Belkin NETCAM HD Quick Install Manual

Viewing through a browser
From any computer,
1
visit http://www.belkin.com/netcam
2 Enter your user name and password
created during setup.
Welcome to NetCam HD.
Download a complete manual at www.belkin.com
Setup
1 Download Belkin NetCam app on your 2 Plug in NetCam HD.
smartphone or tablet. If you have done so
already and you're adding additional
cameras, begin at step 2.
OR
Please set switch to
Wait a minute for a blinking
Belkin NetCam
amber from .
Wall-Mount
1 Unscrew camera post from the base 2 Attach screws to wall and hang plate
and remove weight. onto screws.
1/8 in or 5.5mm
3 Connect to NetCam HD Wi-Fi signal. 4 Launch NetCam app to complete setup.
.
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY
We, Belkin International, Inc., of 12045 E. Waterfront Drive, Playa Vista, CA 90094, declare under our sole
responsibility that the device, F7D7602 V1, complies with Part 15 of the FCC Rules. Operation is subject to the
3 Align base with plate and screw on
following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
camera post.
Caution: Exposure to Radio Frequency Radiation.
The radiated output power of this device is far below the FCC radio frequency exposure limits. Nevertheless,
the device shall be used in such a manner that the potential for human contact during normal operation is
minimized. When connecting an external antenna to the device, the antenna shall be placed in such a manner
to minimize the potential for human contact during normal operation. In order to avoid the possibility of
exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than
20cm (8 inches) during normal operation.
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
IMPORTANT NOTE:
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End
users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain
compliance with FCC RF exposure compliance requirements, please follow operation instructions as
documented in this manual.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
IMPORTANT NOTICE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
2.5mm equipment should be installed and operated with a minimum distance of 23cm between the radiator and
your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Front
28
[711.200]
App Features:
5 After completing setup, set switch to . Tap camera name to view camera.
NETCAM HD
IC Statement:
This Class B digital apparatus complies with Canadian ICES-003
Wi-Fi HD Camera with Night Vision
Cet appareil numerique de la classe B conforme a la norme NMB-003 du Canada ®
Industry Canada Statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions: Quick Install Guide
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired operation
of the device.
Ce dispositif est conforme a la norme CNR- standards d'Industrie Canada applicable aux appareils radio
exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit
pas produire de brouillage prejudiciable, et (2) ce dispositif doit accepter tout brouillage recu, y compris un
brouillage susceptible de provoquer un fonctionnement indesirable.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20cm between the radiator and
your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement
non contrôlé.
Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de
rayonnement et votre corps.
Avertissement:
This radio transmitter (IC: 3623A-F7D7602V1/ Model: F7D7602V1) has been approved by Industry Canada
to operate with the antenna types listed below with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater
than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximal de PCB dipole antenne
avec dB [3.1]. Une antenne à gain plus élevé est strictement interdite par les règlements d'Industrie Canada.
L'impédance d'antenne requise est de 50 ohms.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peutfonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur) approuvé pourl'émetteur par Industrie Canada. Dans
le but de réduire les risques de brouillage radioélectriqueà l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que lapuissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire àl'établissement d'une communication satisfaisante.
Le présent émetteur radio (IC: 3623A-F7D7602V1/ Model: F7D7602V1) a été approuvé par Industrie Canada
pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et
l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le
gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
8820-01324 Rev.A00
F7D7602v1
Camera Status Icons: Tab to access your camera's settings page.
Online: Camera is available to share with
multiple guests.
Private: Camera is set to block all guests.
Offline: Camera is manually disabled.
An error occurred with the camera.
