T E C H N O L O G I E S
4-Pin Floppy
Power Port
Mode Jumper JP4
(Close or Open)
Drive Activity LED
4 slots - CF, SD, MMC, MiniSD, SM,
xD, MS, MS Duo and MS Pro Duo
Standard 40-Pin IDE Interface for Mounting
Directly onto Motherboard IDE Channel
Mode Jumper (JP4):
Note: Only applies on SATA connection
The internal SATA / USB DigiDrive supports Type I, II CF Cards, CF Micro drive, SD, SDHC, miniSD
(with adapter), Trans flash, SD HS (Secure Digital High Speed), MMC Cards (4-bit and 8-bit modes),
RS-MMC, MMC-Micro, MMC Plus, Smart Media, xD picture card- both H and M types, Memory
stick, Memory stick PRO, MS Extreme III Type media, MS PRO, HS (4-bit mode).
Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: 408-453-6212
Email: http://www.addonics.com/support/query/
User Guide
Internal IDE/SATA/USB
DigiDrive (AEDMDISU2)
4-Pin Floppy Power Connector
SATA 1.5Gbs
Data Port
Pin 1
USB 5-Pin Header
SATA Port 2 (Slave)
SATA Port 1 (Master)
v7.1.11
Advertisement
Table of Contents
Related Manuals for Addonics Technologies AEDMDISU2
Summary of Contents for Addonics Technologies AEDMDISU2
-
Page 1: User Guide
User Guide Internal IDE/SATA/USB T E C H N O L O G I E S DigiDrive (AEDMDISU2) 4-Pin Floppy Power Port SATA 1.5Gbs Mode Jumper JP4 Data Port (Close or Open) Pin 1 USB 5-Pin Header Drive Activity LED... - Page 2 Setting up the device in SATA mode Connect a 4-pin floppy power cable from PC to the internal SATA / USB DigiDrive. Attach SATA cable from internal SATA / USB DigiDrive to the PC SATA port. The tables show drive icon and media detection behavior basing on the mode switch setting and the type of SATA port the internal SATA / USB DigiDrive is connected to.
