Page 1: User Manual
Aolynk S1505L Smart Ethernet Switch User Manual Manual Version： T2-UM-20070710-3.05 Huawei Technologies Proprietary... - Page 2 No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
- Page 3 This equipment complies with the following European Directives: 89/336/EEC (electromagnetic compatibility), 73/23/EEC (low voltage). Huawei Technologies Proprietary...
-
Page 4: About This Manual
This document is organized as follows: Chapter Content This chapter describes the appearance 1 Product Overview and features of the Aolynk S1505L Smart Ethernet Switch. This chapter describes the precautions and 2 Installation steps to install the Aolynk S1505L Smart Ethernet Switch. - Page 5 Chapter Content Appendix – This chapter describes the technical Technical specifications of the Aolynk S1505L Smart Specifications Ethernet Switch. Conventions The manual uses the following conventions: GUI conventions Convention Description Button names are inside angle brackets. < > For example, click <OK>.
-
Page 6: Table Of Contents
User Manual Aolynk S1505L Smart Ethernet Switch Table of Contents Table of Contents Chapter 1 Product Overview ............1-1 1.1 Appearance................1-1 1.2 Features ................1-3 Chapter 2 Installation ..............2-1 2.1 Precautions ................2-1 2.2 Hardware Installation ............2-2 2.3 USB Driver Installation ............2-2 Chapter 3 Configuration..............3-1 3.1 Login ..................3-1... -
Page 7: Chapter 1 Product Overview
Aolynk S1505L Smart Ethernet Switch Chapter 1 Product Overview Chapter 1 Product Overview Aolynk S1505L Smart Ethernet Switch (hereinafter referred to as the S1505L) is oriented to small and medium-sized enterprise users and SOHO users for IPTV application. It provides five autosensing... - Page 8 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 1 Product Overview Table 1-1 LED description Label State Description Green The S1505L is powered on. Power Power The S1505L is powered off. Green The port is operating at 100 Mbps. Speed...
-
Page 9: Features
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 1 Product Overview 1.2 Features Table 1-2 Feature description Feature Description IEEE 802.1Q-compliant VLAN VLAN (virtual local area Port-based VLAN network) 16 VLANs at most Broadcast storm control Port Flow control, compliant with 802.3x... -
Page 10: Chapter 2 Installation
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 2 Installation Chapter 2 Installation 2.1 Precautions Before cleaning the S1505L, pull out its power adapter. Do not clean the S1505L with wet cloth or liquid. Do not place the S1505L near water or in a damp area. And prevent water or moisture from entering the S1505L chassis. -
Page 11: Hardware Installation
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 2 Installation 2.2 Hardware Installation Connect the cable As shown in Figure 2-1, you can use the console cable to connect a PC to the S1505L. This cable takes an RJ-45 connector at one end and a USB connector at the other end. - Page 12 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 2 Installation After you plug the USB connector, the [Found New Hardware Wizard] dialog box (see Figure 2-2) pops up, prompting you that a new hardware is found. Figure 2-2 Found New Hardware Wizard dialog box...
- Page 13 User Manual Aolynk S1505L Smart Ethernet Switch Chapter Installation Figure 2-3 Select the locations for searching the driver Insert the driver CD-ROM into the drive of your PC. Select the Search removable media [floppy, CD-ROM…] check box and click <Next>.
- Page 14 User Manual Aolynk S1505L Smart Ethernet Switch Chapter Installation Figure 2-4 Complete the installation Click <Finish> to complete the installation.
-
Page 15: Chapter 3 Configuration
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration Chapter 3 Configuration You can use the configuration program in the CD-ROM accompanying the S1505L to configure and manage the S1505L. After the hardware connection and USB driver installation, you can run the configuration program on the PC and make a connection to the S1505L for further operation. -
Page 16: Main Configuration Window
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration Note: The default user name Admin is unchangeable, but you can change the password after logging into the configuration page. Refer to section 3.5 “Changing Password” for details. 3.2 Main Configuration Window Figure 3-2 Main configuration window (in disconnected status) After you log into the S1505L configuration page, click <Connect>... - Page 17 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration on the page and the exact port is displayed in the [COM Port] field (see Figure 3-3). Figure 3-3 Main configuration window (in connected status) I. Quick setup section The quick setup section allows you to set the S1505L quickly. In this section, you can set the speed, priority, rate limit, flow control, and VLAN for each port.
- Page 18 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration selected, the switch automatically negotiates an operating speed and duplex mode with the peer port. Priority: Four options are available from the drop-down list: Highest, High, Low and Lowest. You cannot configure the priority for the Uplink port.
- Page 19 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration connected to the S1505L to make a connection with the S1505L. <Show Configuration>: Click this button to display the current configuration of the S1505L. <Save Configuration>: Click this button to save your configuration to the S1505L.
- Page 20 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration only need to configure one and choose [File/Save Configuration] to save the configuration to a file. Then you can just choose [File/Open Configuration] to open the saved configuration file and click <Save Configuration> on the main configuration window to configure other S1505Ls.
-
Page 21: Quick Setup
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration [Language]: [Language] allows you to shift between English and Chinese. Figure 3-6 Language menu items [Help]: [About] provides you with the version and copyright information about the S1505L configuration program. -
Page 22: Advanced Settings
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration Click <Save Configuration> to save the configuration to the S1505L. The switch automatically restarts and the configuration takes effect. Note: VLAN 1 is the default VLAN including all the ports. - Page 23 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration Figure 3-8 General tab page Broadcast Storm: Limit the broadcast traffic on the port. When the broadcast traffic exceeds the customer-defined value, the system drops the broadcast packets to reduce the broadcast ratio to a reasonable value.
- Page 24 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration VLAN Type: Two options are available, 802.1Q-based VLAN (default) and Port-based VLAN. IGMP Snooping: A multicast control mechanism running on Layer 2 switch. It is used for multicast group management and control.
- Page 25 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration precedence. By default, the mapping is as follows: 0 and 1 are mapped to the lowest queue, 2 and 3 to low, 4 and 5 to high, 6 and 7 to highest.
- Page 26 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration weights of the four priority queues are in the ratio of 1:2:4:8. The weight of the lowest queue is 1, which cannot be changed, and weights of other queues ranges from 1 to 15.
- Page 27 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration packets with VLAN ID of 100 arriving at port 2. By default, ingress filter is enabled. PVID: Used to display and configure the PVID of each port. By default, the PVIDs displayed here are the same as the VLAN IDs on the main configuration window.
- Page 28 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration type on the [General] tab page before configuring the VLANs. By default, this type is 802.1Q-based VLAN. 802.1Q-based VLAN Section 3.3 “Quick Setup” describes how to create an 802.1Q-based VLAN: Type in the VLAN ID in the corresponding VLAN text box of a port on the quick setup section of the main configuration window.
- Page 29 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration Create a VLAN To create a VLAN, click <New> on the [VLAN] tab page (see Figure 3-12) to enter the [VLAN Member Settings] dialog box (see Figure 3-13). Figure 3-13 Create a VLAN Type in a VLAN ID in the corresponding text box.
- Page 30 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration To edit an existing VLAN, click <Edit> on the [VLAN] tab page (see Figure 3-12) to enter the [VLAN Member Settings] dialog box (see Figure 3-14). Figure 3-14 Edit a VLAN...
- Page 31 User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration Caution: VLAN 1 is the default VLAN, which includes all the ports and cannot be deleted. Port-based VLAN You can create port-based VLAN as needed. First you need to set the VLAN type to port-based VLAN in Figure 3-8. Then choose [Advanced/Advanced Settings] and select the [VLAN] tab to enter the corresponding dialog box (see Figure 3-15).
-
Page 32: Changing Password
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration By default, VLAN 1 includes all the ports. You can only create a VLAN that includes port 1 and port 5. Click <New> and you may begin your creation. If you need to remove or add some ports in the VLAN, click <Edit>. -
Page 33: About
User Manual Aolynk S1505L Smart Ethernet Switch Chapter 3 Configuration Figure 3-16 Change Password dialog box Caution: The password is from 4 to 12 characters in length (case sensitive) and cannot be left blank. 3.6 About Choose [Help/About] to view the version and copyright information about the S1505L configuration program. -
Page 34: Specifications
User Manual Chapter 4 Appendix – Technical Aolynk S1505L Smart Ethernet Switch Specifications Chapter 4 Appendix – Technical Specifications Table 4-1 Technical specifications Item Description Five autosensing 10/100Base-TX Ethernet Ports ports RJ-45 connector Compliant with IEEE 802.3, IEEE 802.3u, and IEEE 802.3x... -
Page 35: Chapter 4 Appendix - Technical Specifications
User Manual Chapter 4 Appendix – Technical Aolynk S1505L Smart Ethernet Switch Specifications Item Description Power 4.5 W consumption Operating 0°C to 40°C (32°F to 104°F) temperature Storage –10°C to +70°C (14°F to 158°F) temperature Operating humidity 20% to 85%...
