- Page 1 AW500 AW600 owner's manual analog and digital systems...
- Page 2 Thank you for purchasing an a/d/s/ All Weather Loudspeaker system. The AW500 and AW600 are the perfect choice for supplying high fidelity sound in outdoor or marine applications. Their advanced polymer housings are designed to be acoustically inert and capable of surviving in harsh environments.
-
Page 3: Mounting The Speakers
mounting the speakers Before mounting the speakers in brackets, plan the mounting location and method very carefully. Follow the speaker placement guidelines described in the instruction manual and decide on the mounting locations. If you plan to hide the speaker wires behind the mounting surface, route the wires before you mount the brackets. - Page 4 wiring Wire Use two-conductor stranded-type, insulated wire to connect the speakers to the amplifier. "Lamp" wire or "zip cord" works well. If you are running wiring within the walls, make sure that it complies with your local building codes pertaining to low-voltage wiring. Use at least 16 gauge for runs of less than 50 feet.
-
Page 5: Troubleshooting
10 Watts - 75 watts RMS Cabinet size: 6.5" (165 mm) h x 7.13" (181 mm) w x 6.63" (168 mm) d AW600 Driver complement: 1" (25 mm) silk dome tweeter 6-½" (165 mm) high compliance woofer with rubber surround Frequency response: 55 - 20kHz, ±... -
Page 6: Warranty Information
Directed Electronics Inc. manufacturer address: One Viper Way Vista, California 92081 declares, that the product: product name: AW500 AW600 conforms to the following standards: EN55013 EN55020 © 2004 Directed Electronics, Inc. All rights reserved G39735/40 10-04...
