Introduction
SRGASKET Airflow Optimization Kit Benefits
• Prevents recirculation of warm equipment exhaust inside enclosures
• Closes side gaps and seals front-to-rear airflow pathway
• Also supports equipment that requires side-to-side airflow
• Facilitates hot-aisle / cold-aisle data center configurations
• Fully compatible with 25U, 42U and 48U SmartRack™ enclosures
Important Safety Instructions
SAVE THESE INSTRUCTIONS
This manual contain instructions and warnings that must be followed during the installation and operation of the product described in this manual.
Failure to comply may invalidate the warranty.
• The instructions in this manual are for common rack and rack enclosure types and may not be appropriate for all mounting applications. You must
determine the fitness of hardware and procedures before mounting. If hardware or procedures are not suitable for your application, contact the
manufacturer of your rack or rack enclosure for a solution.
• Rackmount equipment may be extremely heavy—be careful when moving or lifting equipment. Use one or more assistants if necessary.
• Before applying adhesive strips, measure side panels, gaskets and mounting rails carefully to assure proper alignment. Pay particular attention to
accommodating the horizontal struts of each side panel.
• Attach gaskets to mounting rails, not side panels. If gaskets are attached to side panels, they will not be effective when mounting rail depth is adjusted.
• If equipment requires side-to-side airflow, modify installation procedure as specified in Side-to-Side Airflow Installation.
Owner's Manual
SRGASKET
Airflow Optimization Kit
1111 W. 35th Street, Chicago, IL 60609 USA
+1.773.869.1234 • www.tripplite.com
Copyright © 2008 Tripp Lite. All trademarks are the sole property of their respective owners.
