Addonics Technologies ADUSB2PCI Installation Manual

Features
Easy Installation
·
Compliant with USB2.0 data transfer
·
rate up to 480Mbps
Fully forward and backward compatible
·
to USB1.1
Improves peripheral performance for:
·
Printers, Scanners, and External hard
drives.
5 USB 2.0 ports (3 external and 2
·
internal)
Requires one free PCI slot
·
1 year warranty
·
Hardware Installation Guide
Discharge any static electricity build up by
touching a grounded metal object (such as
the exposed metal parts on the back of your
computer) before handling the Host
Adapter.
WARNING: Turn OFF power to the
computer and disconnect the power cord.
1. After you turn OFF your computer and
unplug the power cord, open the
computer cabinet.
2. Note: See your computer
documentation for specific Instructions
on opening your computer cabinet.
3. Locate an unused 32­bit or 64­bit PCI
expansion slot and Remove the
expansion slot cover. Save the cover
screw for use in Step 4.
4. Insert the Combo Host Adapter into the
PCI expansion slot. Press down firmly
until the card clicks into place.
5. Note: Some PCI slots may need
considerable force to insert the card
completely.
6. Replace the slot cover screw. When
installed properly, the card should be
level with the expansion slot.
7. Close the computer cabinet and reattach
the power cord.
Addonics Technologies, Inc.
Model: ADUSB2PCI – USB 2.0 Host Adapter
Additional Features
Add five USB 2.0 ports to Desktop PC
·
via one PCI slot
Support both USB 2.0 and USB 1.1
·
peripheral devices
Connect up to 127 devices
·
Great for any USB External Storage
·
Devices and USB peripheral devices
such as scanner, printer, camera.
BUS (direct) power for all Addonics
·
USB series of Pocket devices
Software Installation Guide
Windows 98SE, Me, 2000, XP (USB2.0)
1. Windows detects the controller's
presence and displays a "
hardware"
.
New Hardware Wizard
2. When the "
NEXT
appears, Click on
3. Select the appropriate driver folder for
the specific OS of the computer.
4. Follow the wizard to complete the
installation. Reboot if prompted.
TECHNICAL SUPPORT
Addonics Technologies
2466 Kruse Drive
San Jose CA, 95131
Fax: 408­433­3898
Phone: 408­433­3855
Email: Techinfo@addonics.com
Technical Support (8:30 am to 5:30 am PST)
Specifications subject to change without notice.
Found New
"
to Continue.
