Instruction Manual
DMP3 + DMP4
Further languages are available under www.minox.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMP3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Minox DMP3

  • Page 1 Instruction Manual DMP3 + DMP4 Further languages are available under www.minox.com...
  • Page 2: Preface

    Duplication or modification of these publications is prohibited without specific written authorization. Usage MINOX GmbH, Wetzlar shall not be liable for any problems / damages which occur in connection with the use of this product / the recordings or playback. Privacy Do not use this product to shoot images that will infringe upon other people privacy or in places that prohibit the use of photographic equipment and materials.
  • Page 3 • We recommend that you store important data separately. Memory data may be lost or changed under certain circumstances. MINOX GmbH shall not be liable for data loss from the memory of the product, which is caused due to improper use, repairs, defects, rechargeable battery change, or any other reason.
  • Page 4: Table Of Contents

    as possible, should, however any information be erroneous or missing, please contact us immediately. Table of Contents Preface ..............1 Product Introduction .
  • Page 5: Product Introduction

    Product Introduction Power button Hold switch Mode button Menu button Vol + Vol – OK button Up button Down button Left button Right button Description Rechargeable battery Installation / Removal Using both hands hold the DMP with the back facing up. Now remove the battery slot cover by sliding it down with both thumbs.
  • Page 6: Battery Power

    Recharging the Rechargeable battery Charge the rechargeable battery for at least 4 hours prior to initial use. The rechargeable battery is charged automatically when you connect the product to your computer. Be sure to turn off the power of the DMP before charging. Plug the USB end of the connection cable into the USB socket of your computer and plug the mini USB end of the cable into the USB port of the DMP.
  • Page 7: Power Button

    Power Button Power On: Hold the power button in depressed position until the screen starts up and displays the Main Menu. Power Off: Hold the power button in depressed position for at least 2 seconds – the DMP then switches off. Caution! during the switch-off procedure the product will stop all actions and complete the data save before switching off completely.
  • Page 8 - A/V In - Memory - Setup Press the Mode button to return from the respective mode to this display Menu button Press to show the available menu items or options Vol+ Press and hold to increase the volume. Vol- Press and hold to reduce the volume.
  • Page 9: Media Browser

    Up button Press the Up button to move the selection upward. Down button Press the Down button to move the selection downward. Left button Press the Left button to rewind when playing movies. In the mode for Music, Movie and Photo, press this button to select the previous item again. Right button Press the Right button to forward wind when playing movies.
  • Page 10 Selecting files in Media Browser Press Up or Down button to change between different files/folders. Press the OK button to select the highlighted file/folder. If the file is a photo image, this will be displayed Switching back to Media Browser Press the Left or Right button to switch back to the Media Browser.
  • Page 11 Rewind when playing a movie Press the Left button once to activate the Rewind function and press it again to start the Fast Rewind. Press the Left button again to return to normal mode Preparation before playing the movie in the media player To ensure the MP4 file can be played properly, use the program MEDIA CONVERTER on the Driver CD to convert the source file before you play it in the media player Menu Settings...
  • Page 12 Copy to Internal Press Up or down Button to switch between the three folders of the internal flash memory: - Backup_1 - Backup_2 - Backup_3 Press the OK button to select the highlighted folder. 1. Do not remove the flash memory card during the copying process as otherwise it will cause the process to fail.
  • Page 13: Music

    Music Only files with extension : MP3 & WAV can be browsed. Music Format Support Both files in MP3 format or WAV files recorded by the player are supported Selecting music files in File Browser Press Up or Down button to switch between different files. Press the OK button to select and play the highlighted file Play/Stop Music Press the OK button once to play and press the button again to...
  • Page 14 Volume Up/Down Press the Vol+ button to increase the volume Press the Vol- button to decrease the volume Menu Settings Press the Menu button to open the Menu. There are 4 options in the Music Menu Select Directory Play Mode Delete One Exit Press Up or Down button to switch between different options.
  • Page 15 Play Mode There are 3 options in the Play Mode Menu - Single - All - Cycle Press Up or Down button to switch between different options. Press the OK button to select the highlighted option: Single: The current selection will play once only All: All music files in the current directory will play once Cycle: All music files in the current directory will play in loop function until the rechargeable battery is on low.
  • Page 16: Photo

    Photo Only files with the extension JPG can be displayed. Photo Format Support Only files in JPEG compressed data, baseline YUV 4:2:2 format get support Selecting files in File Browser Press Up or Down button to switch between different files. Press the OK button to select the highlighted file and show the selected photo.
  • Page 17 Menu Settings Press the Menu button to open the Menu. There are 4 options in the Photo Menu Select Directory Slide Show Delete One Exit Press Up or Down button to switch between different options. Press the OK button to select the highlighted option Select Directory Press Up or down Button to switch between different directories.
  • Page 18 Slide Show There are 3 options in the Slide Show Menu - Single - All - Cycle Press Up or down Button to switch between different options. Press the OK button to select the highlighted option: Single: The selected photo is displayed All: All Photo files in the current directory are shown one after the other Cycle : All photo files in the current directory are shown one after the other and loop continuously until the rechargeable battery is on low.
  • Page 19: Movie

    Movie Files with extension (AVI) can be displayed. Movie Format Support Files in AVI with Zoran MPEG 4 format supported Preparation before playing movie in the media player To ensure the MP4 file can be played properly use the Media Converter on the Driver CD to convert the source file before playing it in the media player Selecting movie files in File Browser...
  • Page 20 Playing the movie Press the OK button once to play and press it again to pause. Volume Up/Down Press the Vol+ button to increase the volume Press the Vol- button to decrease the volume Forward Wind when playing movie Press the Right button once to activate Forward Wind function and press it again to start Fast Forward.
  • Page 21 Press Up or Down button to switch between different options. Press the OK Button to select the highlighted option Select Directory Press Up or Down button to switch between different directories. Press the OK button to open the selected directory. To view the file list in the current directory select the item “Files”...
  • Page 22: Recorder

    Recorder You can record audio signals with the built-in or external microphone or with an other external device. The recording quality can be adjusted. If an external signal source is connected this is recognized and recorded by the recorder. If there is no external signal source connected the internal microphone will be used.
  • Page 23: Av-In

    AV-IN After connection of a suitable AV transmitter in the jack the received signal will be shown on the LCD panel. You can adjust the desired recording quality for audio and video. Recording a movie Press the OK button once to start the recording and press it again to stop.
  • Page 24 Selecting Video Quality There are 5 options in the Video Menu Best Fine Normal Basic Economic Press Up or Down button to switch between the different options. Press the OK button to select the highlighted option. TV Format There are 2 options in the Video Menu NTSC Press Up or Down button to switch between different options.
  • Page 25: Memory

    Memory Shows the total memory and the memory used. Without SD Card in the player it shows the internal memory. When SD Card is inserted only the SD memory will be shown. Setup There are 5 options in the Setup Menu Format TV Format Auto Off...
  • Page 26 Format With the Format function you can delete (format) the memory. Press Up or Down button to switch between Yes and No. Press the OK button to select the highlighted option TV Format There are 2 options in the Video Menu NTSC Press Up or Down button to switch between different options.
  • Page 27: Usb Mass Storage

    Default With the reset“ function your can reset all settings of the product to the status on delivery. Press the Up or Down button to switch between Yes and No. Press the OK button to selected the highlighted option Language The media player supports the following languages: English French...
  • Page 28: Charging The Rechargeable Battery

    Interface Mini USB, Video Out, Ear Phone Jack, Speaker, Microphone In, Video out TV Out (NTSC / PAL) Internal memory 128MB (DMP3) 2 GB (DMP4) Storage Media SD/MMC Card (32 MB up to 4 GB) Image Format JPEG (baseline YUV 4:2:2)
  • Page 29 Voice Recording AV-In Recording AVI (MPEG4) MP3 Playing Power Specification Battery Li-Ion rechargeable battery (BLB-2 1000 mAh) Product Dimension Weight(g) approx. 2.43 oz (without battery) Length 90 mm Width 70 mm Height 162 mm System Requierments: Microsoft Windows ME/200/XP Intel Pentium III, 450 MHz or higher 256 MB RAM (recommended) USB 1.1 port (USB 2.0 recommended) 200 MB free hard disc space...
  • Page 30: Troubleshooting

    Note: The Media Conversion Programm does not support Mac OS Troubleshooting You can troubleshoot the following problems that may occur while using this product: Cannot switch on the product. Make sure that the rechargeable battery is fully charged and inserted properly. Cannot use the inserted SD/MMC card.
  • Page 31: Rechargeable Battery Information

    What can I do if the system freezes during use? Improper operation may cause the operating system to freeze. If you cannot restart or shut down, open the battery slot cover, remove the rechargeable battery and then re-insert the rechargeable battery.
  • Page 32 Design subject to alterations without notice. MINOX is a registered trademark of MINOX GmbH, Wetzlar. MINOX GmbH Walter-Zapp-Str. 4 D-35578 Wetzlar, Germany Tel.: +49 (0)6441/917-0 Fax: +49 (0)6441/917-612 e-mail: info@minox.com www.minox.com...
