Hotel Fitness Rb9800 Bike Manual

English manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No. HF-RB9800-I.0
USER’'S MANUAL
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, please see
HOW TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
www.HotelFitness.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hotel Fitness Rb9800 Bike and is the answer not in the manual?

Questions and answers

Related Manuals for Hotel Fitness Hotel Fitness Rb9800 Bike

Summary of Contents for Hotel Fitness Hotel Fitness Rb9800 Bike

  • Page 1 Model No. HF-RB9800-I.0 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, please see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. Hotel Fitness and FreeMotion Fitness assume no responsibility for personal injury or property dam- age sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary HOTEL reading this manual, please see the back cover of this FITNESS ® HF-RB9800-I exercise bike. The manual. To help us assist you, note the product model HF-RB9800-I exercise bike provides an impressive number and serial number before contacting us.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY •• Assembly requires two persons. •• In addition to the included tool(s), assembly requires the following tools: •• Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you ...

  • Page 7: From The Left And Right Shields (7, 8). Set The Front Shield Aside

    2. Press the Rail Cap (55) into the end of the Seat Rail (5). Attach the Rail Cap with two 5/16" x 1 1/2" Socket Screws (91). Next, have a second person tip the exercise bike toward one side and hold it. Connect the wire that you inserted in step 1 to the Lower Wire Harness (50).

  • Page 8: Right Shields (7

    4. Remove the four shipping screws from the Upright (3) and discard them. Shipping Screws Have a second person hold the Upright (3) near Wire the Frame (1). Tie the lower end of the wire tie in the Upright (3) to the TV Cable (20), the Main Wire Harness (85), and the Pulse Wire Harness (96).
  • Page 9 6. Press the Front Shield (61) onto the Left and Right Shields (7, 8). 7. Untie and discard the wire tie on the TV Cable (20), the Main Wire Harness (85), and the Pulse Wire Harness (96). While a second person holds the Console (4) near the Upright (3), connect the TV Cable (20), the Main Wire Harness (85), the Pulse Wire Harness (96), and the wires from the...
  • Page 10 8. Tip: Avoid pinching the wires. Attach the Console (4) to the Upright (3) with four #8––32 x 1/2" Screws (43). Avoid pinching the wires 9. Attach the Console Back (12) to the Console (4) with four #8––32 x 3/4" Screws (88).
  • Page 11 10. Plug the Power Cord (31) into the Power Receptacle (21) on the frame of the exercise bike. Note: To plug the Power Cord (31) into an outlet, see HOW TO PLUG IN THE POWER CORD on page 13. 11. Make sure that all parts are properly tightened before you use the exercise bike. After the exercise bike is assembled, inspect it to make sure that it is assembled correctly and that it functions properly.

  • Page 12: How To Upgrade The Console

    HOW TO UPGRADE THE CONSOLE Your console has been preconfigured to operate with a 17" Digital TV (see the drawings below). To learn about the features of the basic console, see page 16. To learn about the features of the 17" Digital TV, see the user’’s manual included with the 17"...

  • Page 13: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should malfunc- be used to tion or break down, grounding provides a path of least connect the Adapter resistance for electric current to reduce the risk of...
  • Page 14 HOW TO MOVE THE EXERCISE BIKE HOW TO LEVEL THE EXERCISE BIKE Due to the size and weight of the exercise bike, If the exercise moving it requires two persons. Remove the rear bike rocks slightly frame cover. Stand in front of the exercise bike, hold on your floor the upright, and place one foot against one of the during use, turn...
  • Page 15 HOW TO CONNECT A CATV CABLE A satellite receiver, VCR, or DVD player can also be connected to the exercise bike. Connect a CATV cable If your exercise bike has the 17" Digital TV, a CATV from the coaxial output on your equipment (usually cable must be connected to the exercise bike for cable labeled TV OUT or RF OUT) to the cable jack on the TV stations to be viewed.
  • Page 16 CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode, you can change the resistance of the pedals with the touch of a button. The console offers an impressive array of features designed to make your workouts more effective and As you exercise, the console will display instant exer- enjoyable.
  • Page 17 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the exercise bike has been exposed The console features a tablet with a full-color touch to cold temperatures, allow it to warm to room screen. The following information will help you become temperature before turning on the power.
  • Page 18 HOW TO SET UP THE CONSOLE The Internet browser will open to the iFit.com regis- tration page. Select either the basic or the limitless Before using the exercise bike for the first time, set up plan. Note: For more information, read the details the console.
  • Page 19 HOW TO USE THE MANUAL MODE To select the desired display mode, simply flick or slide the screen. You can also view additional work- 1. Begin pedaling or press any button on the out information by touching the red boxes on the console to turn on the console.
  • Page 20 When your pulse is detected, your heart rate will be 7. When you are finished exercising, unplug the shown. For the most accurate heart rate read- power cord. ing, hold the contacts for at least 15 seconds. When you are finished exercising, touch the home If the display does not show your heart rate, make button or the back button.
  • Page 21 HOW TO USE AN ONBOARD WORKOUT If the resistance level for the current segment is too high or too low, you can manually override the 1. Begin pedaling or press any button on the setting by pressing the Resistance buttons. If you console to turn on the console.
  • Page 22 HOW TO USE A SET-A-GOAL WORKOUT IMPORTANT: The target rpm is intended only to provide motivation. Your actual pedaling speed 1. Begin pedaling or press any button on the may be slower than the target rpm. Make sure console to turn on the console. to pedal at a speed that is comfortable for you.
  • Page 23 HOW TO USE AN IFIT WORKOUT For more information about the iFit workouts, please see www.iFit.com. Note: To use an iFit workout, you must have access to a wireless network (see HOW TO USE THE When you select an iFit workout, the screen will WIRELESS NETWORK MODE on page 28.
  • Page 24 HOW TO USE THE EQUIPMENT SETTINGS MODE 6. Enable or disable the Internet browser. The console features an equipment settings mode that You can disable the Internet browser, which will allows you to change various settings for the exercise help to restrict the bandwidth used on your wireless bike.
  • Page 25 10. Enable or disable street view. To set a workout time limit, touch the Workout Time Limit button. To enable the workout time limit, touch You can disable the street view for maps workouts, the Enable checkbox. Then, touch the increase which will help to restrict the bandwidth used on and decrease buttons to select the amount of time your wireless network.
  • Page 26 HOW TO USE THE ENTERTAINMENT MODE Touch the Default Settings button and then select a default channel and a default volume if desired. The console features an entertainment mode that allows you to connect the console to a remote TV. Touch the Custom Settings button and then select your TV type from the drop-down list if necessary.
  • Page 27 HOW TO USE THE MAINTENANCE MODE The screen will show the progress of the update. When the update is complete, the exercise bike will The console features a maintenance mode that allows turn off and then turn back on. If it does not, press you to update the console firmware, view machine the power switch into the off position.
  • Page 28 HOW TO USE THE WIRELESS NETWORK MODE An information box will ask if you want to connect to the wireless network. Touch the Connect button The console features a wireless network mode that to connect to the network or touch the Cancel but- allows you to set up a wireless network connection.
  • Page 29 HOW TO USE THE SOUND SYSTEM HOW TO CHARGE A DEVICE To listen to the console audio, remote TV audio, or Plug your MP3 player, smartphone, or other USB personal 17" Digital TV audio with your personal head- device into the USB port on the front of the console to phones or ear buds, plug your headphones into the charge the device.
  • Page 30 HOW TO USE THE INTERNET BROWSER To use the keyboard, see HOW TO USE THE TOUCH SCREEN on page 17. Note: To use the browser, you must have access to a wireless network including an 802.11b/g/n router with To enter a different web address in the URL bar, first SSID broadcast enabled (hidden networks are not slide your finger down the screen to view the URL bar, supported).

  • Page 31: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise bike regu- CONSOLE TROUBLESHOOTING larly. Replace any worn parts immediately. If the console does not display your heart rate when To clean the exercise bike, use a damp cloth and a you hold the handgrip heart rate monitor, or if the dis- small amount of mild soap.

  • Page 32: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 33: Part List

    PART LIST Model No. HF-RB9800-I.0 R1112A Key No. Qty. Description Key No. Qty. Description Frame Lower Wire Harness Front Frame Cover Standoff Upright Carriage Cover Console Backrest Cover Seat Rail Handgrip Cap Front Accessory Tray Rail Cap Left Shield 1/4" x 2 1/4" Screw Right Shield Button Pad Seat...

  • Page 34: Exploded Drawing

    EXPLODED DRAWING A Model No. HF-RB9800-I.0 R1112A...
  • Page 35 EXPLODED DRAWING B Model No. HF-RB9800-I.0 R1112A 43 87...

  • Page 36: How To Contact Customer Care

    HOW TO CONTACT CUSTOMER CARE If you have questions after reading this manual, or if parts are damaged or missing, please contact the store where you purchased this product. If you are unable to contact the store, contact Customer Care at the phone number, email address, or postal address listed below.
