American DJ PDP-800 User Instructions

American DJ
Caution!
Always disconnect from main
power before replacing lamps or servicing unit.
Remember to always replace with same lamps
and fuses.
Model: PDP-800™
SPECIFICATIONS:
Protection: 20A breaker
Power: 110V/60Hz
Weight: 7 lbs.
Size: 19" x 6.75" x 1.75"
19 in. single space rack mount.
user
®
PDP-800™
American DJ
® LOS ANGELES, CA. 90058
Instructions
Thank you for purchasing this American
DJ® product. For your convenience this
products ready to be used, there is no
assembly required. Please read the follow-
ing instructions before installing or using
your new unit.
Operating Instructions:
The American DJ® PDP-800™ Power
Distribution Panel features include: The PDP-
800™ features 7 protected switched A/C
grounded outlets on the rear of the unit, & 1
A/C unswitched outlet on the rear of the unit,
1 A/C outlet switched on the front panel, 15
amps per outlet/20A protection breaker but-
ton on the front panel, master on/off switch,
and dual pop-out lights with dim control
knob; great for lighting up DJ control booths.
The PDP-800™ eliminates wires in mobile
racks, control booths, or studios. For night
club, studios, and mobile DJ's where power
distribution is a concern. Single space 19"
rack amount.
NOTICE: When pop-up lights are not in use
make sure dim control knob is all the way off.
For service, contact your American DJ
.
dealer
®
