Swissebauches AD101-1 Instruction Manual

Features:
Mode Operation
Normal Time, Calendar, Alarm, Chronograph, Timer and Display ON/OFF.
Key Operation:
Rotate S2 to enter the Modes (→ Up; ←Down)
Normal Time
Calendar
1. NORMAL TIME
Press and hold S1 for 3 seconds to enter the setting mode and
Hour digits flash Rotate S2 up or down to increase or decrease the
digit.
Press S3 to jump from each of the setting items
Press S1 to exit the setting mode
S2 (adjust)
HOUR
For Analog Setting
Pull the crown out and turn the crown upward or downward to
adjust the hands at the desired time.
Remark:
Digital and analog setting procedures should be separated, e.g.
digital increase but the analog remain unchange.
For T2 Time:
In Normal Time Mode, press S3 to enter the T2 time mode, press S1
for 3sec. to enter the setting mode and the setting procedures are
shown as follows.
S2 (adjust)
HOUR
Remark:
1) In T2 Time mode the Analog will not change while setting in
digital. The date can only increase or decrease one day
2) The minute cannot be adjusted in T2
2 7 . 0 6 . 2 0 0 4
A D 1 0 1 - 1 I n s t r
A D 1 0 1 - 1 I n s t r
A D 1 0 1 - 1 I n s t r
Alarm
Chronograph
S2 (adjust)
S2 (adjust)
S3 S3
S3
SECOND
MINUTE
S3
S2 (adjust) S2 (select)
S3 S3
12/24H
DATE
S3
M o d e l : A D 1 0 1 - 1
u c t i o n M a n u a l
u c t i o n M a n u a l
u c t i o n M a n u a l
Set
Mode/Adjust
Shift
Timer
S2 (select)
12/24H
P a g e : 1/4
SWISSEBAUCHES
Normal Time
Date
Time Setting Mode
T2 Time Setting Mode
E d i t i o n : 3
