ENGLISH
Blow tube assembly (fig. A)
The blow tubes (1) must be assembled before use.
Align the square latches (6) on the side of the blow tubes
u
(1).
Push the blow tubes (1) firmly into each other until the
u
square latches (6) click into place.
Note! The blow tubes can be separated for storage by press-
ing in the square latches (6) on the side of the blow tube and
pulling them apart.
Mounting the blow tube (fig. B)
Align the square latches (6) on the side of the blow tube
u
(1) with the square latches (7) on the nozzle (8).
Push the blow tube (1) firmly onto the nozzle (8) until the
u
square latches (6 & 7) click into place.
Note! The blow tubes can be separated from the nozzle by
pressing in the square latches (7) on the side of the nozzle
and pulling them apart.
Fitting and removing the battery (fig. C)
To fit the battery (4), line it up with the receptacle on the
u
tool. Slide the battery into the receptacle and push until
the battery snaps into place.
To remove the battery, push the release button (9) while at
u
the same time pulling the battery out of the receptacle.
Use
Warning! Let the tool work at its own pace. Do not overload.
Charging the battery (fig. D)
The battery needs to be charged before first use and whenev-
er it fails to produce sufficient power on jobs that were easily
done before. The battery may become warm while charging;
this is normal and does not indicate a problem.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C. Recommended charging tem-
perature: approx. 24 °C.
Note: The charger will not charge a battery if the cell
temperature is below approximately 0 °C or above 40 °C.
The battery should be left in the charger and the charger
will begin to charge automatically when the cell tempera-
ture warms up or cools down.
To charge the battery (4), insert it into the charger (10).
u
The battery will only fit into the charger in one way. Do
not force. Be sure that the battery is fully seated in the
charger.
Plug in the charger and switch on at the mains.
u
The charging indicator (11) will flash green continuously
(slowly).
6
(Original instructions)
The charge is complete when the charging indicator (1) lights
green continuously. The charger and the battery can be left
connected indefinitely with the LED illuminated. The LED will
change to flashing green (charging) state as the charger occa-
sionally tops off the battery charge. The charging indicator (1)
will be lit as long as the battery is connected to the plugged-in
charger.
Charge discharged batteries within 1 week. Battery life will
u
be greatly diminished if stored in a discharged state.
Leaving the battery in the charger
The charger and battery pack can be left connected with the
LED glowing indefinitely. The charger will keep the battery
pack fresh and fully charged.
Charger diagnostics
If the charger detects a weak or damaged battery, the
charging indicator (1) will flash red at a fast rate. Proceed as
follows:
Re-insert the battery (4).
u
If the charging indicators continues flashing red at a fast
u
rate, use a different battery to determine if the charging
process works properly.
If the replaced battery charges correctly, the original
u
battery is defective and should be returned to a service
centre for recycling.
If the new battery gives the same indication as the original
u
battery, take the charger to be tested at an authorised
services centre.
Note: It may take as long as 60 minutes to determine that
the battery is defective. If the battery is too hot or too
cold, the LED will alternately blink red, fast and slow, one
flash at each speed and repeat.
Switching on and off (fig. E)
Warning! Use both hands to grip the product firmly when
switching on.
To switch the appliance on, slide the on/off switch (3)
u
forward.
To switch the appliance off, slide the on/off switch (3)
u
back.

Maintenance

Your Black & Decker appliance has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper appli-
ance care and regular cleaning.
Switch off and unplug the appliance/tool.
u
Or switch off and remove the battery from the appliance/
u
tool if the appliance/tool has a separate battery pack.
Or run the battery down completely if it is integral and then
u
