Sunpak PF30X Instructions

Sunpak PF30X Flash Instructions
Congratulations on your purchase of a Sunpak PF30X flash dedicated for use on
the latest Canon, Nikon or Sony digital single lens reflex camera. Never use the
flash on any camera brand other than the one noted on the base of the flash.
Before use, please read the instructions carefully to take full advantage of its
features and safe usage.
Flash Safety
* For maintenance, inspection or repair, return to ToCAD America Inc.
* Never try to open, repair or modify the flash. Such action may result in fire,
shock hazard or injury due to high voltage.
* Never use accessories not specified by Sunpak. Using them may result in fire,
shock hazard or injury.
* If the flash is dropped or damaged, or impacted, return to ToCAD America Inc.
for service and repair.
* Never use the flash at close distances to subject's eyes, especially babies and
newborns. Using the flash at close distances to subject's eyes may result in
visual impairment. When shooting infants or newborns, keep the flash at a
minimum distance of 3 feet or greater.
* When loading batteries, install in the correct polarity. When replacing the
batteries, replace both at the same time, use only the same model and type and
from the same manufacturer. Incorrect battery usage may result in leakage, over
heating, rupture, short battery time and loose contacts.
* Never use the flash near glass or near containers holding cosmetics or
chemicals. If cosmetics or chemicals enter the flash, it may result in fire, shock
hazard or injury.
* Never use the flash in a place with high humidity, such as in the bathroom or
near a humidifier. It may result in fire, shock hazard or injury.
* When cleaning or caring for the flash, be sure to remove the batteries.
* Never use the flash in a place where flammable gas or explosive gas may exist
in the air.
* Keep batteries away from babies so that they will not be swallowed or ingested.
* Never place the flash in a dusty environment, subject to direct sunlight or area
of high humidity. Increased temperatures may result leading to serious damage,
shock hazard or fire.
* Never use the flash without the locking ring securely tightened. If left
un-tightened it may fall or drop from the camera resulting in injury.
Other Cautions
* Never use benzene, thinner or alcohol to clean the flash. Use a soft cloth
without chemicals or solvents.
*If subject to moisture, remove the batteries and dry completely before reusing.
*Neglecting any of these instructions may lead to injury or damage.
Before use
* Mount the flash on the camera and securely tighten the locking ring to secure to
the camera. For operation, be sure to hold the body of the camera, not the flash.
If the flash is used to hold the camera, the camera will break from the flash
causing serious damage to the flash and camera.
* For additional operating instructions and camera compatibility, go to
www.sunpak.jp.
Mounting
When the PF30X is mounted or dismounted from the camera, be sure to turn
OFF the Power switch. If the PF30X is mounted or dismounted with the power
ON, malfunction or failure of the camera may result.
1. Insert the flash into the camera's hot shoe firmly and turn the Locking Ring
clockwise to secure the flash to the camera. For Sony version, turn the
Locking Ring in the direction of the arrow until the ring locks into position.
2. After mounting the flash on the camera, turn on the camera and flash.
3. The shutter speed of the camera will automatically be set.
4. To confirm a correct exposure, the Auto Check function of the Test Charge
indicator will flash approximately two seconds. If Auto Check function of the Test
Charge indicator does not blink indicating a correct exposure, the distance from
the flash to the subject is too great. Move closer to the subject if possible until
confirmation of the Auto Check Test Charge indicator confirms the correct
exposure.
Flash Diffuser
Battery Cover
AF Assist Light
Bounce Head
- EV Indicator
- EV Selector
Auto Check
Power Switch
Locking Ring
(Canon & Nikon )
Hot Shoe
Locking Ring (Sony)
Hot Shoe (Sony)
Installing Batteries
1. Confirm that the Power switch is OFF before loading the batteries.
2. Press down on the Battery cover and slide it downwards to open it.
3. Carefully load 2 AA type batteries into the battery box in accordance with the +
- illustrations. The flash is designed to prevent incorrect loading, but if the
batteries are installed incorrectly, failure will result.
4. Close the battery cover and slide it upward to close securely. Turn power
switch to the ON position. Charging will start with the beep sound. During the
charging cycle, the Ready Lamp will blink indicating the charging cycle and then
to continues on for full charge status. (When fully charged, the lamp changes
from blinking to steady lighting.)
5. To turn off, turn the Power switch to the OFF position.
Before Mounting
* When the flash is not mounted on a camera and turned on, use caution not to
short-circuit the hot shoe terminals. If short-circuited, the flash may fire and
cause an operational failure of the flash.
* Nickel Metal-Hydride (NiMH) batteries are highly recommended to shorten the
charging time and increase the number flashes.
Information on the Ready Lamp
Confirm after each shot that the Ready Lamp is on and not blinking. If blinking,
charging is still taking place. If the flash is fired without the Ready Light on
continuously, there will be insufficient flash to illuminate the subject causing an
under exposure image. Therefore it is highly recommended for images with the
optimum amount of illumination, wait until Ready Light remains on continuously.
* If the Ready lamp continuously blinks for more than 30 seconds without
changing to a continuous illumination, the voltage of the batteries has dropped
below the recommend voltage and must be replaced.
+ EV Indicator
+ EV Selector
Ready Lamp/Test
