- Page 2 STREET MACHINE SERIES FULL RANGE CAR AUDIO SPEAKERS Congratulations on your purchase of the new Autotek Street Machine Series speaker system. The SM speaker series offer superior sonic accuracy, intense high power sound quality with exotic build materials and outstanding good looks.
- Page 3 SPEAKER LOCATION AND MOUNTING TIPS THE FIRST STEP IS THOROUGH PLANNING BEFORE THE INSTALLATION BEGINS. THE SPEAKER SCREW HOLE CONFIGURATION WILL WORK WITH MOST DOMESTIC AND FOREIGN VEHICLES. FOLLOW THESE INSTRUCTIONS CAREFULLY TO ENSURE PROPER IMAGING AND MAXXIMUM PERFORMANCE. Factory Speaker Replacement Location and Installation 1.
- Page 4 COMPONENT MOUNTING & WIRING PROCEDURES Inner Metal Door Panel Interior Door Panel Door Mount Tweeter Speaker Speaker Grill Speaker Screws Factory Grommet Inner Metal Door Panel Wire Routing Speaker Wires Wire Connections MID BASS utotek To amplifier street machine + & - output BLACK Passive In-Line Crossover TWEETER...
- Page 5 COAX & 3-WAY MOUNTING & WIRING PROCEDURES Rear Deck Mount Speaker Grill Mounting Screws Spacer Ring Speaker Inner Metal Door Panel Door Mount Interior Door Panel Speaker Speaker Grill Speaker Screws Factory Grommet Wire Routing Speaker Wires Inner Metal Door Panel Wire Connections Amplifier Black...
- Page 6 SPEAKER DIMENSIONS SM62CX SM52CX 4.53” 5.6” SM6.2C SM5.2C 4.53” 5.59” SM693 SM5.2C / SM6.2C Tweeter .47” 1.79” 2.03”...
- Page 8 Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, Autotek, MB Quart, Crunch and Hifonics car audio products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase.
