CT6600øµ Æmenual 89.6.16 11:12 AM
‰¿Ã¡ˆ1
USER°Ø
S GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Daewoo CT6600

Summary of Contents for Daewoo CT6600

  • Page 1 CT6600øµ Æmenual 89.6.16 11:12 AM ‰¿Ã¡ˆ1 USER°Ø S GUIDE...
  • Page 2 CT6600øµ Æmenual 89.6.16 11:12 AM ‰¿Ã¡ˆ2 CT6600 CONTENTS DAEWOO CT6600 USER° S GUIDE CONTENTS...

  • Page 3: Table Of Contents

    CT6600øµ Æmenual 89.6.16 11:12 AM ‰¿Ã¡ˆ3 Contents CONTENTS Starting How to use this manual / Check Items / System Setting 1. System Configuration front Cpnfiguration / Rear Cpnfiguration 2. Srart to Install Plugging keyboard and mouse / Plugging the Monitor Plugging the power cord / Plugging the RJ11 Phon line 3.

  • Page 4: Starting

    Starting This manual is for anyone who wants to setup and configure the PC. It will help you to use CT6600 computer easily. Please read this guide carefully before you install the system ¡ For your safety, remember to turn off the system and to disconnect all the cords and cables before opening the system chassis.
  • Page 5 CT6600øµ Æmenual 89.6.16 11:12 AM ‰¿Ã¡ˆ5 Starting Starting Your packing box includes CT6600, keyboard, mouse and power cord. Check all the items form your box S y s t e m K e y b o a r d M a n u a l...
  • Page 6 CT6600øµ Æmenual 89.6.16 11:12 AM ‰¿Ã¡ˆ6 CT6600 USER°Ø S GUIDE Operate the PC on a sturdy level surface such as desk or table Please do not overload the Keep the computer away from power socket high temperature and direct s u n l i g h t...

  • Page 7: System Configuration

    CT6600øµ Æmenual 89.6.16 11:12 AM ‰¿Ã¡ˆ7 System Configuration 1. System Configuration MIDI/GAME port Power LED Headphone MIC in HDD LED Power Button Floppy Disk Drive FDD Eject button CD-Rom Drive LED CD-Rom Drive eject button CD-Rom Drive USB Port Keyboard...

  • Page 8: Srart To Install

    CT6600øµ Æmenual 89.6.16 11:12 AM ‰¿Ã¡ˆ8 CT6600 USER°Ø S GUIDE 2. Start to Install PS/2 Mouse PS/2 Keyboard Keyboard and mouse connector is on the rear panel Connect the keyboard cable to the keyboard connector colored blue Connect the mouse cable to the mouse connector colored gre e n...
  • Page 9 DIGITAL MONITOR OUT connector colored white. Voltage Selection Switch Power Cord CT6600 Computer System applies both 110/220Vpower range with voltage selecting switch. B e f o re plug the power cord to your PC and connect the cord into the g rounded outlet, you should select voltage 100 or 220 first.

  • Page 10: System Disassemble & Upgrading

    Connect phone jack and telephone line of the PCs you want to network with RJ11 telephone line 3. System disassemble & upgrading CT6600 provides many convenient options that gives you more system flexibility. This chapter describes how to install optional part inside the computer and remove and replace the computer cover and expansion-card c a g e .
  • Page 11 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ11 System disassemble & upgrading board, to avoid possible damage to the system board. 4. Touch an unpainted metal surface on the computer chassis, such as the power supply, before touching anything inside your computer.
  • Page 12 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ12 CT6600 USER°Ø S GUIDE This section is to describe that upgrading memory and Installing the PCI option card. Upgrading Memory This model has 64 Mbytes memory as a default and you can upgrade max 256 Mbytes when you need.
  • Page 13 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ13 System disassemble & upgrading How to remove 1 . Locate the two clips that hold the memory module in place. One clip holds the left edge of the module and the other clip holds the right edge.
  • Page 14 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ14 CT6600 USER°Ø S GUIDE PCI Slot Option PCI CARD Phone Tel Line(to the wall) ° The Add-On Cards should be properly inserted in the slot. If the card is not properly inserted,then it could cause the system failure...

  • Page 15: Mother Board

    CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ15 Mother board 4. Mother board Item Specification Model Name CB660F-WH Single Celeron Processor 400/433/466/500/533 MHz (370-pin PGA connector) Front Side Bus 66/100 MHz Main Memory -Supports a maximum memory size of 512MB -Supports two 168-pin DIMM Socket...
  • Page 16 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ16 CT6600 USER°Ø S GUIDE JP11 JP10 GMCH DAEWOO CT6600...
  • Page 17 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ17 Mother board Several hardware settings are made through the of jumper caps to connect jumper pins(JP) on the motherboard. Refer to motherboard layout on following page. The jumper settings will be described numerically such as °1 - 2° , °2 - 3°f o r connect pins 1&2, connect pins 2&3 respectively, or °O N ( S h o r t )°...
  • Page 18 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ18 CT6600 USER°Ø S GUIDE JP7, JP8: Support ACPI S3 mode(STR)-option REMARK All OPEN 1-2, 3-4, 5-6, 7-8 Entering up to S3 Non-STR 1-2, 3-4, 5-6 All OPEN Entering up to S1 JP10: AUDIO Setting...

  • Page 19: Bios Setup

    CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ19 BIOS Setup 5. BIOS Setup The SETUP program is a built-in program that allows configuration of functions and devices of the system. This chapter provides information on how the setup program allows you to c o n f i g u re the function and device of your computer and how to configure each items on the setup menus.
  • Page 20 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ20 CT6600 USER°Ø S GUIDE 1. During boot-up sequence, press<F2> to display the SETUP menu. 2. Press <ESC> to go to the °E x i t° m e n u . 3. On the °Load Setup Deafaults° option, Press <Enter> and select <Ye s > .
  • Page 21 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ21 BIOS Setup Use this menu for basic system configuration. You can make the following selections on the Main Menu itself. ¡ System Time This option displays the current system time. Use <+> and <->keys to change the values.
  • Page 22 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ22 CT6600 USER°Ø S GUIDE § Keyboard auto-repeat rate : Sets the number of times a second to repeat a ™ k e y s t roke when you hold the key down. § Keyboard auto-repeat delay : Set the delay time after the key is held down ™...
  • Page 23 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ23 BIOS Setup Use this menu to set the Advanced Features available on your system’s chipset. Selecting °A d v a n c e d°f rom the Menu Bar displays the Advanced Menu, Which looks like this :...
  • Page 24 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ24 CT6600 USER°Ø S GUIDE ¡ Processor Serial Number C o n t rols detection of processor Serial Number. (Note:this option woul show only if there is Pentium ¥² processor in your system.) ¡ Installed O/S...
  • Page 25 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ25 BIOS Setup ¡ Local Bus IDE adqpter Enable or Disable the integrated local bus IDE adapter. Specifies an option from below. § Disabled : Disabled the Local Bus IDE adapter. ™ § Primary:Use only the primary Local Bus IDE.
  • Page 26 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ26 CT6600 USER°Ø S GUIDE § ™ Video BIOS This option is selectable between °Degault VB° and °Updated VB° . Once it has both video BIOS in the system,you can select which video BIOS will be used by the internal graphic device. This option is automatically BIOS will be used by the internal graphic device.
  • Page 27 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ27 BIOS Setup d. Skip loading the video BIOS patch Once the system has a video BIOS patch loaded and enabled, it° s possible during the POST, to skip the updated patch and load the defaul one instead.

  • Page 28: Set Supervisor Password

    CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ28 CT6600 USER°Ø S GUIDE Use this menu to set User and Supervisor Password and Backup and Vi r u s check re m i n d e r. Selecting °S e c u r i t y°f rom the Menu Bar displays the Security menu, which...
  • Page 29 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ29 BIOS Setup To clear the current password, just hit <Enter> on New Password and c o n f i rm Password.(Maximum 5 characters can be used for a password.) ¡ Password on boot D e t e rmines whether the password will be asked for in every boot(Enabled), or when entering in to the SETUP pro g r a m ( D i s a l d e d ) .
  • Page 30 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ30 CT6600 USER°Ø S GUIDE § ™ Hot-Key: It allows you to power on the system by the Hot-key. (Ctrl+F1/Ctrl+f2/Ctrl+f3/Ctrl+F4) § ™ Password: It allows you to power on the system by the password that you entered.
  • Page 31 CT6600øµ Æmenual 89.6.16 11:13 AM ‰¿Ã¡ˆ31 BIOS Setup Support 4sec Power override. § Disabled: Use Power Button as Soft-off Button. ™ ¡ Power Savings Specify Power Savings option as following: § Maximum Power Saving:Conserves the greatest amount of system ™...
  • Page 32 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ32 CT6600 USER°Ø S GUIDE Use this menu to specify any drive as a boot drive. Selecting “Boot” from the Menu Bar displays the Boot menu, which looks like this: Phoenix BIOS Setup Utility Main...

  • Page 33: Hard Drive

    CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ33 BIOS Setup ¡ Hard Drive If you have more than one hard drive, select “Hard Drive” from the B o o t M e n u . Select the hard drive to use for booting by using the up-and-down arro w s .

  • Page 34: Exit Saving Changes

    CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ34 CT6600 USER°Ø S GUIDE Exits the current menu. Selecting “Exit” from the Menu Bar displays the Exit menu, which looks like t h i s : Phoenix BIOS Setup Utility Main Advanced Security Power...

  • Page 35: Driver Insrallation

    CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ35 Driver Installation 6. Driver Installation The Inf files for Intel(R) 810 chipests contain Windows device installation files(*.inf) that outline to the operating system how the chipset components shall be configure d for proper functioality of the following feature ;...
  • Page 36 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ36 CT6600 USER°Ø S GUIDE Click the °y e s° b u t t o n . ¡ Click the °n e x t° b u t t o n . ¡ Click the °n e x t°button, then Inf files will be copied to c:\pro g r a m ¡...
  • Page 37 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ37 Driver Installation 2) Installing the Inf Update utility Run °Setup. exe° file in °I n f i n s t° d i rectory. (That is d:\infinst\setup.exe) ¡ Click °n e x t° button, then you will be prompted to agree to the license ¡...
  • Page 38 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ38 CT6600 USER°Ø S GUIDE Click °f i n i s h° button then system will re s t a r t . ¡ Run the ¡S e t u p . e x e¡ file in ¡w i n 9 x¡ d i re c t o r y .
  • Page 39 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ39 Driver Installation Click ¡y e s¡ b u t t o n . ¡ Click next butto, then the vga drivers will copied will copied c:\pro g r a m ¡ files\intel\GfxDrvEUD dire t o r y .
  • Page 40 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ40 CT6600 USER°Ø S GUIDE ° Click °s t a r t° button, select settings, and select control panel. ¡ Double click °S y s t e m°icon, and select the Driver Manager tab. Then ¡...
  • Page 41 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ41 Driver Installation Click °n e x t° b u t t o n . ¡ Check the °Specify a location° box, and type the location. ¡ (If you use Win98SE or Win2000, type d:\audio\win98se_2k.
  • Page 42 CT6600øµ Æmenual 89.6.16 11:14 AM ‰¿Ã¡ˆ42 CT6600 USER°Ø S GUIDE Click °n e x t° button. Then System will copy driver files. ¡ Click °f i n i s h° b u t t o n . ¡ Then the Device Manager tab will change like following figure .
