1. 1. Getting Started
1.1 Introduction
The VideoWalker DVB-T USB allows you to watch free-to-air digital terrestrial TV
programs and listen to digital radio on your PC or Notebook. This amazing portable
TV box has features for real-time recording and schedule recording in MPEG-2
format for high image quality. Use the time-shift feature so you never miss any shows,
and you can capture your favorite images by using the still image capture function. It
also supports the Electronic Program Guide (EPG), which offers you more
information about TV programs. With the portable shape, take the VideoWalker
DVB-T USB with your notebook and watch digital TV programs anywhere at anytime.
1.2 Features:
Watch free-to-air digital terrestrial TV programs and listen to digital radio
Schedule recording and real-time recording in MPEG-2 format
Supports time-shift and still image capture
Supports EPG (Electronic Program Guide) and Teletext
Auto channel scan and channel preview
Easy-to-use infrared remote control
1.3 Package Contents
You should have the following items in the package.
VideoWalker DVB-T USB
Driver CD
USB cable
Infrared remote controller with AAA4 battery
Mini portable terrestrial antenna (Highly recommended to use outdoor antenna
to make sure better receiving quality)
User's Manual
1.4 System Requirement
PC Pentium III 500MHz or higher
USB Port ( compatible with USB2.0)
Minimum 128MB RAM(256MB is recommended)
100MB HD space for installing driver
Microsoft Media player 7.0 or above
Microsoft DirectX 8.0 or above
VGA card with 8MB Memory
Speaker for audio output
Supports Windows 2000 / XP
English
Advertisement
Summary of Contents for Genius KYE Systems VideoWalker DVB-T USB
-
Page 1: Getting Started
1. 1. Getting Started 1.1 Introduction The VideoWalker DVB-T USB allows you to watch free-to-air digital terrestrial TV programs and listen to digital radio on your PC or Notebook. This amazing portable TV box has features for real-time recording and schedule recording in MPEG-2 format for high image quality. -
Page 2: Remote Controller
19. Teletext: Click this button to display Teletext 2. Installation and Introduction 2.1 Hardware Installation VideoWalker DVB-T USB Hardware Installation. You can connect either the portable antenna which is included in the package or your home antenna with VideoWalker DVB-T USB. - Page 3 VideoWalker DVB-T USB box. If the jack is not suitable, please buy a suitable converter from your TV shop. Note 1: If you install Videowalker DVB-T USB in “Notebook”, make sure to turn off the “Power Saving” function. It will slow down the CPU performance and could...
- Page 4 3. Software Installation Complete installation includes installing “Driver” and “Application Program”. And both of them can be installed easily from the VideoWalker DVB-T USB TV Box driver Please follow the instructions. 3.1. After connect VideoWalker DVB-T USB with your PC or Notebook, you should see two pop up windows of “Found New Hardware Wizard”.
- Page 5 3.7. Please click “Finish” to finish installation. 3.8 When you see the window, you can launch the VideoWalker DVB-T USB by clicking the “VideoWalker DVB-T USB” icon showed on your PC or Notebook.
-
Page 6: System Setup
There are three ways to scan Digital TV Programs, please choose one of them to setup when you power on VideoWalker DVB-T USB for the first time.(It is highly recommended to use the first one to scan TV programs if you do not know the frequency of TV channels). - Page 7 English III. Searching for TV Channels by scanning frequency range: the VideoWalker DVB-T USB will search for the TV channels by the frequency range that you put in. Step1： Please click at “Scan by frequency range”. Step2： Or, Please enter the period of frequency you would like to scan into “Frequency Start”...
- Page 8 English Channel list at the left side to the Right side icon. Click “OK” and type the file name to save. If you want to delete the channels you scanned, please click “Delete” or “Delete All” from the left side list then click “OK” and type the file name to save. Programs Classification FTA：Only shows the FTA (Free to Air) channels in list.
- Page 9 English Note 2: Up to 10 TV programs to be recorded. Note 3: Please don’t take recorded TV Programs for commercial use. Step 4: Choose the directory or drive where you would like your schedule recorded clip be saved on “Save to” icon. Step 5: On the “Notice”...
- Page 10 5.2.1. Terrestrial List Live Update Please click at on the control panel and click at “Update Terrestrial list”. VideoWalker DVB-T USB will connect to server and update the latest terrestrial list. Note: Connect the PC to the internet in advance. 5.2.2. Clock The clock will automatically be set to the host computer’s time.
- Page 11 Click at to capture the still frame you are currently watching. 5.2.10. Teletext The application “Teletext” is a simple teletext browser. To start this function, please click at on the control panel. It only works when VideoWalker DVB-T USB is launching.
- Page 12 English 5.3 Right Click Menu Right click your mouse over VideoWalker DVB-T USB UI and you will see a pop up menu. Here are the brief introduction. Play：Play Video Pause：Pause the video you are currently watching Stop：Stop the video you are currently watching Record：Record the video program you are currently...
- Page 13 Check whether VideoWalker DVB-T USB was inserted correctly in the USB port. b. After the VideoWalker DVB-T USB is plugged into the USB port, wait for at least 3 seconds before you launch VideoWalker DVB-T USB. c. Re-start the operation system.
- Page 14 The remote controller's "POWER" key for VideoWalker DVB-T USB can only "power off" the application, but not "power on". It's a hardware limitation. 13. The Remote controller does not work. VideoWalker DVB-T USB does not react to the key presses? VideoWalker DVB-T USB window must be the “focus”...
