ASCOM Pocket Receiver 912T Product Manual

LED Display Function button
IR receiver
The LED indicates:
• When turning on the receiver
• When receiving a paging or an alarm
Pocket receiver 912T
912T is a robust pocket text receiver used in system 900.
The receiver has a two-line display and shows 2 x 12
characters at the same time. It can receive messages of up
to 120 characters in each message. The receiver has a
memory for 10 messages with altogether 480 characters.
Six call numbers can be programmed and five of them can
be enabled/disabled. The pocket receiver is designed for use
in tough environments and where there is a need for long
text presentations.
Table Heading
912T
Characters per message
Messages stored
Characters in memory
Group paging numbers
Absence indication
Time stamp
Time display
Out of range indication
Vibrator option
EX-classification option
Note: Your receiver can have functions other than described
here, depending on the pre-programmed parameters.
Symbols and display texts
Charge or replace the battery
New message (the symbol flashes)
More than one message stored
Message longer than 2 × 12 characters
Audible signal switched off
Out of range/Error indication
Info message
Time stamp (the time when the message was
received)

Basic functions

Turning the receiver ON
One short press on the Function button. The identity is
shown in the display.
Turning the receiver OFF
Two long presses on the Function button.
Scrolling through messages
One short press on the Function button.
Erasing messages
One long press on the Function button until ******** appears.
120
Accepting a message
10
One short press on the Function button,
480
5
Replacing the battery
Yes
1. Turn off the receiver.
Yes
2. Unscrew the screw with a coin and remove the cover.
Yes
3. Replace the battery and close the cover. It will take up
Yes
to 10 seconds before the receiver starts up.
Battery replacement of EX-version is not permitted in
restricted area.
Long messages
The 912T can receive long messages with a maximum of 10
lines. A message with more than two lines is marked with
The message scrolls automatically, but when it stops, it can
be started again by a short press on the Function button.

Function settings

When the identity is shown in the display, one long press on
the Function button will access the function settings. A
short press on the button scrolls between function settings
and a long press confirms the choice.
Main menu
Long press OFF?
Short press TONE?
Short press MENU?
stops flashing.
Short press
One long press confirms the choice.
Sub-menu functions
• Changes the beep signal volume
• Shows the call number
• Enables/disables the 5 extra paging numbers
• Shows time stamp
• Reminder beep for unacknowledged pagings
• Rotates the display 180°
• Programmable via radio
• Exit to identity mode
One long press enables/disables.
Note that your 912T may not have all these functions.
long press Sub-menu
VOL
Call No.
Extra paging Nos
RTC (CLOCK)
REMIND
LCD (DISPLAY)
PROGRAM?
EXIT?
