DPT SmartRaidV Century Ultra2 SCSI RAID Controller PM2654U2-R Features List

V
SMART RAID
®
Ultra2 SCSI RAID Controlle r
1 Intel® i960® RD processor for peak performance
2
Expansion Modules add 1 or 2 additional Ultra2 SCSI
channels or 1 Fibre Channel Arbitrated Loop
PCI 132MB/s data transfers, 32-bit, 33MHz
3
Internal and external 68-pin SCSI connectors
4
Includes high-speed RAID data path engine,
5
hardware XOR and ECC processor
6 Support for up to 64MB of hardware cache
4
Features:
• Fully I O® compliant
2
• Controls SCSI-1, SCSI-2 or SCSI-3 devices
• Controls Wide or Narrow Ultra2, Ultra or Fast SCSI
devices with up to 80MB/s transfer rate
• Controls up to 15 SCSI devices per channel
• Up to 12 meter SCSI cable length
• Integrated hardware RAID 0, 1, 5, 0+1 and 0+5
• 4 SIMM sockets support up to 64MB of hardware cache
(DPT ECC EDO or industry standard EDO SIMMs)
• Expansion Modules add 1 or 2 additional Ultra2 SCSI
channels or 1 Fibre Channel Arbitrated Loop
• PCI 2.1 compliant with 132MB/s bus mastering
Century
4
2
1
3
PM2654U2-R
Available with one, two or three
5
6
• Intel i960 RD processor for ultra-low host CPU utilization
• SCSI SCRIPTS ® processor for maximum SCSI performance
• Very high-density SCSI connector allows 3 external
SCSI channels from one slot
• Flash-upgradable firmware and BIOS
• Supports SAF-TE, SES and DEC Fault Bus for intelligent
storage cabinets
• Dynamic Array Expansion permits drives to be added
on-the-fly to existing arrays
• Easy-to-use GUI Storage Management Software
• BIOS-based SCSI and RAID configuration utility
Ultra2 SCSI Channels
