- Page 1 REPAIR PARTS MANUAL MODEL NO. YP21KH42 (96041031300) LAWN TRACTOR 581 03 03-27...
-
Page 2: Table Of Contents
HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor. Some hardware and parts are drawn larger in order to more readily identify them. -
Page 3: Schematic
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 SCHEMATIC SCH10 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK BLACK SEAT SWITCH... -
Page 4: Electrical
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 ELECTRICAL T06S With 12V Outlet Option With Service Minder Option... - Page 5 TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 19 32-28 Box Battery 532 17 61-38 Switch Interlock 532 18 37-59 Harness Socket Light 532 00 41-52 Bulb, Light #1156...
-
Page 6: Chassis
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 CHASSIS Chassis-tex_elite basic_15... - Page 7 TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 CHASSIS PART DESCRIPTION 532 41 17-64 Dash 532 44 15-32 Hood 532 18 67-06 Grille 532 44 72-53 Plate Engine 817 06 05-12 Screw 5/16-18 x 3/4 532 44 34-76 Fender 873 68 05-00 Nut Lock 5/16-18...
-
Page 8: Drive
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 DRIVE 80 125 drive-tex_K46_pedal_102_r1... - Page 9 TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 DRIVE PART PART DESCRIPTION DESCRIPTION – – – – – – Transaxle, Tufftorq K46BT 532 42 91-64 Nut Push .625 (426120)(Order parts from 532 40 52-57 Latch Brake Parking transaxle manufacturer.) 532 19 43-22 Keeper Belt Centerspan 532 12 35-83 Key Square...
-
Page 10: Engine
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 ENGINE 21 20 SPARK ARRESTER KIT engine-tex_kohl_51... -
Page 11: Engine
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 ENGINE PART DESCRIPTION – – – – – – Engine Kohler Model No. SV610-3216 (581010801)(Order parts from engine manufacturer.) 532 18 86-55 Muffler 532 19 43-20 Keeper Belt Engine 532 40 54-71 Pulley Engine 532 40 75-45... -
Page 12: Steering
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 STEERING steering-tex_STDHRS_14... -
Page 13: Tractor - - Model Number Yp21Kh42 (96041031300), Product No. 960 41
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 STEERING PART DESCRIPTION 532 42 45-43 Wheel, Steering 532 41 81-68 Axle Asm., Front 532 40 30-87 Spindle Asm., LH 532 40 30-88 Spindle Asm., RH 532 12 49-31 Washer Thrust 0.75 x 1.23 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga. -
Page 14: Mower Deck
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 MOWER DECK 117 119 118 119 42_D_man-tex_LT_48... -
Page 15: Mower Deck
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 19 64-95 Mower Housing 872 11 06-16 Bolt Rdhd Sqnk 3/8-16 unc x 2 532 19 51-86 Arm Suspension 532 19 94-77 Arm Brake Mower 532 41 63-58 Screw #10 x 0.750 BOS Thread... -
Page 16: Mower Lift
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 MOWER LIFT 101* lift-tex_17_r3 *Key 91 may be substituted for Key 101 PART PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm., Cross Lift 532 19 51-81 Link Lift Susp Mower Rear 532 19 52-31 Lever Asm., Lift RH 817 00 06-12... -
Page 17: Seat
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 SEAT seat-tex_6.5SL_2 PART PART DESCRIPTION DESCRIPTION 532 41 14-05 Seat 873 80 05-00 Nut, Lock 5/16-18 unc 532 18 01-66 Bracket Pivot Fender 532 19 76-61 Handle Slide 532 14 06-75 Strap, Asm Fender 532 19 82-00... -
Page 18: Decals
TRACTOR - - MODEL NUMBER YP21KH42 (96041031300), PRODUCT NO. 960 41 03-13 PART PART DESCRIPTION DESCRIPTION 532 43 92-82 Decal, Str. Whl. STDHRS 532 43 92-76 Decal, Hood 532 16 88-69 Decal Tick Mark 581 01 61-02 Decal, Panel SD 532 15 97-36 Decal, Chassis 532 19 68-41... - Page 19 SERVICE NOTES...
-
Page 20: Limited Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
