Description
The Wheelock BAT -(#) sealed lead acid batteries are leak-proof
and maintenance free. They are based on a unique efficient oxygen
recombination technology. Oxygen evolves from the positive plates
and diffuses through the microporous glass fibers to the negative
plates where it is changed back to water by recombination reaction.
This process eliminates the need for water replacement.
All battery models are designed per NFPA 72 (2002) Section
(6.9.4.5) for use with engine driven generators, local central station
or proprietary systems and auxiliary or remote station systems.
The (BACT-R) enclosure is constructed of steel and its' door hinges
fold downward for easy loading of the batteries. It also comes with
a lockable door that is keyed like the SAFEPATH® control panel.
Specification and Ordering Information
Model
Order
Number
Code
BATC-R
5414
BATC-B
5413
BAT-1212
7390
12 Volt, 12 Ampere Battery Cell Dimensions: 4"H x 6"W x 4"D
BAT-1224
7391
12 Volt, 24Ampere Battery Cell
BAT-1265
7392
12 Volt, 65 Ampere Battery Cell Dimensions: 7"H x 14"W x 7"D
NOTE: Care must be given when determining the size of the battery system. Larger applications might require more than
one battery cabinet.
Description
Battery Cabinet, Red
Battery Cabinet, Black
BAT-1212
Specifications
Dimensions: 9.5"H x 24"W x 9"D
Weight: 20lbs. (Empty)
Lock: Keyed like the SAFEPATH Control Panel
Dimensions: 9.5"H x 24"W x 9"D
Weight: 20lbs. (Empty)
Lock: Keyed like the SAFEPATH Control Panel
Dimensions: 5"H x 7"W x 7"D
Batteries and Battery Cabinet
BATC-R
Weight: 8lbs., 6oz.
Weight: 19lbs., 12oz.
Weight: 50lbs., 5oz.
Advertisement
Table of Contents
Summary of Contents for Cooper Wheelock Cooper BATC-R
- Page 1 BAT-1212 BATC-R Description The Wheelock BAT -(#) sealed lead acid batteries are leak-proof and maintenance free. They are based on a unique efficient oxygen recombination technology. Oxygen evolves from the positive plates and diffuses through the microporous glass fibers to the negative plates where it is changed back to water by recombination reaction.
- Page 2 Architects and Engineers Specifications The Battery Standby System shall consist of a Wheelock BATC-B/R (Battery Cabinet) and the appropriate battery cell size to accomplish the specified standby requirements of the system. The Battery Cabinet shall be available in red (BATC-R). It shall be constructed of steel and have a locking downward folding hinged door. The lock shall be keyed lock the SAFEPATH Control Panel.
