- Page 1 DELORME Getting Started with Earthmate ® BT-20 Bluetooth ®...
-
Page 2: Table Of Contents
Table of Contents Overview .......................... 2 Hardware Features ......................2 Using the Earthmate GPS BT-20 ..................3 Charging the Battery ......................4 Troubleshooting ........................ 4 Hardware Specifications ....................6 FCC Certification ......................6 Caution ..........................7 FCC Radiation Exposure Statement ................. 7 Battery Caution ........................ -
Page 3: Overview
• As a USB device, when connected to the USB port on a laptop computer Once you connect to a compatible PDA or laptop, you can use the Earthmate GPS BT-20 and a compatible mapping application to track your location while you are moving. -
Page 4: Using The Earthmate Gps Bt-20
Using the Earthmate GPS BT-20 To track your progress while you travel, connect the Earthmate GPS BT-20 to a laptop or PDA with a Bluetooth connec- tion to display your location on any NMEA 2.0-compliant mapping application, such as Street Atlas USA , Topo USA ®... -
Page 5: Charging The Battery
Troubleshooting First Things to Check: • Does the Earthmate GPS BT-20 have a clear view of the sky? Buildings, mountains, and heavy foliage may block your satellite reception. • Is your mapping software running properly without the Earthmate GPS BT-20? •... - Page 6 Use the Bluetooth manager software that came with your Bluetooth-enabled PDA/laptop or Bluetooth adapter to check which COM port is associated with the Earthmate GPS BT-20 device. If the Bluetooth Manager does not display the COM port, use the steps below to determine the correct port to use in the mapping application.
-
Page 7: Hardware Specifications
Hardware Specifications • NMEA 2.0-compliant 12-channel receiver • STA2051 GPS chip set • Cold Start: <90 seconds • Warm start: <38 seconds • Hot Start: < 1 second • Power: ~90mA at 3.7V • Power with a Bluetooth connection: ~118mA at 3.7V •... -
Page 8: Caution
DeLorme warrants that your Earthmate GPS BT-20 device will be free from defects in materials and workmanship for sixty days from the date of purchase. If your Earthmate GPS BT-20 fails in normal use, DeLorme will, at its sole option, either repair or replace the unit. -
Page 9: Delorme Contact Information
DeLorme Contact Information Technical Support Visit www.delorme.com/support to access the DeLorme Technical Support Knowledge Base, get answers to frequently asked questions, or for additional support information. If you cannot find an answer to your problem on the site, please call 207-846-8900 to speak to a Technical Support representative.
