Iomega Clik! drive 40 Quick Start Manual

Quick Start Guide

Quick Start Guide
Notebook Computer Setup
™ 2. Connect the Clik! PC Card
1. Slide the Clik!
Battery onto Cable into Clik! drive.
the back of
the Clik!
drive.
4. Plug the Clik! Power 5. Slide the Clik! PC Card
Supply into an electrical Adapter into the
outlet. PC card slot on
your notebook
computer.
Desktop PC Computer Setup
1. Slide the Clik! 2. Set the
Battery onto the Clik! drive
back of the into the
Clik! drive. Clik!
Desktop
Dock.
7. If you have a 8. Plug the Clik! Power Supply
printer, connect into the Clik! Parallel Port
the printer cable Interface.
to the Clik!
Parallel Port
Interface.
(See the
User's Manual
for more
instructions.)
Window CE Device Setup
1. Follow 2. Slide the Clik! PC Card Adapter
steps 1-4 into the PC card
as shown slot on your
®
above Windows CE
in the device.
Notebook
Computer
Setup.
Clik! Media Usage
1. Squeeze the top 2. Never manually open
and bottom of the the shutter of the
Clik! disk case Clik! disk.
to open.
3. Plug the Clik!
Power Supply
into the Clik!
PC Card
Cable.
6. Install Clik! Software.
®
(Attach Windows CE
device if necessary).
3. Plug the Clik! Parallel Port Interface
cable into the back of the Clik!
Desktop Dock.
9. Plug the Clik! Power Supply into
an electrical outlet. Plug in the
power to your computer and
turn computer on.
3. Attach your 4. Insert a Clik! disk into the
®
Windows CE Clik! drive (label side
device to your up) until it clicks.
desktop or
notebook
computer,
then install
the Clik!
Software.
3. Open the drive door on 4. To eject the Clik! disk, open
the Clik! drive and gently the drive door and gently
insert the disk (label push in the Clik!
side up) until it disk until
clicks. it clicks.
FOR MOBILE COMPUTERS
7. Insert a Clik! disk into the 8. Verify drive letter assignment.
Clik! drive (label side
up) until it clicks.
4. Disconnect power on your 5. Locate your
computer. computer's
parallel
port and
disconnect
any cable
already
attached.
10. Install Clik! Software. 11. Insert a Clik! disk into the
®
(Attach Windows CE Clik! drive (label side
device if necessary). up) until it clicks.
5. Locate files on the Clik! disk.
5. Always
store and
transport
the Clik!
disk in the
Clik! disk
case.
CLIK! ™ DRIVE
9. If you want to
use the Clik!
Battery, (with-
out the Clik!
Power Supply)
it must be
charged for
2-4 hours
before
initial use.
6. Connect the
Clik! Parallel
Port Interface
cable to your
computer's
parallel port.
12. Verify drive letter.
03466500
