ULTRAGAIN PRO-8 DIGITAL ADA8000 Technical Specifications
ULTRAGAIN PRO-8 DIGITAL ADA8000
Audiophile 8-Channel A/D & D/A Converter with
Premium Mic Preamplifiers and ADAT Interface
Ultra-high quality 8-channel A/D and D/A converter for virtually any digital recording/mixing environment
8 state-of-the-art, studio-grade IMP "Invisible" Mic Preamps
Phantom power on all microphone inputs
Audiophile 24-bit A/D and D/A converters for ultimate signal integrity
Processes 44.1 and 48 kHz sample rates
External sample rate synchronization via wordclock or ADAT input
Optical ADAT in/out interface for ultimate compatibility
All mic/line inputs are routed to the ADAT output
ADAT input can be routed to all Line outputs
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany

Specifications

Microphone Inputs
Type
Gain range
Max. input level
Impedance
Phantom power
Line Inputs
Type
Impedance
Gain range
Max. input level
Line Outputs
Type
Impedance
Max. output level
Digital Input
Type
Format
Electronically balanced,
discrete input circuitry
+10 to +60 dB
+6 dBu @ +10 dB gain for 0 dBFS
approx. 2 kΩ balanced
+48 V, switchable
¼" TRS connector, electronically balanced,
discrete input circuitry
approx. 20 kΩ balanced,
approx. 10 kΩ unbalanced
-10 to +40 dB
+26 dBu @ -10 dB gain for 0 dBFS
XLR, electronically balanced
approx. 500 Ω balanced,
approx. 250 Ω unbalanced
+16 dBu @ 0 DBFS
TOSLINK, optical connector
ADAT, 8 channels,
24-bit @ 44,1/48 kHz
Digital Output
Type
Format
A/D Converter
Type
Dynamic range
D/A Converter
Type
Dynamic range
Synchronization
Source
Wordclock Input
Type
Input level
Frequency range
TOSLINK, optical connector
ADAT, 8 channels, 24-bit @ 44,1/48 kHz
24-bit, 64-times oversampling, delta-sigma
Analog input to digital output,
approx. 103 dB
24-bit, 128-times oversampling,
delta-sigma
Digital input to analog output,
approx. 100 dB
Internal 44.1 kHz, internal 48 kHz,
ADAT input, wordclock input
BNC, 1 x sample rate
2 to 6 V peak-to-peak
44.1 to 48 kHz
