Large Blood Pressure Cuff

For all CVS or Microlife upper arm blood pressure monitors.
Thank you for purchasing a CVS accessory cuff. This cuff is suitable for arm cir-
cumferences of 12" to 16". The cuff is easy to adapt to all units.
For automatic monitors simply remove the existing
cuff from the monitor and plug the large cuff
into the monitor. (Skip to section A)

For semi-automatic (manual inflation) monitors

follow these steps:
1. Remove the T connector from the unit.
2. Detach the hose that leads to the cuff.
3. Remove the connector on the end of the new cuff.
4. Attach replacement cuff's hose to the T connector
Then connect the T connector to the monitor.
A - Once the cuff is properly connected to the
monitor, prepare the cuff for your measurement.
1. Thread cuff end through metal loop and slide cuff
onto left arm. The cuff is properly placed when the
bottom edge is just above the elbow crease, and the
"artery mark" is directly over the brachial artery
2. Fasten the Velcro just tight enough so you can slide
two fingers under the cuff.
3. Sit comfortably and rest arm at heart level with
palm up.
Be sure to consult the instruction booklet included with your monitor for
Questions? Call the Customer Help Line Toll Free at 1-866-464-6184.
CVSCUFF-L-M04-2
correct use of your blood pressure monitor.
