  • Page 1 A Higher Level of Precision… A Higher Level of Performance Intell-Print OM-192-S Dot Matrix Printer User Operation Manual...
  • Page 2 1. INTRODUCTION OM19X is a dot matrix impact printer that is available in 24 column, OM190, and 40 column, OM192, models. It is compact and reliable with a variety of features and options suitable for a wide array of applications including medical and industrial instruments, point of sale, test and measurement, security, time and attendance, etc.
  • Page 3: General Specifications

    2. SPECIFICATIONS 2-1. General specifications. Model OM190 OM192 Print method Shuttle impact dot matrix (8 pins) No. of columns Printing speed 2.5 lps 1.7 lps No. of dots per line Dot Size 0.33 (H) x 0.38 (W) mm Character size 1.7 (W) x 2.6 (H) 1.1 (W) x 2.6 (H) (mm)
  • Page 4: Setting Up The Printer

    Z: Designates input voltage for the external power adaptor Blank 110VAC Without adaptor 220 –240 VAC SMPS 90-240VAC 3. Setting up the printer 3-1. Unpacking. The items illustrated below are included with your printer. If any items are damaged or missing, please contact your dealer for assistance. Printer, Paper Roll, Power Supply, Ribbon (installed), Manual, and Interface Cable.
  • Page 5: Connecting The Power Adapter

    1. Protect your printer from excessive heat such as direct sunlight or heaters. 2. Avoid exposing the printer to excessive dust and humidity. 3. Place the printer on a firm, level surface free from intense vibration or shock. Connecting the Power Adapter This printer requires an external power supply.
  • Page 6: Installing The Ribbon Cartridge

    3. Use a screw driver to fasten the cable screws to the two nut screws installed on the printer connector. 4. Connect the other end, DB9-F connector, to your computer. 5. Use Omniprint part number: CBL-625F-25M (DB-25 male on the host side) CBL-69F-25M (DB-9 male on the host side) 3-4-2...
  • Page 7: Loading Paper

    Regular ERC-09- ( P for purple or B for black) Long Life ERC-22- ( P for purple or B for black) © Loading Paper Use a paper roll that meets the specifications. Do not use paper rolls that are glued to the core. Make sure data is not being transmitted to the printer while loading paper.
  • Page 8: External Appearance

    4. Hold the both edges of the paper and insert it straight into the paper slot. 5. Press the FEED button until approximately two inches of paper is fed through the mechanism. 6. Tear the excess paper against the serrated edge and close the cover. 7.
  • Page 9: Control Panel

    Interface connector DC Jack 5. Control Panel The control panel features four buttons and one LED to indicate printer status. ON BUTTON: Press the ON button to power up the printer. A red LED inside the button will light up. The printer goes ON LINE ready to receive data from the host.
  • Page 10: Running The Self Test

    6. Running the Self Test Any time you want to check the performance of your printer you can run the self test described below. This shows whether your printer is working correctly. 1. While holding down the FEED button, turn the printer on. 2.
  • Page 11 By turning the power on while pressing the SEL button the printer will print the current configuration and get in SET-UP mode. The power LED will flash every second to indicate the printer is in SET- UP mode. By pressing the FEED button, in SET-UP mode, you can scroll through the printer parameters in the order shown in the table below.
  • Page 12: Diagnostic Mode

    If the printer is turned on while pressing the SEL and FEED buttons, simultaneously, and only the SEL button is released, the printer will print : “nvr comms ready>” At this point the printer is waiting to receive data in the following format : SET- UP mode + Carriage Return +n1+…n10 (n1 to n10 are hex number) the SET-UP mode followed by a carriage return indicates that the printer should expect parameter data as shown in the table...
  • Page 13: Troubleshooting

    9. Accessories 1) Paper: 57.5mm+/-0.5mm(width) , 60mm max(roll diameter) , 85 microns (thickness) PP-225-80 1-ply paper roll PP-225-75WC 2-ply paper roll 2) Ribbon specification : ERC-09 P (Purple) or B (Black) Standard cartridge ERC-22 P (Purple) or B (Black) Long Life Cartridge 3) Interface Cable: 6 foot long, shielded cable with molded connectors.
  • Page 14: Interface Connections

    PRINTED Make sure a ribbon cartridge is installed properly that is not worn out. Please note that the ribbon needs to be in front of the paper. If the printout is faint, turn the knob on the cartridge in the direction of the arrow. Also, see if the knob turns when the FEED button is pushed, if it does not, then the advance gear on the ribbon or the mechanism may be defective or worn out.
  • Page 15: Parallel Interface

    Input Control (DTR signal) : Mark: Data transmission not possible Space: Data transmission possible 11-1-2 Connector Pin Assignment FUNCTION PIN NUMBER INPUT-OUTPUT 7,9,14 *POWER 12,13,16 5,6,8,10,11,15,17-19,21- F-GND * Please note that some models can be set at the factory to receive power through the serial port.
  • Page 16: Command Codes

    FUNCTION FUNCTION STROBE N.C. DATA 0 N.C. DATA 1 N.C. DATA 2 N.C. DATA 3 N.C. DATA 4 DATA 5 DATA 6 DATA 7 BUSY N.C. N.C. Printer is capable of receiving data from the host while the BUSY signal is in the LOW state and communication will be interrupted when the signal is HIGH>...
  • Page 17: Command Descriptions

    REVERSE PRINT CTRL Y DOUBLE HEIGHT CTRL Z GRAPHICS CTRL [,n 1BH, n 27,n 12.2 COMMAND SUMMARY FOR EPSON ESC/POS EMULATION FUNCTION KEYSTROKE DECIMAL HORIZONTAL TAB CTRL I LINE FEED CTRL J FORM FEED CTRL L CARRIAGE RETURN CTRL M SET PRINT MODE ESC ! n 1BH,21H,n...
  • Page 18 CR(0DH) : This command prints the data in the print buffer and feeds one line. If a LF is sent immediately after CR, it will be ignored to avoid double printing. When the line buffer is full, ie upon receiving the 24 and 40 characters in the case of OM190 and OM192, respectively, the printer will automatically print the data in the buffer.
  • Page 19 CR(0DH) : This command prints the data in the print buffer and feeds one line. If a LF is sent immediately after CR, it will be ignored to avoid double printing. ESC ! n(1BH,21H,n) : Sets the print mode according to the following table. n is a single byte in which each bit sets the printing function.
  • Page 20: Appendix 1. International Characters Set

    11.2.3 COMMAND DESCRIPTION FOR CBM560 EMULATION LINE FEED (0AH) : Prints the data in the print buffer and feeds one line. FORM FEED(0CH) : Form feeds after printing. This is fixed at three lines. CR(0DH) : Feeds a new line after printing. REVERSE PRINT(14H) : This command causes the printer to print white on black.
  • Page 21: Appendix 2. Printable Character Set

    APPENDIX 2. PRINTABLE CHARACTER SET...
  • Page 22: Appendix 3. External Dimensions

    APPENDIX 3. EXTERNAL DIMENSIONS...
