Aztech WL830PC Easy Start

WL830PC Easy Start
ATTENTION: Please DO NOT insert your
wireless PC card to your computer UNTIL
you have installed the software FIRST.
Introduction
Thank you on your purchase of WL830PC Wireless Card.
WL830PC Wireless Card provides user the flexibility to connect to the Internet in a
wireless environment.

Operating System Requirement

MS-Windows 98 SE (Second Edition)
MS-Windows 2000
MS-Windows Me (Millennium Edition)
MS-Windows XP Home/Professional Edition

Installing the Driver

For Windows 98 SE Users
Please click cancel at the Start up page (if prompted) after you have
inserted the Installation CD. Please run the file Wmi9x.exe located in the
root directory of the Installation CD before installing the driver. (Eg. D:\
Wmi9x.exe)
iii Insert Installation CD into the CD-ROM drive. If the
automatically, please run the Setup.exe
ii
Click "Next".
iii Select "I accept the terms of the license agreement"
iv Click "Next" to continue with the rest of the installation steps.
For Windows XP Users, you would encounter a screen that says "Software Installation".
This is normal, just click "Continue Anyway".
v. Click "Finish" to end the Installation wizard.
Insert WL830PC Wireless Card into the PCMCIA slot firmly and evenly. Take care not
to force it into the slot. WL830PC Wireless Card will automatically run its own
installation setup.
For Windows 98 SE Users, skip the file when prompted for
after the driver installation has completed.
For Windows 98 SE / ME Users
Please locate the file ar52119x.sys found in root directory of the Installation
CD if prompted for missing ar52119x.sys file. (Eg. D:\ ar52119x.sys)
The Installation will activate the Client Utility icon
taskbar. You can find the icon at the right-bottom of your screen.
Installation CD does not start
program located on the CD-ROM.
and click "Next".
.CAT file. Restart the PC
in the "system tray" of the Windows
For configuring your wirless card, double-click the
under Help > Atheros Client Utility Help.
Follow on screen instructions to configure your wireless card.

Uninstalling the Drivers

On your Desktop , Click on the
iii
ii
Click "Control Panel".
iii Double click "Add/Remove Programs".
iv Double click "Atheros Wireless Network Adapter and Applications"
v Under the "Atheros Install Program For Wireless Network Adapter
please select "Delete the previous installation".
vi Follow on-screen instruction to uninstall the driver.
LED Specification
Power LED Network LED
Slow-rate Blink OFF
OFF
ON
Alternate Blink
Alternate Blink
Slow-rate Blink
Slow-rate Blink
Fast-rate Blink
Fast-rate Blink
OFF
OFF
© Copyright Jan 2004. All Rights Reserved.
P/N: 040-511553-101
Client Utility icon and select
"My Computer" icon.
Products",
Meaning
Power Save Mode (default
from power up or reset)
Awake
Search for network
association
Associated with network - No
activity
Associated with network -
blink increases with activity
No power
