VERTICAL FLOAT SUMP PUMP
SET UP And OPERATIng InSTRUCTIOnS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MAnUAL.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
95591 - .75 HP
Model
95592 - 1 HP
Model
95593 - 1.5 HP
3491 Mission Oaks Blvd., Camarillo, CA 93011
. All rights reserved. No portion of this
®
.
®
Cover revised 07l
Advertisement
Table of Contents
Related Manuals for Chicago Electric 95591-.75 HP
Summary of Contents for Chicago Electric 95591-.75 HP
- Page 1 VERTICAL FLOAT SUMP PUMP Model 95591 - .75 HP Model 95592 - 1 HP Model 95593 - 1.5 HP SET UP And OPERATIng InSTRUCTIOnS Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. distributed exclusively by Harbor Freight Tools ®...
-
Page 2: Specifications
SPECIFICATIOnS Model 95591 Model 95592 Model 95593 Motor 115 V~ / 60 Hz / 4 A 115 V~ / 60 Hz / 5.5 A 115 V~ / 60 Hz / 6 A / 3/4 HP / 1 HP / 1.5 HP Power Switch Type Automatic Float Switch Power Plug Type... -
Page 3: Electrical Safety
ELECTRICAL SAFETY grounded tools must be plugged into a gFCI (ground Fault Circuit Interrupt- er) outlet, properly installed, and grounded in accordance with all codes and ordinances. never remove the grounding prong or modify the plug in any way. Do not use any adapter plugs. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. -
Page 4: Specific Safety Rules
Store idle equipment out of reach of children and other untrained persons. Electrically-powered products are dangerous in the hands of untrained users. Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect this product’s operation. If damaged, have the Sump Pump serviced before using. - Page 5 This Pump is designed to move clean or dirty water only. Do not pump water hotter than 95 degrees Fahrenheit. Make sure the discharge pipe (not included) is secured to a solid surface to ensure the stability of the Pump. Make sure to position the Pump on a flat, level, solid surface.
- Page 6 gROUndIng of electric shock. (See 3-Prong Plug and Outlet.) TO PREVEnT WARnIng The grounding prong in the plug is ELECTRIC connected through the green wire in- SHOCK And dEATH FROM side the cord to the grounding system InCORRECT gROUndIng in the tool. The green wire in the cord WIRE COnnECTIOn: must be the only wire connected to Check with a qualified...
- Page 7 Double insulated tools may be used dition. Always replace a damaged in either of the 120 volt outlets shown extension cord or have it repaired by in the preceding illustration. (See a qualified electrician before using it. Outlets for 2-Prong Plug.) Protect the extension cords from sharp objects, excessive heat, and Extension Cords...
- Page 8 UnPACKIng When unpacking, check to make sure all the parts shown on the Parts List on page 12 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. ASSEMBLY And OPERATIng InSTRUCTIOnS note: For additional information regarding the parts listed in the following pages, refer to the Assembly diagram on page 13.
- Page 9 FIgURE E CHECK VALVE UnIOn (nOT InCLUdEd) TO 115 VOLT, gROUndEd gFCI OUTLET dISCHARgE PIPE (nOT InCLUdEd) 1/8” AIR BLEEd HOLE BASE (25) Connect the Discharge Pipe to the Base (25). nOTE: Make sure the Discharge Pipe is secured to a solid surface, with appropriate hardware (not included), to ensure the stability of the Pump.
-
Page 10: Inspection, Maintenance, And Cleaning
Carefully set the Pump in place. do not lower or raise the Pump by the Power Cord or discharge Pipe. (See Figure E.) The Float Switch (2) automatically switches on and off at a water depth of approxi- mately 4 inches. The ON/OFF height can be manually changed by adjusting the Float Switch Lock. -
Page 11: Troubleshooting
To clean the Impeller Cover and Impeller: A clogged or dirty Impeller Cover or Impeller (28) will greatly reduce performance of the Pump. To clean the Impel- ler Cover (31), spray the Cover with clean water. To clean the Impeller, remove the nine Screws (32) at the bottom of the Base (25). -
Page 12: Please Read The Following Carefully
PLEASE REAd THE FOLLOWIng CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 13: Assembly Diagram
ASSEMBLY dIAgRAM For technical questions, please call 1-800-444-3353 SKU 95591/95592/95593 PAGE 13... -
Page 14: Limited 90-Day Warranty
LIMITEd 90 dAY WARRAnTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this prod- uct is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
