Model No. EPTL89011.0
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-866-997-6999
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.iconservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for Epic Fitness Tl 2015 Treadmill
Summary of Contents for Epic Fitness Tl 2015 Treadmill
- Page 1 Model No. EPTL89011.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care. IMPORTANT: Please register this product (see the limited warranty on the back cover of this manual)
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . 2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precations and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 20. Never leave the treadmill unattended while 24. Inspect and properly tighten all parts of the it is running. Always remove the key, unplug treadmill regularly. the power cord, and press the power switch DANGER: Always unplug the power into the off position when the treadmill is not cord immediately after use, before clean- in use.
-
Page 5: Before You Begin
Thank you for selecting the revolutionary EPIC reading this manual, please see the front cover of this ® 2015 treadmill. The TL 2015 treadmill offers an im- manual. To help us assist you, please note the product pressive selection of features designed to make your model number and serial number before contacting us. -
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 7: Assembly
ASSEMBLY • To hire a service technician to assemble this • To identify small parts, see page 6. product in your home, call 1-800-445-2480. • Assembly requires the following tools: • Assembly requires two persons. the included hex keys • Place all parts in a cleared area and remove the packing materials. - Page 8 3. Identify the Left Upright (89), which is marked with a “Left” sticker or an “L” sticker. Have a sec- ond person hold the Left Upright near the Base (94). See the inset drawing. Tie the wire tie in the Wire Left Upright (89) securely around the end of the Upright Wire (81).
- Page 9 5. Identify the Left Base Cover (82) and the Right Base Cover (83). Slide the Left Base Cover onto the Left Upright (89). Slide the Right Base Cover onto the Right Upright (90). Do not press the Base Covers into place yet. Identify the Left Upright Cover (79) and the Right Upright Cover (80).
- Page 10 7. Attach the Left Handrail (88) to the Left Upright (89) with two 5/16" x 1" Screws (5), two 5/16" Star Washers (11), and a 5/16" x 1 1/4" Bolt (4). Do not fully tighten the Screws and Bolt yet. Attach the Right Handrail (87) in the same way.
- Page 11 10. With the help of a second person, hold the con- sole assembly near the Left Handrail (88). Connect the Upright Wire (81) to the console Console wire. See the inset drawing. The connectors Assembly should slide together easily and snap into place.
- Page 12 12. Firmly tighten the four 3/8" x 2 3/4" Screws (7) and the four 3/8" x 1 1/4" Screws (8) (only one side is shown). Press the Left Base Cover (82) and the Right Base Cover (83) onto the Base (94) until they snap into place.
- Page 13 15. Attach the Left and Right Trays (107, 108) to the console assembly with four #8 x 1/2" Screws (1). Console Assembly 16. IMPORTANT: See page 16 and plug in the power cord. Next, see page 18 and turn on IMPORTANT: the power.
- Page 14 17. Raise the Frame (56) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (53) so that the large barrel and the latch knob are oriented as shown. Attach the lower end of the Storage Latch (53) to the Base (94) with a 3/8"...
-
Page 15: The Chest Heart Rate Monitor
THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°... -
Page 16: Operation And Adjustment
OPERATION AND ADJUSTMENT HOW TO PLUG IN THE POWER CORD This product is for use on a nominal 120-volt circuit (see drawing 1). A temporary adapter may be used to connect the surge suppressor to a 2-pole receptacle if DANGER: a properly-grounded outlet is not available (see Improper connec- drawing 2). - Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s stereo sound system The treadmill console offers an impressive array of while you exercise. features designed to make your workouts more effec- To turn on the power, see page 18.
- Page 18 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
- Page 19 4. Change the incline of the treadmill as desired. The Distance dis- play—This display will To change the incline of the treadmill, press the show the distance that Incline increase or decrease button or one of the you have walked or run. numbered Quick Incline buttons.
- Page 20 6. Measure your heart rate if desired. When you are finished using the treadmill, press the power switch into the off position and unplug Note: If you use the handgrip heart rate moni- the power cord. IMPORTANT: If you do not do tor and the chest heart rate monitor at the same this, the treadmill’s electrical components may time, the console will not display your heart...
- Page 21 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
- Page 22 HOW TO USE AN IFIT LIVE WORKOUT www.iFit.com. Note: If there are no workouts of the selected type in your schedule, the next work- Note: To use an iFit Live workout, you must have an out in your schedule will be downloaded. optional iFit Live module.
- Page 23 THE INFORMATION MODE function. If the demo mode is turned on, the word ON will appear in the center display. To turn on or The console features an information mode that keeps turn off the demo mode, press the Enter button or track of treadmill information and allows you to person- the Speed decrease button.
-
Page 24: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left. -
Page 25: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following c. Remove the key from the console, and then the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further as- sistance is needed, see the front cover of this d. - Page 26 Locate the Reed Switch (52) and the Magnet (50) b. If the walking belt is overtightened, treadmill per- on the left side of the Pulley (49). Turn the Pulley formance may decrease and the walking belt may until the Magnet is aligned with the Reed Switch. become damaged.
- Page 27 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first re- when walked on move the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller screws a. If the walking belt is off-center, first remove the clockwise, 1/4 of a turn.
-
Page 28: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. - Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
-
Page 30: Part List
PART LIST Model No. EPTL89011.0 R1011A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Reed Switch Clip #8 x 3/4" Screw Reed Switch 3/8" x 2" Bolt Storage Latch 5/16" x 1 1/4" Bolt Drive Motor 5/16"... - Page 31 Key No. Qty. Description Key No. Qty. Description Module Housing Console Base Console Back Base Ground Wire Console Hood Clip Console Frame #10 x 3/4" Flat Head Screw Ground Wire Chest Strap Console Clamp Chest Sensor Left Tray – User’s Manual Right Tray Note: Specifications are subject to change without notice.
-
Page 32: Exploded Drawing
EXPLODED DRAWING A Model No. EPTL89011.0 R1011A... - Page 33 EXPLODED DRAWING B Model No. EPTL89011.0 R1011A...
- Page 34 EXPLODED DRAWING C Model No. EPTL89011.0 R1011A...
- Page 35 EXPLODED DRAWING D Model No. EPTL89011.0 R1011A...
-
Page 36: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
