Furman Q-Series Equalizer EQ-2151 Specification Sheet

All Q-Series Equalizers Feature:
•
Constant Q circuitry
•
XLR and 1/4" balanced inputs/
outputs and unbalanced RCA
inputs/outputs
•
Bypass switch
•
Selectable boost and cut range of
6dB or 12 dB
•
Switchable input AC voltage
•
Road-worthy steel construction
•
Three year limited warranty
Additional Features:
Q-1311
Single Channel 31 Band Graphic EQ
•
Short throw sliders
•
High and low cut filters
Q-1312V
Single Channel 31 Band Graphic EQ withVU Meter
•
Long throw sliders
•
VU output meter
•
High and low cut filters
Q-2151
Dual Channel 15 Band Graphic EQ
•
Short throw sliders
Q-2152V
Dual Channel 15 Band Graphic EQ withVU Meter
•
Long throw sliders
•
VU output meters
Q-2312
Dual Channel 31 Band Graphic EQ
•
Short throw sliders
•
High and low cut filters
F u r m a n S o u n d , I n c . l
P h o n e : 7 0 7 . 7 6 3 . 1 0 1 0
The Q-Series
Furman offers fi ve different equalizers to best suit your needs: from a
single-rack-space mono 31 band, to a stereo 15 band with 60 mm long
throw sliders and VU metering in a two rack space.
The new Furman Q-Series EQ's are designed for use by live sound
engineers, recording studios, and musicians. These units feature constant Q
circuitry with 4% center frequency accuracy. Each is equipped with 1⁄4" TRS
and XLR balanced inputs/outputs, and RCA unbalanced inputs/outputs for
the fl exibility to interface with a variety of systems.
Switchable to a +/-6 range for more control and better dynamics, they feature
+/-6 and +/-12 range LED indicators. Each channel bypass switch has a red
LED indicator to compare the equalized sound to the original sound, and
each channel is outfi tted with a clip LED for overload detection. A shielded
internal power supply provides for low noise operation. Selectable AC input
voltage between 120 VAC 50/60HZ and 240 VAC 50/60 HZ allows for use in
almost any location. Durable all steel construction makes these units perfect
for life on the road.
The Furman Q-Series is protected by a three-year limited warranty covering
defects in materials and workmanship.

SPECIFICATIONS

Frequency Response
THD
Input Impedance
Maximum Input Level
Output Impedance
Maximum Output Level
Common Mode Rejection
Signal to Noise Ratio
Low Pass Filter
High Filter
Dimensions
Q-2151, Q-1311
Q-2152V, Q-1312V, Q-2312
1 9 9 7 S . M c D o w e l l B l v d . l
F a x : 7 0 7 . 7 6 3 . 1 3 1 0
l
20HZ to 20KHZ +/-0.5 dB
.01% @ +4 dBu
Balanced 20K ohms, Unbalanced 15K ohms
+20 dBu
Balanced <150 ohms, Unbalanced <100 ohms
+22 dBu
>75 dB @ 60HZ
94 dB (20KHz Noise Bandwidth)
10Hz - 250Hz, 12dB/Octave
3KHz - 40KHz, 12dB/Octave
1.75"(H) x 19"(W) x 8.5"(D)
3.50"(H) x 19"(W) x 8.5"(D)
P e t a l u m a , C A 9 4 9 5 4 - 6 9 1 9
w w w. f u r m a n s o u n d . c o m
