Quicksilver Audio V4 Mono Amplifier Operating Instructions page 3

Power Output
Power Bandwidth
Peak Power
Input Sensitivity
Input Impedance
Tube Complement
Dimensions
Finish
Weight
Warranty
Quicksilver Audio warranties your amplifiers for a period of 3 years from the date of purchase
(90 days on tubes.) Parts and labor are provided free of charge as long as the failure was not
caused by misuse, accident or negligence. Shipping to the factory is not included.
Retain at least one packing carton in case a unit needs to be returned for service.
Quicksilver Audio V4 Mono Amplifier
SPECIFICATIONS
120 watts into 4 or 8 ohms
from 22 Hz to 40 KHz
18 Hz to 80 KHz
180 watts at 1 KHz
1.5 volts
100 K ohms
1 - 12FQ7 input
1 - 12BH7 or 12FQ7 driver
2 - KT88 outputs
7 7/8" high x 13 3/4" deep
x 16 3/4" wide
Nickel chassis
Carbide black capacitor and transformer cover
51 lbs.
3 years parts and labor
Tubes 90 days
WARRANTY
Quicksilver Audio
4119 Coronado Ave., Unit 8
Stockton, CA 95204
(209) 957-6640 / Fax 957-6641
www.quicksilveraudio.com
