Intelligent instrumentation UDAS-1001E Series User Manual

Udas-1001e series multifunction data acquisition system
Hide thumbs
Table of Contents

Advertisement

Quick Links

INNOVATIVE PC Data Acquisition Solutions
UDAS-1001E Series
Hardware User Manual
for the
Multifunction Data Acquisition System
855M495
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UDAS-1001E Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Intelligent instrumentation UDAS-1001E Series

  • Page 1 INNOVATIVE PC Data Acquisition Solutions UDAS-1001E Series Hardware User Manual for the Multifunction Data Acquisition System 855M495...
  • Page 2 Copyright 2000 by Intelligent Instrumentation Inc., Tucson, Arizona, USA All rights reserved. Warranty and Repair Policy Statement Warranty and Repair Policy Statement General Seller warrants that its products furnished hereunder will, at the time of delivery, be free from defects in material and workmanship and will conform to Seller's published specifications applicable at the time of sale.
  • Page 3 Warranty. Online Support If errors persist after repeatedly checking the unit as described in the UDAS-1001E Series Hardware User Manual, check the technical support links on Intelligent Instrumentation’s 24- hour World Wide Web site at http:// www.instrument.com. The site contains information on Intelligent Instrumentation’s products, new developments, announcements, application notes,...
  • Page 4 Trademarks Trademarks U-Link Software Libraries is a trademark of Intelligent Instrumentation Incorporated. VisualDesigner is a registered trademark of Intelligent Instrumentation Incorporated. LabVIEW is a registered trademark of National Instruments Corporation. Windows 98 is a registered trademark of Microsoft Corporation in the U.S.A. and other countries.
  • Page 5 UDAS-1001E Series User Manual Revision History Version Date Revision 000218 Original Release...

  • Page 6: Table Of Contents

    Table of Contents UDAS-1001E Series Data Acquisition Systems Chapter 1 Introduction ..........
  • Page 7 Specifications Appendix A UDAS-1001E Series Hardware Specifications..... TABLE A.1 Hardware Specifications ......

  • Page 8: Udas-1001E Series Data Acquisition Systems 1.1 Introduction

    Acquisition Systems 1.1 Introduction Introduction The UDAS-1001E Series Data Acquisition Systems are stand-alone, multifunction, plug-and-play data acquisition systems that connect to the Universal Serial Bus and operate using power supplied through either the USB connector or an external power supply.

  • Page 9: Features

    UDAS-1001E Series Data Acquisition Systems 1.1.1 1.1.1 Features Features Features and basic specifications of the UDAS units are listed below. Specifications of each UDAS unit are listed in Appendix A, Specifications. The UDAS system block diagram is shown below. DIGITAL I/O...
  • Page 10 UDAS SYSCHECK The SYSCHECK application enables you to verify the UDAS installation is functioning properly. SYSCHECK can also be used during the calibration procedure and for simple data acquisition. U-Link Software Libraries for Windows 98 These function libraries allow custom application development using C/C++ and Visual Basic. LabView 5.0 Support Library Allows the use of UDAS with LabVIEW.

  • Page 11: Udas 1001E Series Functional Description

    UDAS-1001E Series Data Acquisition Systems Digital Input/Output Digital Input/Output • 16 Programmable digital I/O channels. Groups of 8 separately programmable for input or output. • Digital inputs can be programmed to read digital signal status, detect a change-of-state or to perform low speed event counting (up to 2 kHz).
  • Page 12 • Programmable gains are 1, 10, and 100 which translate to a full-scale input of 0-10 V, 0-1.0 V, 0-0.1 V, 10 V, 1.0 V, 0.1 V, 5 V, 0.5 V, and 0.05 V. ± ± ± ± ± ± •...
  • Page 13 UDAS-1001E Series Data Acquisition Systems If an analog input is used for the trigger, specify the trigger level, analog input channel, and slope. Use analog output channel 1 for setting the trigger level. Note: When using analog input channel 1 for a trigger, do not use this channel for any other purpose.
  • Page 14 The scanner operates with the built-in analog channels, or with the optional AI-MAX. The AI- MAX allows up to 256 analog input channels to be connected to a single UDAS device. Note: The scanner begins on the selected trigger channel and not channel 0 when the start on trigger mode is used with an analog input trigger.

  • Page 15: Analog Output

    UDAS-1001E Series Data Acquisition Systems Example: If 9 channels are being scanned at a rate of 100Hz and the slope is low to high, the trigger signal must remain below the trigger level for 9/100 of a second, and above the trigger level for 9/100 of a second to ensure that a trigger event occurs.
  • Page 16 Digital I/O signals are TTL-compatible and perform functions such as reading digital inputs, driving digital outputs, and detecting input change-of-state. Digital I/O direction is programmable separately for each port through software. A nine-position DIP switch is provided inside of the unit to select the power-up direction of Digital I/O Port 1 (input/output) and to individually set power-up output states for each bit.

  • Page 17: Figure 1.2 Udas-1001E-4 Dimensional Drawing

    UDAS-1001E Series Data Acquisition Systems A diagram of the termination panel for the UDAS-1001E-4 unit is shown below. 5.750 6.600 1.520 7.290 FIGURE 1.2 UDAS-1001E-4 dimensional drawing 1-10...

  • Page 18: Power

    1.2.2 1.2.2 Power Power The UDAS unit normally uses power from the host computer via the USB cable. Power can also be obtained from an external power supply that is available (See Appendix B, Accessories). When the UDAS unit is connected to a power source, the computer controls the power. The unit does not have a power switch.
  • Page 19 UDAS-1001E Series Data Acquisition Systems Visual Designer UDAS Support Library This support package provides the block functions necessary to acquire data and output data using the UDAS device. To use Visual Designer or the Visual Designer Evaluation Version with an UDAS unit, the Visual Designer UDAS Support Library must be installed on the computer.

  • Page 20: Configuration And Installation 2.1 Introduction

    Configuration and Configuration and Chapter 2 Chapter 2 Installation Installation 2.1 Introduction Introduction This chapter contains instructions on the configuration and installation of the UDAS unit. 2.2 Power-on Default Digital I/O Configuration Power-on Default Digital I/O Configuration In some situations, it is important to have the digital output port on a UDAS unit initialize at power-on to a particular state.

  • Page 21: Figure 2.1 Udas Switch S1

    Configuration and Installation Setting the Configuration Setting the Configuration Switches 1-8 set the initial levels of the port’s channels 0-7 if the port is set for output operation. A switch set to the On position sets the corresponding port’s output channel to a high level (TTL +5V) on power-up.
  • Page 22 If you plan to use any of the digital I/O ports for output control in your application(s), note the following Caution statement: CAUTION: For applications using UDAS units to generate output signals for control or other sensitive purposes, the status or level of outputs during power-up may be of critical importance.

  • Page 23: Table

    Configuration and Installation Channels connected to a thermocouple must be connected to bias resistors for proper operation. Use jumpers JP2 and JP3 Note: When monitoring thermocouples, always use differential channels. To select the jumpers for each channel that you plan to use for thermocouples, use TABLE 2.1, CJC Jumper Positions shown below.

  • Page 24: Connecting The Udas Unit

    SYSCHECK software is included on the UDAS-1001E Data Acquisition System CD and can also be found on Intelligent Instrumentation’s web site. See Section 1.3.1, Software Support, on page1-11 in Chapter 1, UDAS-1001E Series Data Acquisition Systems. For information on using SYSCHECK, see Chapter 3, Checking the System in this manual.
  • Page 25 Checking the System Checking the System Chapter 3 Chapter 3 3.1 Introduction Introduction This chapter contains instructions for installing and using the UDAS SYSCHECK software. The software contains diagnostic features that verify the UDAS unit is functioning. WARNING! Use extreme caution when using SYSCHECK. The UDAS SYSCHECK software could cause unexpected results in the equipment that you connect to the UDAS unit.

  • Page 26: Checking The System 3.1 Introduction

    Checking the System 3.2 Installing and Running UDAS SYSCHECK Installing and Running UDAS SYSCHECK UDAS SYSCHECK provides an easy-to-use graphical interface for using and displaying the I/O capabilities of the UDAS unit. System Requirements System Requirements • UDAS SYSCHECK 1.0 only runs on Windows 98. •...

  • Page 27: 3.3.1 Unit Info

    3.3.1 Unit Info The Unit Info dialog displays the number of UDAS units detected and has a drop down list containing the serial number for each UDAS unit detected by SYSCHECK. FIGURE 3.1 Unit Info dialog If there is only one UDAS unit, the message shown beneath the drop down list displays the unit type and self-test results.

  • Page 28: 3.3.2 System Check

    Checking the System 3.3.2 System Check When the System Check tab is selected, a dialog containing buttons used to execute a variety of system test programs appears as shown in FIGURE 3.2, UDAS SYSCHECK System Check dialog. FIGURE 3.2 UDAS SYSCHECK System Check dialog The System Check tabbed dialog displays four major sub-functions possible on the UDAS units.

  • Page 29: Analog Input Test

    3.3.2.1 Analog Input Test 3.3.2.1 Analog Input Test Click the Analog In button to access a new window specific to analog input. The UDAS SYSCHECK ANALOG INPUT dialog shown in FIGURE 3.3, UDAS SYSCHECK Analog Input Test of a UDAS unit appears. The analog input test performs software-based reading of the first 8 analog input channels on UDAS units.

  • Page 30: Analog Output Test

    Checking the System 3.3.2.2 Analog Output Test 3.3.2.2 Analog Output Test The analog output test controls the voltage on the analog output channels of the UDAS unit. In the UDAS SYSCHECK Test Category Selection Window, click the Analog Out button and the UDAS SYSCHECK ANALOG OUTPUT dialog shown in FIGURE 3.4, UDAS SYSCHECK Analog Output Test of a UDAS unit opens.

  • Page 31: Counter Test

    3.3.2.3 Counter Test 3.3.2.3 Counter Test The counter test monitors TTL transitions that are connected to the counter input of the UDAS unit. Depending on the mode that you select, the TTL level of the gate pin may effect the readings. For all of the modes except Measure frequency, data is automatically read and displayed four times per second.

  • Page 32: Figure 3.6 Udas Syscheck Counter Test: Measure Input High Mode

    Checking the System For the Count when gate is high and the Count when gate is low modes, the TTL level of the gate enables or disables counting, depending on the mode that you set. If there is no input connected to the gate input, use the Count when the gate is in high mode.

  • Page 33: Figure 3.7 Udas Syscheck Counter Test: Measure Frequency Mode

    Select the desired Gate Time. The data displays shown at the lower portion of the dialog provide the status and the frequency in hertz. FIGURE 3.7 UDAS SYSCHECK Counter Test: Measure Frequency Mode The gate time is the amount of time that UDAS uses to count TTL transitions. This time base allows frequency to be calculated by the software.

  • Page 34: Figure 3.8 Udas Syscheck Digital I/O Test

    Checking the System Digital I/O Test Digital I/O Test The Digital Input/Output test enables you to read data from, or write data to, either 8-bit Digital I/O port on a UDAS unit. FIGURE 3.8, UDAS SYSCHECK Digital I/O Test shows an example test of the UDAS unit that has two 8-bit digital I/O ports.

  • Page 35: 3.3.3 Paced Analog Input

    3.3.3 Paced Analog Input The Paced Analog Input dialog enables you to configure a hardware-paced analog input process. Select the number of channels to include in the data run, select the gain, and select the single- ended/differential from drop-down lists in each field. See FIGURE 3.9, UDAS SYSCHECK Paced Analog Input Window.

  • Page 36: Figure 3.10 High-Speed Aquisition Sample

    Checking the System Clicking the High-Speed Run button (shown in FIGURE 3.9, UDAS SYSCHECK Paced Analog Input Window) configures and starts the process. This launches a full screen window that displays the results of the run. FIGURE 3.10 High-Speed Aquisition Sample The time base is displayed on the x-axis and the voltages are displayed on the y-axis.

  • Page 37: Troubleshooting Tips

    3.4 Troubleshooting Tips Troubleshooting Tips 3.4.1 Basic Troubleshooting If you are unable to successfully communicate with the UDAS unit, this section contains troubleshooting hints which may help identify the problem. Verify that all of the proper connections have been made between the computer, UDAS unit(s), and the equipment being monitored.
  • Page 38 Checking the System UDAS Drivers UDAS Drivers Verify the UDAS system driver is properly installed by following the instructions for the USB Port (above). Click on the plus sign (+) located next to the Universal serial bus controller. When the directory opens, double-click III Taos USB Data Acquisition System.
  • Page 39 • Check the wiring and cables for shorts or damage. Note: For units with USB cables connected directly to the computer as a power source, when the computer’s power is off or if the computer is in a suspended mode, the UDAS unit shuts down. If errors still persist after repeatedly checking the unit, check the technical support links on Intelligent Instrumentation’s web site http://www.instrument.com for the most current support information and contact addresses.

  • Page 40: A.1 Udas-1001E Series Hardware Specifications

    Specifications Specifications Appendix A Appendix A A.1 UDAS-1001E Series Hardware Specifications UDAS-1001E Series Hardware Specifications All specifications are typical at 25ºC unless otherwise noted. Note: When powered from an external source, the on-board power supply circuit can supply up to 200mA at 5V DC to termination panels through the 50-pin I/O connector.

  • Page 41: Appendix A Specifications

    Specifications PARAMETER CONDITIONS SPECIFICATION Noise Input grounded at connector (RMS) Gain <=10 1.0 LSB Gain = 100 DC Accuracy No missing codes, guaranteed Linearity Error ±0.024%FS (± 1LSB) Throughput 100 k Samples/second Analog Trigger (with AO option) Range ±10 V Hysterisis 28 mV Resolution...
  • Page 42 PARAMETER CONDITIONS SPECIFICATION Resolution 32-Bit Number of Channels Max Input frequency TTL-level input 2 MHz TimeBase Generator Type Crystal-based Rate Generator (24-Bit) Number 2 (1 analog input, 1 analog output) Resolution 125 ns Output Frequency Range 0.5 Hz to 1 Mhz Output Levels TTL-compatible Bus Interface...

  • Page 43: Udas-1001E-3, Udas-1001E-4 Dimensions

    Specifications A.2 UDAS-1001E-3, UDAS-1001E-4 Dimensions UDAS-1001E-3, UDAS-1001E-4 Dimensions UDAS units are housed in standard metal enclosures made of a rugged extruded aluminum base (connected to chassis ground) with a vinyl-clad steel cover. Interior tracks on side rails hold the circuit board securely in place. This page provides the dimensions of each unit with the connectors.

  • Page 44: Figure A.3 Dimensions Of The Udas Unit (Bottom View)

    4.700 .525 4-40 FH SCREW 1.295 4.700 4 PL FIGURE A.3 Dimensions of the UDAS unit (Bottom view)

  • Page 45: Figure A.4 Dimensional Drawing Of The Udas Series Pcb

    Specifications The dimensions of the UDAS PC board are shown below in FIGURE A.4 Dimensional Drawing of the UDAS series PCB. 5.305 4.70 6-32 HEX STANDOFF 0.21 1.16 4.70 TYP, 4 PL 7.02 0.60 MAXIMUM COMPONENT HEIGHT 0.15 FIGURE A.4 Dimensional Drawing of the UDAS series PCB...

  • Page 46: Udas I/O Connectors

    A.3 UDAS I/O Connectors UDAS I/O Connectors Signal Name Single Ended Input Function Differential Input Function Analog Input Channel 0 Analog Input Channel 0+ Analog Input Channel 1 Analog Input Channel 1+ Analog Input Channel 2 Analog Input Channel 2+ Analog Input Channel 3 Analog Input Channel 3+ Analog Input Channel 4...
  • Page 47 Specifications Signal Name Single Ended Input Function Differential Input Function AO 0 Analog Output Channel 0 AO 1 Digital I/O bit Digital Port 0 bit 0 Digital I/O bit Digital Port 0 bit 1 Digital I/O bit Digital Port 0 bit 2 Digital I/O bit Digital Port 0 bit 3 Digital I/O bit...

  • Page 48: Table

    Signal Name Single Ended Input Function Differential Input Function External Input External Trigger or Pacer input Digital Ground Ground Digital Ground Ground Unused Unused TABLE A.2 UDAS I/O Connectors (Continued)

  • Page 49: Table

    This appendix includes information on the termination and mounting accessories that are available separately from Intelligent Instrumentation for the UDAS unit. TABLE B.1, Accessories for the UDAS-1001E Series provides the model numbers for the UDAS units, the cables, and the power adpaters.

  • Page 50: Udas Termination Panels

    Accessories B.1 UDAS Termination Panels UDAS Termination Panels The Termination Panel plugs directly into the I/O connectors of the UDAS unit, providing 32 channels of digital I/O through four screw-type terminal strips. Stand-off nuts on the UDAS unit secure the termination panel in place. B.1.1 B.1.1 PCI-20429T-1 Multifunction Termination Panel...

  • Page 51: Figure B.2 Pci-20429T-1 Multifunction Termination Panel

    FIGURE B.2, PCI-20429T-1 Multifunction Termination Panel shows the signals assigned to each terminal block on this panel. PORT 0: Bit 0 is also high- speed counter input. AGND AGND PORT 0 AI10 DGND DGND AI11 AGND AGND PORT 1 AI12 AI13 AI14 AI15...

  • Page 52: Udas Termination And Signal Conditioning Options

    Accessories B.1.2 B.1.2 UDAS Termination and Signal Conditioning Options UDAS Termination and Signal Conditioning Options FIGURE B.3, UDAS-1001E Termination Options uses the various UDAS-compatible termination panels currently available from Intelligent Instrumentation. Also reference FIGURE B.4, UDAS- 1001E Termination Options (continued). The EDAS-1010T-1 Analog I/O Termination Panels and EDAS-1011T-1 Digital I/O Termination Panels are designed for ease-of-use with UDAS units.

  • Page 53: Figure B.4 Udas-1001E Termination Options (Continued)

    PCI-20305T-1 Digital I/O Customizer Termination Panel 16 Channels PCI-20324T-1 PCI-20311A -1 Opto-Isolated Digital I/O Panel Standard-Density 8 Channels for use with 1100 Series Shielded Digital Opto-Isolator blocks Digital Cable PCI-20326T-1 Opto-Isolated Digital I/O Expander Panel 8 Extra Channels for use with 1100 Series Digital Opto-Isolator blocks PCI-20355T-1 Relay Output Panel...

  • Page 54: Figure B.5 Diagram Of The Pci-20430A-1'S Connectors And Cables

    Accessories Analog In Single- Analog In Analog In Single-Ended Ended Function Differential Function and Differential Function Analog In (+) Chan 0 Analog In (+) Chan 8 Analog In (-) Chan 0 Analog Ground Analog In (+) Chan 9 Analog In (-) Chan 1 Analog In (+) Chan 1 Analog Ground Analog In (+) Chan 2...

  • Page 55: Isolator Blocks

    B.1.3 B.1.3 Isolator Blocks Isolator Blocks PCI-1100 Series Digital Opto-Isolator Blocks PCI-1100 Series Digital Opto-Isolator Blocks The PCI-1100 Series are digital, optically isolated, signal conditioning blocks. A separate opto- block is used for each channel, allowing complete I/O flexibility. The twelve different opto-blocks are divided into two groups: standard and slim-line. Both standard and slim-line models can be used on EDAS-1011T-1 Panels.

  • Page 56: Appendix C Analog Input And Output Calibration Procedures

    Analog Input and Output Analog Input and Output Appendix C Appendix C Calibration Procedures Calibration Procedures C.1 UDAS Analog Input Circuit Calibration UDAS Analog Input Circuit Calibration Procedures Procedures The analog input section of each UDAS unit is calibrated at the factory prior to shipment. If your application requires periodic calibration checks or if inaccuracies occur, use the procedures below to calibrate the UDAS unit.

  • Page 57: Figure C.1 Locations Of Potentiometers For Adjusting Analog Circuits C

    Analog Input and Output Calibration Procedures Connect the UDAS to the host computer and allow at least a 15 minute warm-up period before performing the adjustments. CAUTION: The unit may become damaged if you use an uninsulated screwdriver and accidentally touch other components. FIGURE C.1 Locations of Potentiometers for Adjusting Analog Circuits on page C-2 shows the locations of the potentiometers used to adjust the analog circuits on a UDAS unit.

  • Page 58: Analog Input Calibration Procedure

    C.1.2 C.1.2 Analog Input Calibration Procedure Analog Input Calibration Procedure Calibrating the analog input section requires adjusting the input offset voltage, the ± 10V range, ± 5V range, and the 0 to 10V range. The procedures are listed separately, but should be performed during a single calibration session.
  • Page 59 Analog Input and Output Calibration Procedures Note: On all adjustments, there is likely a range of adjustment resulting in the proper reading. Determine this range and leave the adjustment in the center of the range. Set the calibrated input to 9.5068 V. Adjust Pot R46 for 9.5068 V.
  • Page 60 Repeat the procedure and verify the adjustments are correct. Note: These adjustment steps are very interactive and may require several iterations. Adjust Offset and Gain for 0 to 10 Volt Range Adjust Offset and Gain for 0 to 10 Volt Range Verify the termination panel is attached to the 50-pin connector of a UDAS unit.

  • Page 61: Udas Analog Output Circuit Calibration Procedure

    Analog Input and Output Calibration Procedures C.2 UDAS Analog Output Circuit Calibration UDAS Analog Output Circuit Calibration Procedure Procedure This section applies to models UDAS-1001E-2, UDAS-1001E-2G, and UDAS-1001E-4 that are equipped with the analog output feature. The analog output channels on the UDAS unit are calibrated at the factory. If your application requires periodic calibration checks or if you suspect inaccuracies, use the following procedures to calibrate the unit.
  • Page 62 Analog Output Channel 0 Offset and Gain Analog Output Channel 0 Offset and Gain Verify the termination panel is attached to a 50-pin connector of a UDAS unit. Begin with step 2 if the unit has built-in termination. Attach a multimeter to analog output channel 0. Use SYSCHECK or other software to set analog output channel 0 to -10.000 V.
  • Page 63 Index stopping conversions analog input high-speed analog input triggering 1-3, 1-4 paced rate generator 3-11 test termination analog output digital I/O 1-3, 1-8 test test 3-10 auto zero mode digital I/O port 1 direction dimensions UDAS pcb dimensions of UDAS unit 1-10 bias resistors drivers...
  • Page 64 Index starting conversions, high-speed analog input mode LabView 5.0 support library status LED library stopping conversions LabVIEW Support switch S1 U-Link software for Windows 98 switch settings Visual Designer Support SYSCHECK library, software support analog input test load limitations 1-11 examples of I/O tests low-level drivers, verifying 3-13...
  • Page 65 initial connection models serial number UDAS-1001E-1 UDAS-1001E-1G UDAS-1001E-2 UDAS-1001E-2G UDAS-1001E-3 UDAS-1001E-4 U-Link software libraries for Windows 98 unit info, serial number Universal Serial Bus (USB) USB cable connections verifying USB port 3-13 Visual Designer application generator 1-11 support library UDAS support library 1-12 wizard, add new hardware Index-3...
