Summary of Contents for Wintal RFMX3
- Page 1 MINI UHF TRIPLE INPUT MODULATOR MODEL: RFMX3 OWNER’S MANUAL (PLEASE READ BEFORE USE)
-
Page 2: Important Safety Precautions
CHAPTER TABLE OF CONTENTS PAGE 1. Important-Safety Precautions • To avoid electrical shock, do not take apart this device. • This device should use only the power supply included with it or provided as Important-Safety Precautions……………………………………..2 an accessory. • Do not overload wall outlets and extension cords as this can result in the risk The Modulation System……………………………………………3-5 of fire or electrical shock. - Page 3 2. The Modulation System 2-2 Control Elements, Modulator 2-1 Packaging and accessories Fig1 One modulator One power adapter (9VDC/300mA) Three RCA plug to RCA plug video cables Three 3.5mm stereo plug to 2RCA plug audio cables One owner’s manual in English...
-
Page 4: Installation Of System
1. Plug in the DC power plug to the power input socket of the device. 2. Turn on the power switch, and then the power LED indicator will light. 3-2 Output select and channel select 1. Press MOD key to select A/V input (A, B or C) and the corresponding A/V input LED indicator will light. -
Page 5: Troubleshooting
3.5mm stereo plug to 2RCA plug audio cable. For A/V input B/C connection, follow the same procedure above. NOTE: Three pieces of audio cables are included in RFMX3 for audio connection, three pieces of video cables for video connection. 5. Trouble shooting... - Page 6 No image or sound Make sure the power switch is in the “ON” position. Check the right connection of all the connectors and plugs. Make sure the modulation and TV are on the same channel. Interruptions in image and sound Make sure the modulation and TV are using the free channel.
