Summary of Contents for Cowon Digital Pride D20
- Page 1 User’s Guide ver. 1.0 EN...
- Page 2 Product specification may change without notice. Images contained in this manual may differ from the actual product.
-
Page 3: Copyright Notice
+ Copyright Notice General + COWON is a registered trademark of COWON SYSTEMS, Inc. + COWON SYSTEMS, Inc. owns the copyright to this manual, and any unauthorized distribution of its contents, whether in part or in its entirety, is strictly prohibited. - Page 4 + Contents Before you start! Precautions Package Components Names of Parts and Functions Buttons / Charging Connecting and Disconnecting the PC Firmware Upgrade Basic Use Main Screen (Daily Life UI) Menu Screen I (Daily Life UI) Menu Screen II (Visible Layered UI) Clock Screen (Visible Layered UI) The Most Recent Screen (Visible Layered UI) Basic Menu...
-
Page 5: Before You Start
+ Do not attempt to disassemble the player. Disassembly will void the warranty and the unit will be permanently disqualified from any warranty services. + Be sure to use only the USB power adaptor and USB cable approved by COWON SYSTEMS, Inc. - Page 6 /or unit failure, voiding the warranty. + Be careful not to be torn or ruptured by any sharp materials, such as animals’ teeth. + Please handle the product with care as the stainless steel back of D20 is susceptible to scratch marks.
- Page 7 If necessary, wipe the polluted area carefully with a soft cloth. + In case of using this device primarily for a storage device, it is recommended to back up all data before use. COWON SYSTEMS Inc. is not responsible for any data loss due to hardware failure.
-
Page 8: Package Components
Before you start! + Package Components Quick Guide COWON D20 Earphones TV-Out Cable AC Adapter USB Cable (Optional) (Optional) * Actual package contents may differ from the above images. COWON D20... -
Page 9: Names Of Parts And Functions
RESET EXT Port SD/SDHC/MMC Card Slot * When buttons or touch do not work properly, please press RESET button. This reset only shuts off power in case of a device malfunction and does not affect the device's performance. COWON D20... - Page 10 General Hold or Touchscreen Hold in the System menu 4. Volume (-/+) - Lowers or raises the volume. 5. M Button - Returns to the menu screen. * The D20's default Power Off setting is Sleep mode, which consumes very little power. COWON D20...
- Page 11 - COWON D20 has a built-in Lithium Polymer battery. To prolong the life of the battery, it is recommended that you charge the device frequently, as opposed to fully discharging and then charging the device.
-
Page 12: Connecting And Disconnecting The Pc
1. Use the USB cable to connect COWON D20 to the PC. 2. COWON D20 displays the USB connected image if properly connected to the PC. 3. Also make sure to check My Computer or Windows Explorer to see if COWON D20 is properly connected to the PC. -
Page 13: Firmware Upgrade
2. Use the USB cable to connect COWON D20 to the PC. 3. Unzip the downloaded firmware and copy it to the root folder of COWON D20. 4. Perform “Safely Remove Hardware” function on your PC and disconnect the USB cable. - Page 14 ×, then the Daily Life the Menu screen, then the UI changes automatically last Daily Life UI selected depending on the time of before powering off the device day, regardless of the user's remains set as the main last choice. screen. COWON D20...
- Page 15 + Menu Screen I (Daily Life UI) Drag the main screen upwards to display four menus. * Smart Return : Drag the screen upwards while on the last menu to return to the first menu. Drag Rotates the screen 180 degrees. COWON D20...
- Page 16 + Menu Screen II (Visible Layered UI) Press the Theme icon in the Options menu to change to the Visible Layered UI. Touch Visible Layered UI ▶ Touch To return to the Daily Life UI, simply touch the Theme icon again. COWON D20...
- Page 17 Clock screen upwards to display the Calendar and User Name screens. Drag Drag Drag 길게 터치 Touch and hold the Put Your Name screen to display a panel to enter the user's name. Press the keyboard-shaped icon to return to the previous screen. COWON D20...
- Page 18 13 screens. Drag The 13 Most Recent Items Music / Videos / Pictures / Radio / Documents / Flash / Recorder / Browser / Calculator / Settings / Notepad / Typist / Stopwatch COWON D20...
-
Page 19: Basic Menu
Set & read documents at your preference. Documents Access data stored in different folders on the device. Browser Play Flash games and animations. Flash Record sounds through the microphone. Recorder Change settings at user’s convenience. Settings Calculate numbers using the calculator. Calculator COWON D20... - Page 20 Change the theme of the UI. Theme If ○, the main screen remains fixed on the Daily Life UI selected by the user. User Defined If ×, the Daily Life UI changes automatically at different times during the day regardless of the user's choice. COWON D20...
- Page 21 Press Next to reveal a hidden selection screen. Press Prev to return to the previous selection screen. The Prev icon is inactive if you are on the first selection screen. Touch the icon to return to the parent menu. COWON D20...
- Page 22 * Customize a preset by touching the cogwheel icon next to each user and adjusting the sound effects. Use to apply detailed settings for the COWON D20's display, such as Display Language, Font, Time display, Auto display off, Brightness, TV-out standard, and Screen rotation.
- Page 23 Reverb Maximize the natural and live presence of the sound. (9 Modes) * You may hear distortion or noise when using extreme settings of JetEffect 5. For more information about JetEffect 5, visit us at www.COWON.com COWON D20...
-
Page 24: Product Specification
FLAC : Compression Level 0 - 8, 44.1KHz, Mono / Stereo APE : Fast compression, Normal, High compression 16Bit, ver. 3.97~3.99 WAV : 48KHz, 16bit, Mono / Stereo Meta Tag ID3 V1, ID3 V2.2 / V2.3, Vorbis comments COWON D20... - Page 25 The storage capacity may differ from the actual capacity due to the space used to store system files. The playback time is based on the company’s own test standards, thus it may differ from the actual playback time. COWON D20...
-
Page 26: Troubleshooting
+ I am still confused even after reading the manual. COWON website (www.COWON.com) provides support for users of COWON products with FAQ (Frequently Asked Questions) Users are strongly encouraged to check out the website for further information regarding product usages and firmware upgrades. For individual inquiries, please contact us on-line as we will try to help you as best as we can. - Page 27 6 album images. + Video won’t play. Make sure that your files are in a format that D20 supports (check the codecs/resolution/options). If you’re unsure of a video’s compatibility,use a video conversion program (e.g. JetAudio) and then play the converted version.
- Page 28 Set your preferred language again in Settings ▶ Display ▶ Language. If the problem persists, set the current font to the system font. COWON products are developed based on the Korean Windows OS, and this may cause corruption of some special fonts or languages on the display.
- Page 29 'EJECT’ procedure must be performed before removing the device from the PC. The device can malfunction with MAC OS 10.5 Leopard version or later. If the device shows a problem, format it as FAT and install the latest firmware. COWON D20...
-
Page 30: Battery Replacement
The rechargeable batteries have limited number of charge cycles, and it will require a replacement as capacity to hold power will eventually diminish. The rechargeable batteries in COWON products should be replaced only by official COWON service centers. Please contact batteryreplace@cowon. -
Page 31: Product Disposal
+ Product Disposal COWON products contain built-in rechargeable batteries, and must be separately disposed from household waste. Disposing the products with regular waste may cause pollution to the environment due to the waste batteries inside. Contact your local authorities for specified locations / guidance of E-waste and waste batteries, and dispose them in compliance with local regulation / guidance. - Page 32 www.COWON.com...
