  • Page 1 ® Microsoft Broadband Networking 5-Port Switch | MN-150...
  • Page 2 Microsoft may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document. Except as expressly provided in any written license agreement from Microsoft, the furnishing of this document does not give you any license to these patents, trademarks, copyrights, or other intellectual property.

  • Page 3: Table Of Contents

    contents. Introduction ..................1 Do You Have Everything You Need to Install Your Switch? ....2 Your Switch and Its Connections ............2 About Ethernet Connections ..............5 Straight-Through and Crossover Cables .......... 5 Connecting to Broadband Modems ..........5 Planning ....................

  • Page 5: Introduction

    Introducing the Broadband Networking 5-Port Switch ® Congratulations on your purchase of the Microsoft Broadband Networking 5-Port Switch. The switch can be used in a number of different ways. It will let you expand your existing Ethernet network by connecting additional computers, printers, scanners, and other Ethernet devices.

  • Page 6: Do You Have Everything You Need To Install Your Switch

    (Front View) The switch’s front panel contains one power light and 15 additional status-indicator lights that help you monitor and troubleshoot network connectivity and activity. Each vertical line of three lights 2 Microsoft Broadband Networking 5-Port Switch User’s Guide...
  • Page 7 corresponds to one of the five ports on the back of the switch. The lights for each port will be on, off, or blinking, depending on the current network configuration and activity for that port. The Power light is to the left of the port indicator lights. The following table describes the meaning of each light.
  • Page 8 Use Ethernet cables to connect your adapter to devices on your network. Any Ethernet-compatible network device will have one or more high-powered Ethernet ports. Some examples of network devices are: Routers, gateways, or base stations, such as the Microsoft Broadband Networking Wired Base Station Broadband modems Computers with Ethernet adapters...

  • Page 9: About Ethernet Connections

    Straight-Through and Crossover Cables Data is sent and received through specific wires within an Ethernet cable. Depending on the arrangement of its sending and receiving wires, an Ethernet cable is either a “straight-through” type or a “crossover” type. The following diagram demonstrates how to differentiate between the two types.

  • Page 11: Planning

    Planning Your Network ® Your Microsoft Broadband Networking 5-Port Switch can be configured in several ways. This chapter will help you locate setup instructions for your network configuration. Each computer to be connected to the network must have an installed network adapter with an available Ethernet port, and an Ethernet cable.
  • Page 12 Option A, make sure that all computers are behind a firewall or that your broadband modem uses Network Address Translation (NAT) technology to hide your computers from unauthorized access over the Internet. 8 Microsoft Broadband Networking 5-Port Switch User’s Guide...

  • Page 13: I Want To Share Files Or Printers Between Two Or More Computers That Are Not Connected To The Internet

    Option B: I want to share files or printers between two or more computers that are not connected to the Internet. Your 5-port switch can be used to connect two or more computers in a local area network (LAN) that does not have Internet access. By using this setup option, you can connect up to five computers and share files and printers among them.

  • Page 14: My Broadband Modem Has A Firewall, And I Want To Use The Switch To Add More Computers To My Network

    Many routers or gateways, such as the Microsoft Broadband Networking Base Station, provide firewall protection and could be used between the switch and the broadband modem to provide a higher level of security. 10 Microsoft Broadband Networking 5-Port Switch User’s Guide...

  • Page 15: My Computer Runs Firewall Software And Is Directly Connected To My Broadband Modem

    Option D: My computer runs firewall software and is directly connected to my broadband modem. This setup option allows you to add one or more computers to a network that already has a computer equipped with Network Address Translation (NAT) or firewall software. In this configuration, the existing networked computer must have an available Ethernet port for connecting the switch.
  • Page 16 You might also consider adding a Microsoft Broadband Networking Base Station to your network. A base station offers several advantages. It allows multiple computers to connect to the Internet through a secure connection. It uses Network Address Translation (NAT) software to hide your computer from unauthorized access outside your network.

  • Page 17: Setting Up

    Installing and Connecting Your 5-Port Switch This chapter will guide you through the process of connecting the ® Microsoft Broadband Networking 5-Port Switch. Your connection process might vary, depending on the setup option you selected in Chapter 2. Step 1: Choose a Location for Your Switch Use the following guidelines to choose a good position and location for your switch.

  • Page 18: Connect The Switch To A Power Outlet

    To learn more about protecting your network from viruses and hackers, see Chapter 4. If you have any problems connecting to or using your network, see the troubleshooting information in Chapter 5. 14 Microsoft Broadband Networking 5-Port Switch User’s Guide...

  • Page 19: Security

    security. Securing Your Network Protecting your data and programs from security threats, such as computer viruses and hackers, is very important. This chapter provides general information about steps you can take to protect your network. Protect Your Network from Computer Viruses A switch will not provide security for your network, because it simply passes data from one cable to another.

  • Page 20: Protect Your Network From Hackers

    Protect Your Network from Hackers ® If you have not already done so, consider purchasing the Microsoft Broadband Networking Wired Base Station to establish a security layer between your network computers and the Internet. The security mechanisms provided by the base station include a firewall and Network Address Translation (NAT).

  • Page 21: Troubleshooting

    If the problem you are experiencing is not covered in this chapter, how large a problem is. you can find more troubleshooting information on the Microsoft Broadband Networking Web site at http://www.microsoft.com/broadbandnetworking/. Setup and Hardware Problems This section will help you solve common setup and hardware- related problems with your switch.

  • Page 22: Network And Internet Problems

    If your computer can’t find your workgroup, it might be looking for the workgroup with the wrong name or you might be logged on to a domain. You cannot be logged on to a domain and a workgroup at the same time. 18 Microsoft Broadband Networking 5-Port Switch User’s Guide...

  • Page 23: File And Printer Sharing Problems

    My existing network used to work, but now it doesn’t. Check the existing network installation to verify that all cables are still attached and all link/activity lights on the other network devices read correctly. Verify that the network settings on all of the computers are correct.
  • Page 24 If one of your network cables is connected to a network port that does not have an illuminated link light, there might be a problem with the cable itself. Try using a different Ethernet cable to make the connection. 20 Microsoft Broadband Networking 5-Port Switch User’s Guide...
  • Page 25 My printer is connected directly to my network, and I cannot access the printer from the computers on my network. Check to make sure that the printer is turned on. Verify that all network cables between the computers and the printer are securely connected.

  • Page 27: Reference

    Toll-free support for U.S. customers: (800) 936-3900. For customers in Canada: (800) 668-7975. These numbers are only for support of Microsoft Broadband Networking products. Please do not use these phone numbers for support of other Microsoft products. TTY Users: Microsoft text telephone (TTY/TDD) services are available at (425) 635-4948 in Washington state or (800) 892-5234 elsewhere in the United States.

  • Page 28: Regulatory Information

    RF interference will not occur in a particular installation. Your Microsoft hardware device has been tested, and it complies with the limits for a Class B digital device in accordance with the specifications in Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful RF interference in a residential installation.
  • Page 29 In the event that the Hardware Device fails to comply with this Guarantee, Microsoft shall either, at Microsoft’s option, (a) repair or replace the Hardware Device or (b) return the price you paid for the Hardware Device (if any), provided that you return the Hardware Device to Microsoft with a copy of your receipt of purchase.

  • Page 30: Limited Warranty

    Dispositif matériel. GARANTIE MICROSOFT. Microsoft garantit (la « Garantie ») que pour une période de 2 ans à compter de la date de réception : (a) le Dispositif matériel sera, pour l’essentiel, exempt de vices matériels et de fabrication ; et (b) tout service d’assistance fourni par Microsoft sera, pour l’essentiel, conforme à...

  • Page 31: Technical Specifications

    1.2” x 5.3” x 3.7” (30.5 x 134.6 x 94 mm) Weight 6 oz (170.3g) without power adapter System Requirements To use the Microsoft Broadband Networking Ethernet 5-Port Switch: Computer with 10 Mbps Ethernet or 100 Mbps Fast Ethernet network adapter 120V AC power outlet Reference 27...

  • Page 33: Glossary

    A device (also known as a router or gateway) that acts as a central point for networked devices, receives transmitted messages, and forwards them. Microsoft Broadband Networking base stations can link many computers on a single network, and can share a secure Internet connection with wired and wireless devices.
  • Page 34 Acronym for “Dynamic Host Configuration Protocol.” A TCP/IP protocol that automatically assigns temporary IP addresses to computers on a local area network. Microsoft Broadband Networking base stations support the use of DHCP which, combined with ICS, allows you to share one Internet connection with multiple computers on a network.
  • Page 35 Acronym for “Internet Connection Sharing.” A software feature in Microsoft Windows that allows computers on a network to access online services through a single Internet connection. Microsoft Broadband Networking hardware replaces software ICS.
  • Page 36 IP addresses used within a private network and Internet IP addresses. NAT enables all of the computers on a network to share one IP address. The Microsoft Broadband Networking Base Station supports NAT, which provides an extra layer of network security by masking the actual IP addresses of the computers using a base station.
  • Page 37 Acronym for “Point-to-Point Protocol over Ethernet.” A specification for connecting users on an Ethernet network to the Internet by using a broadband connection (typically through a DSL modem). Microsoft Broadband Networking hardware supports PPPoE for connections that require it. protocol A set of rules that computers use to communicate with each other over a network.
  • Page 38 Acronym for “universal serial bus.” A hardware standard for easily connecting peripherals to a computer system. USB adapter A device that connects to a USB port; the Microsoft Broadband Networking Wireless USB Adapter is a type of USB adapter. USB connector The end of the USB cable that is plugged into a USB port.
  • Page 39 My Network Settings Use this page to record your network settings. Workgroup or domain name: Base station password (if applicable): Wide Area Network (WAN) Settings Complete this section only if your network has a base station (gateway or router). You can obtain this information from your Internet service provider (ISP).
