Summary of Contents for Jensen NVX200 - Touch&Go - Automotive GPS Receiver
-
Page 1: User Manual
User Manual GPS navigation software for Audiovox NVX200 English Owners manual :128-8219 R : 00... - Page 2 Copyright note Audiovox Electronics Corp. 150 Marcus Blvd., Hauppauge, NY 11788 Call center: 800 290 6650 The product and the information contained herein may be changed at any time without prior notification. This manual or any parts of it may not be reproduced, transmitted in any form either electronically or mechanically (including photocopying) without the express written consent of Audiovox Electronics Corp.
- Page 3 Thank you for choosing the NVX200 Navigator as your door-to-door in-car navigator. The memory card version is very easy to use. Read the Quick Start Guide first and start using The NVX200 Navigator right away. This document is the detailed description of the software.
-
Page 4: Table Of Contents
Table of contents Warnings and safety information ...........8 General information ............... 10 Operating The NVX200 Navigator (Controls).......12 Hardware buttons..................12 Screen buttons and controls..............15 3.2.1 Direct selectors ................... 15 3.2.2 List selectors ..................16 3.2.3 Sliders ....................16 3.2.4 Switches.................... - Page 5 4.4.10.4 Inactive legs of the route .............. 29 4.4.10.5 Roads in the route excluded by your preferences......29 Screens with map..................30 4.5.1 Turn preview (No. 1) ................31 4.5.2 Zoom in and out (No. 2 & 3) ..............31 4.5.3 Tilt up and down (No.
- Page 6 Settings ................... 56 General settings ..................56 5.1.1 Safety Mode ..................56 5.1.2 Set Favorite Destinations ..............57 5.1.3 Automatic Night Colors ............... 57 5.1.4 Warn When Speeding ................. 57 5.1.4.1 Speeding tolerance ..............58 5.1.4.2 Alternative speed limit ..............58 5.1.4.3 Alternative speeding tolerance.............
- Page 7 5.6.1.5 Cockpit layout ................68 5.6.2 Backlight settings ................68 5.6.2.1 Power management ..............68 5.6.2.2 Brightness ..................69 5.6.3 Smart Zoom ..................69 5.6.3.1 Smart Zoom settings ..............69 5.6.3.2 Enable Overview mode ..............69 5.6.3.3 Restore Lock-to-Position and Smart Zoom ........70 5.6.4 Route options ..................
-
Page 8: Warnings And Safety Information
Warnings and safety information The NVX200 Navigator is a navigation system that helps you find your way to your selected destination. It will determine your exact location with the help of an attached GPS device. The position information obtained from the GPS receiver will not be transmitted anywhere, so others will not be able to track you. -
Page 10: General Information
General information To Enter a Destination address Skip to Page 76 of this Owners manual for detailed instruction The NVX200 Navigator is a navigation system optimized for in-car use. It provides door-to-door navigation for both single and multi-point routes using adaptable route parameters. -
Page 12: Operating The Nvx200 Navigator (Controls)
Operating The NVX200 Navigator (Controls) The NVX200 Navigator is designed for easy operation. All controls are operable by fingertips, or Stylus. Wherever possible, pushbuttons and lists are provided to make accessing functions or changing settings as easy as possible. 3.1 Hardware buttons Hardware buttons are mostly used on map screens to zoom, tilt and rotate the map, or to open other screens. - Page 13 VIEWS Back View 3.Stylus Take the pen out of its compartment in order to use it, and replace it after use. The pointer pen is required for operating the touch screen. 4.Loudspeaker Plays back language statements and warnings. 5. Reset button Press it to reset the unit.
- Page 14 VIEWS Top / Bottom View 7.Sleep/Wake up Button Press and hold Sleep/Wake up button for about two seconds to Wake up the unit. 8. USB Interface Interface for connecting to a PC by means of the ActiveSync Cable (for data matching). Left / Right View 9.SD/MMC Slot Accepts an optional SD (Secure Digital) or MMC (Multi Media Card) Card for removable storage.
-
Page 15: Screen Buttons And Controls
GPS(Global Positioning System) GPS is a satellite-backed system for determining your position. With the help of 24 satellites revolving around the earth, it is possible to determine your position on earth with the accuracy of a few meters. The satellite signals are received by the antenna of the built-in GPS receiver, which must have a “line of sight”... -
Page 16: List Selectors
3.2.2 List selectors When the values in the list need to be named, only the current value is shown (sometimes together with a short description) in a horizontal stripe with arrows at both ends. The arrows are buttons. Tap to move left in the list or tap to move right. -
Page 17: Special Switches
3.2.5 Special switches Some switches behave differently. Instead of being dark when not selected, the light turns red and the lamp becomes crossed out ( ) to emphasize the prohibition of use. Furthermore the switches used for the road types (to be included or avoided when planning a route) in the Route Parameters screen (5.4.4) cannot be changed for some vehicle types. -
Page 18: Abc-Type Keyboards
3.2.7.1 ABC-type keyboards These keyboards contain only letters (Latin, Hebraic, Greek or Cyrillic). If you wish to enter numbers, you need to tap the Keys ( ) button to switch to the numeric keyboard. Use Backspace ( ) to delete the last letter you have entered if you have made a mistake, tap Space ( ) to enter more words, and hit Done ( ) to finish entering... -
Page 19: The Numeric Keyboard
3.2.7.3 The numeric keyboard The numeric keyboard only contains numbers, on huge buttons. The special keys you find on the other keyboards (except Space) are available here as well. Although QWERTY-type keyboards also contain number keys, when entering a house number, the program offers the more convenient numeric keypad. -
Page 20: Discovering The Program Through The Screens
Discovering the program through the screens The best way to discover The NVX200 Navigator is to explore each screen in detail, and to find out how to move from one to another. Read this chapter for a guided tour. The NVX200 Navigator starts by displaying the Main menu. This is the root of the screen hierarchy, but you only need to return here in a few cases. -
Page 21: About Screen
** Same as removing the SD card 4.2 About screen Tap About on the Main menu screen to open this screen. The About screen is not used in no It is here to inform you about the map licenses you have, the creators of The NVX200 Navigator and the legal aspects of using the program. -
Page 22: Gps Connection Indicator
Additional pieces of information on this screen are: current position in latitude/longitude format, elevation, speed, date, time and calculated accuracy. Note: Accuracy can be affected by several factors the GPS cannot take into account. Use this accuracy information only as estimation. There are two icons on the left to show the status of the GPS connection and the quality of reception. -
Page 23: Time Synchronization
• - Green means 3D reception. The GPS receiver has enough satellites to calculate altitude. Position is generally correct (yet it can still be inaccurate due to different environmental factors). The NVX200 Navigator is ready for navigation. 4.3.4 Time synchronization In the top right corner of the screen you have another button that leads to a new screen where you can synchronize the clock of your PND to the very accurate time provided by the connected GPS. -
Page 24: And 3D Map Views
Navigator provides much more than regular paper maps can. The look and the contents can be changed. 4.4.1 2D and 3D map views Besides the classical top down view of the map (called 2D mode), you have the possibility to tilt the map to have a perspective view (3D mode) that gives a view similar to that seen through the windscreen with the possibility to see far ahead. -
Page 25: Daylight And Night Color Schemes
the optimal view in your current situation. When approaching a turn, it will zoom in and raise the view angle to let you easily recognize your maneuver at the next junction. If the next turn is at a distance, it will zoom out and lower the view angle to flat in order to let you see the road in front of you. -
Page 26: Streets And Roads
4.4.4 Streets and roads The similarity of The NVX200 Navigator to paper roadmaps is also convenient when it comes to streets, the most important elements of the map concerning navigation. The NVX200 Navigator uses similar color codes to those you are accustomed to, and the width of the streets also refers to their importance, so it will not be difficult to tell a highway from a small street. -
Page 27: Selected Map Point, Also Known As The Cursor
The arrow is sized and vertically rotated with the zoom and tilt levels to always look realistic. The NVX200 Navigator has a built-in Lock-on-Road feature that always puts the position arrow on the road, on the axis of the street in case of one-way streets, or on the side of the road where you drive (e.g. -
Page 28: Visible Pois (Points Of Interest)
The NVX200 Navigator automatically selects the color of the pin. Different colors help you identify a pin in the History list (6.3.2) later. There they are shown together with their address and GPS coordinates. Tip: A quick way to tell the coordinates of a location you found on the map is to pin it, and then look for the coordinates in the History list (6.3.2). -
Page 29: Elements Of The Active Route
4.4.10 Elements of the Active Route The NVX200 Navigator uses a multi-destination routing system in which you have a start point (your current location if GPS position is available), a destination, the line of the active leg of the route, and optionally via points and inactive legs. They are all shown on the map. -
Page 30: Screens With Map
4.5 Screens with map Having explained the contents of the map, the description of the other parts of the map screens follows. There is two map screens: the Map screen and the Cockpit screen. The way they show the map is the same but their look and controls are optimized for different purposes. -
Page 31: Turn Preview (No. 1)
(Cockpit only) Turn preview* Opens Route menu* Zooms in (optional) Zooms out (optional) Tilts down (optional) Tilts up (optional) Indicates that Lock to GPS position and Re-enables Lock-to-Position / Smart Zoom heading is inactive Selected map point (Cursor) Opens Popup Info and Cursor menu (Map only) Map scale Zooms in/out by dragging Menu (Find, Quick, Route, Main) -
Page 32: Tilt Up And Down (No. 4 & 5)
As already described in Error! Reference source not found., zoom will change the scale of the map. Zoom out shows a larger part of the map, while Zoom in shows a smaller part of the map in more detail. The automatic Smart Zoom function will do the necessary zooming for you when navigating (zooms out if the next turn is at a distance to let you see far ahead and zooms in when approaching a turn to give you a better view of the upcoming maneuver). -
Page 33: Cursor (No. 7)
Normally The NVX200 Navigator positions the map to keep the GPS position visible somewhere on the map (when North-up orientation is selected), or always at the bottom centre of the map (when Track-up orientation is selected). If you manually move the map, it will freeze the map in the new position. To return to the GPS position, use this Lock button. -
Page 34: Menu (No. 9)
4.5.7 Menu (No. 9) This button opens the Menu with the Find engine, the Quick menu, the Route menu and the exit button that takes you to the Main menu screen. The Menu will be described in detail later in 4.7. 4.5.8 Map orientation and Overview (No. -
Page 35: Gps Position Quality (No. 11)
4.5.9 GPS position quality (No. 11) Similarly to the icon found on the GPS Data screen (4.3.3), the map screens also inform you about the GPS signal. They can show the same four values: • The black satellite dish with the red exclamation mark shows there is no connection with the GPS receiver. -
Page 36: Track Log Recording/Playback Indicator (No. 14)
Tap again to re-enable sounds. Note: Sound can be muted in Sound settings (5.3), too. There you have a Master switch that works together with the switch described above. There is also a Master slider on that screen. That you can use to fully turn down the volume of the device. Setting the volume low is different from muting;... - Page 37 Tip: If you want to see the map around the Cursor, close the Cursor menu and reopen it. When this menu is opened manually, the map is always moved to have the cursor in the centre. The content of the Cursor menu depends on the screen (Map or Cockpit) and it is slightly different if there is an active route already planned.
-
Page 38: Current Street (No. 16)
• Add POI: opens the new POI capture window to let you add the selected map point to the list of your user points. This menu point is only available on the Map screen and if there are no POIs near the cursor (i.e. only the address is shown in the Popup Info window). -
Page 39: Distance To Next Turn (No. 18)
4.5.16 Distance to next turn (No. 18) This field shows the distance to go before reaching the next route event (turn, roundabout, exit, etc.) This field is only displayed when navigating a route. 4.5.17 Next street / Next settlement (No. 19) This field shows the road or street that comes next in the route itinerary. -
Page 40: Route Data Displayed (For Destination And Via Points)
4.6.1 Route data displayed (for destination and via points) In the top section of the screen you see information about the current route. These fields are continuously updated while you keep this screen open. When you open the screen, all fields contain information on reaching your final destination. -
Page 41: Time Left
4.6.1.4 Time Left This is an estimated value that can also be displayed in one of the Route data fields on the Cockpit screen as ‘Time to destination’. It shows the time needed to reach the final destination of the route based on information available for the remaining segments of the route. -
Page 42: Fit To Screen
• - This icon shows that toll roads are included in the recommended route. • - This icon shows that you need to board a ferry along the recommended route. • - This icon shows that you need to pay for the ferry. •... -
Page 43: Parameters
4.6.4 Parameters This button opens the Route parameter settings screen (5.4) otherwise opened from the Route menu (4.7.3). 4.7 Menu The Menu button can be found in the top right corner of the portrait and square map screens and in the bottom left corner of the landscape map screens. Tapping this button brings up a menu that allows you to access some of the most frequently used functions of The NVX200 Navigator. -
Page 44: Zoom & Tilt
Note: When you reach 2D view by tilting the map, Smart Zoom will tilt the map as you press the Lock button or it disappears after the timeout (set in Advanced settings) expires. Use the 3D Map toggle to permanently switch to 2D view. 4.7.2.2 Zoom &... - Page 45 If you highlight any of the POI groups by tapping them, the button in the bottom left corner will become Show if the POI group is hidden, or Hide if the group is shown or partly shown. Tip: To make a partly shown group fully shown, tap this button twice. First you will hide the whole group, and then you will have it displayed with all its subgroups.
- Page 46 • Show/Hide: similarly to built-in POIs, you have the possibility to show or hide all POIs of the selected category on the map. Groups with a blue icon are displayed; groups with a grey icon are hidden. • New: you can create a new My POI group by tapping this button. You need to select an icon, a name, and the maximum zoom level at which the POI is still visible on the map (provided you let the POI group be displayed at all).
-
Page 47: Popup Info
• Delete: you can delete any of your previously saved POIs. The NVX200 Navigator will ask you to confirm this action. • Edit: you can edit the attributes (name, icon and group) of a previously created POI. • OK: if you tap this button, the map screen returns with the selected POI in the middle. - Page 48 Each track log has a color, shown to the left of its name when the track log is visible on the map. If the track is not visible, an underscore character is shown here. Tapping the line of the highlighted track log will toggle between showing and hiding that log.
- Page 49 • Replay: push this button to see a simulation of the saved track log on the map. A green icon (4.5.12) will appear on the map screens to let you know it is not a fly over but a simulation based on a real saved log. •...
-
Page 50: Route Tab
4.7.3 Route tab This menu contains options to manage different settings in the program. 4.7.3.1 Recalculate This menu point is only available if an active route exists and GPS position is present. It brings up a menu with four options. Using one of these functions you can modify the current route. -
Page 51: Delete
no via points left (only the destination), the name of this button turns to Delete Route, and it cancels the navigation. Bypass When you run into a traffic jam or roadblock, you may want to have The NVX200 Navigator calculate a route that departs the original route as soon as it can. You will need to select the minimum distance along the original route where your new route is allowed to rejoin the original route. -
Page 52: Itinerary
4.7.3.3 Itinerary This function opens the itinerary (route event list) of the active route. The Itinerary has three different display modes and two functions. Display modes Display modes are different only in the number of events displayed in the list. List items are always shown with all information available including pictograms of the needed action and distance of the event from the previous list item. -
Page 53: Fly Over
• Road: when you exclude a road, The NVX200 Navigator will calculate a route that does not use that road. It is useful when you anticipate a traffic jam in a street used in your route, or a roadblock is announced on the radio, and you find that road in your Itinerary. -
Page 54: Info
Use the arrows on the right to browse through the list and tap any line to highlight it. You can perform the following operations: • Add: you can add a new route point (or a new final destination if the highlighted item is the last one in the list) after the selected point. -
Page 56: Settings
Settings The NVX200 Navigator provides several settings in order to let you customize the functions of the program. The Settings screen can be accessed directly from the Main menu screen (4.1) and from the map screens by using the battery icon (4.5.10), while some of its sub-screens are accessible from other parts of the program. -
Page 57: Set Favorite Destinations
5.1.2 Set Favorite Destinations You can select two of your most frequent destinations to be your favorites (6.3.5). You can start navigating to either of them by only two taps on the screen. The original names of these points are Home and Work. You can rename them and specify their locations. -
Page 58: Speeding Tolerance
You can set two different kinds of behavior for the warning: one is applied up to a certain speed limit and the other one is used above that. 5.1.4.1 Speeding tolerance The NVX200 Navigator will warn you when you exceed the speed limit by the amount specified here. -
Page 59: Off-Route Recalculation
5.1.5 Off-route Recalculation Once a route is planned, this setting will tell The NVX200 Navigator what to do when you deviate from that route. 5.1.5.1 Automatic The route will be recalculated automatically a few seconds after you go astray. 5.1.5.2 Ask First The NVX200 Navigator can also ask your preference each time you leave the planned route. -
Page 60: Map Settings
5.2 Map settings You can set a few parameters determining the appearance of the maps in The NVX200 Navigator. 5.2.1 Daylight / Night color profile The NVX200 Navigator comes with different color schemes for both daylight and night use. There is always one selected daytime scheme and one selected nighttime scheme. -
Page 61: Textured Polygons
Note: You can only disable street names and POI icons if The NVX200 Navigator follows your position. As soon as you move the map and Lock-to-Position (4.5.4) is disabled, street names and icons become visible again. Press Enter or tap Lock to re-enable Lock-to-Position and have the labels and icons disappear again. -
Page 62: Key Sound Volume/Switch
5.3.3 Key sound volume/switch The switch on the left can turn the key sounds on or off. Key sounds are audible confirmations of either pressing hardware buttons or tapping the touch screen. When key sounds are turned on, the slider on the right will adjust their loudness. In its leftmost position the key sounds are suppressed, in its rightmost position they are played at the master volume level. -
Page 63: Route Parameter Settings
5.4 Route parameter settings This is a very important page. Settings here determine how routes will be calculated. This screen is directly accessible from the Route Information screen (4.6). 5.4.1 Method Use the handle to set the speed of the route calculation. In the leftmost position the route may not be optimal but the calculation will be very fast. -
Page 64: Vehicle
5.4.3 Vehicle You can set the type of the vehicle that you will use to navigate the route. Based upon this setting, some of the road types will be excluded from the route (e.g. motorways for pedestrians), or some of the restrictions may not be taken into account (e.g. -
Page 65: U-Turns
5.4.4.4 U-turns Although displayed amongst road types, this is a type of action. Most drivers prefer to replace them with a few normal left and/or right turns in the next few junctions, so it is disabled by default. Turning back on dual carriageways is not considered as a u-turn. Note: If you are not totally against u-turns, leave them on here, and add a certain penalty (equivalent extra distance to travel) in Advanced settings Route options (5.6.4.2). -
Page 66: Program Language
5.5.1 Program language This button displays the current written language of the program. By tapping the button you can select from a list of available languages. The NVX200 Navigator will have to be restarted if you change this setting. The NVX200 Navigator will ask for confirmation before it restarts. -
Page 67: Display Options
Tap on any button to set the corresponding parameters. They all open new windows where you can make your desired changes. 5.6.1 Display options These settings determine how The NVX200 Navigator displays different content elements or how it presents the screens. 5.6.1.1 2D in Map mode (and north-up orientation) The normal use of the Map mode is to browse the map and look for different places... -
Page 68: Zoom In After Find
5.6.1.3 Zoom in after find When this switch is turned off, The NVX200 Navigator will centre the map to the location selected in Find but will not change the zoom level. If you turn this switch on, The NVX200 Navigator will also zoom in to the selected point. The zoom level in this case depends on the type of object you have searched for. -
Page 69: Brightness
Smart power save You can also initiate this special feature of The NVX200 Navigator. Smart Power save will light up the screen only when you press or tap a button, or if The NVX200 Navigator has something to show you. After a few seconds the light level decreases, and after another few seconds the backlight turns off. -
Page 70: Restore Lock-To-Position And Smart Zoom
The Route event distance will determine when The NVX200 Navigator switches to the Overview or back to the Navigation view. The Overview zoom level will determine the fixed zoom level of the map in both automatic and manually selected (by the Map orientation icon – see in 4.5.8) Overview modes. -
Page 71: Route Options
changed the view accidentally, or you modified it to quickly check something near your route. After a certain timeout set below, the Lock button disappears, then Smart Zoom changes the view back for navigation. Unlike with Restore Lock-to-Position, the view changes smoothly. -
Page 72: U-Turn Penalty
position to the recommended route and the road network of the map, sometimes the errors are too large to correct. To reduce the effect of large errors, you can increase the recalculation tolerance two ways. Off-route sensitivity This is a range of relative values from 0 to 10, telling The NVX200 Navigator how far the GPS position should be from the recommended route before the program decides to recalculate. -
Page 73: User Data Management
5.6.5 User data management Everything that was saved (pins, My POIs, Favorites, track logs etc.) or modified (Settings, History lists) since The NVX200 Navigator was installed is stored in a user database located in the RAM of the PND device. Here you have options to save, restore or reset the database or parts of it. -
Page 74: Clear Data
5.6.5.4 Clear Data This button will delete all user data. It is a reset to factory settings. Tapping this button means you lose all your saved data and customized settings. The NVX200 Navigator will warn you about this. 5.6.5.5 Reset Advanced Settings There are a multitude of advanced settings in The NVX200 Navigator. -
Page 76: Find
Find One of the most frequently used functions of The NVX200 Navigator is selecting the destination. Once you have the destination, you can start navigating. Getting to this point should be as fast as possible. The NVX200 Navigator provides you with a versatile search engine designed to find your chosen destination after only a few taps on the screen. -
Page 77: Using The Find Menu
Tip: If you want the selected point shown in the centre of the map, close and reopen the menu or wait until it closes and open it again. By opening the Cursor menu manually, the map will be moved to have the selected location in the centre. 6.3 Using the Find menu The Find menu is accessible by the Find &... -
Page 78: Selecting The City, State And Country To Search In
6.3.1.1 Selecting the city, state and country to search in The first screen of the address-search module is the list of recently used cities (and states in Australia). The first line of the list is always the city you are in or near to. Should the settlement you are looking for appear on the list, just tap it and you will immediately jump to the Street Name Input screen with the selected city name or postcode shown at the top of the screen. - Page 79 combination of those. You can search for multiple partial words by inserting space characters in the pattern. For example Key West in Florida will be found if you enter ‘Ke W’ or even ‘We K’ (any word order will do). You do not need to enter accents when searching for a destination.
-
Page 80: Selecting A Street Or The Centre Of The Settlement
Once you have selected the city, you can continue by entering the street name. Changing the state (Australia, USA, etc.) Some of the maps contain state information. If the settlement you are looking for is in a different state, tap Other City then Change State from the list of recently used cities, then select the appropriate state. -
Page 81: Selecting A House Number Or The Midpoint Of The Street
Selecting the centre of the settlement If you wish to navigate to the settlement displayed in the top centre of the screen, just tap done before entering any letters. The search result will be the centre point of the city (where its name is displayed on the map). Note: This point is not the geometrical centre but an arbitrarily selected point chosen by the creators of the map, usually the most important intersection in case of a small town or village, and for larger cities an important intersection in the city centre. -
Page 82: How To Select An Intersection Instead Of A House Number
Enter the number, tap done, and The NVX200 Navigator will show you the selected location on the map (or will start navigating immediately if you have selected Find & GO at the Main menu). Note: House numbers may not be available on the map of your region. Ask your local dealer for details. -
Page 83: Find Coordinates
Just pick any of the recent locations as your destination. Here you have no possibility to reorder the list or filter it by name, but the Next and Previous buttons let you browse through the complete list to find your preferred point. Tip: If you will need a location later but you do not want to save it as POI, just mark it with a pin, and remember its color to find it easily in the History list. -
Page 84: Find A Poi
Once you have entered both numbers, press done to make the selection. Tip: The quickest way to tell the coordinates of a point is to select it by tapping on the map or by using Find, and then come to this page and read the coordinates. Tip: If you need to reformat coordinates to the format selected in The NVX200 Navigator at 5.6.1.4, enter the coordinates in the format you have, press done to show it in the map, then come back here to see the same location in the chosen... - Page 85 • GPS Position: the search will be carried out around the current location given by the GPS if it is available. If no GPS position is available, the last known GPS position (grey arrow on the map) will be used. •...
-
Page 86: Find One Of The Favorites (Home/Work)
Tapping OK will return to the map with the selected POI in the centre (or starts navigating to it if Find & GO was selected). Tapping the arrow in the top left corner returns to the search results. Tip: If you want to find the nearest POIs, or if you are close to one of them but do not know exactly where it is or what its name is, tap the All button on the very first screen of POI search, and get a list of the nearest POIs.
