Installation Information

230/208 volt electronic room air conditioner

Enlarged version

ASQ12DL

230/208 Volt Electronic Room Air Conditioner

Wall Case Dimensions and Installation Information (in inches)

Note: When installing slide-out chassis units in through-the-wall

applications, keep louvers free. Do not restrict air flow areas. Fixed

chassis units are not suitable for through-the-wall applications.

Wall Outlets: All wiring including installation of receptacle must

be made in accordance with local electrical codes and regulations.

Electrical outlet should be in reach of line cord.

Note: Aluminum wiring may pose special problems – consult a

qualified electrician.

For answers to your Monogram,

GE Profile

appliance questions, visit our website at

ge.com or call GE Answer Center

800.626.2000.

™

service,

21-1/2

Specification Created 1/08

14-19/32

Tandem

230V

Total volume and shelf

Listed by

area are calculated by

Underwriters

the Association of Home

Laboratories

Appliance Manufacturers'

standards.

390440
