QUICK SETUP
GUIDE
40" LED TV
NS-40D40SNA14
Thank you
for purchasing this state-of-the-art
Insignia television. We hope you enjoy
the quality and reliability of this
television for years to come.
Included accessories
1 2
4 5
7 8
0
ENTER
ASPECT
+
VOL
MUTE
-
SLEEP FAVORITE
NS-RC4NA-14
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
B4 type (16mm length)
then click .
(6 pcs.)
START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: A Phillips screwdriver and a soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to protect the
screen from damages and scratches.
B Secure the stand column to your TV with the six provided 16 mm screws
(the shorter screws).
C Secure the TV stand to the stand column with the ve provided 18 mm screws
(the longer screws).
- OR -
How do I prepare my TV for wall mounting?
(not for use with a TV stand)
You'll need: A soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and scratches.
B See the instructions that came with your wall mount for more information about how to correctly mount your TV.
Which cables do you have?
Your TV has several di erent jacks for connecting devices. For the
STOP!
best video quality, use the best available connection. Use the cables
that came with your devices.
Do not plug your
power cable in until
all other devices have
VIDEO QUALITY
been connected.
BEST
BETTER
Component video and analog audio
GOOD
GOOD
INPUT
3
6
Note: You can use the HDMI 1/DVI (ARC) jack to connect a DVI device to your TV. Attach
9
an HDMI-to-DVI adapter to the end of the HDMI cable. The adapter connects to the DVI
Remote control
device's jack.
and two AAA batteries
CCD
CH
Features
MTS/ASP PICTURE
AUDIO
Front view
Stand column
Power indicator
Remote control sensor
T V stand
Back view
B4 type (18mm length)
(5 pcs.)
Note: Images may not necessarily represent the exact design of your television.
Before using your new product, please read these instructions to prevent any damage.
A B
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) or connect a device such as a DVD or
Blu-ray Disc player, game console, or camcorder?
Using an HDMI cable (BEST)
JACK TYPE CABLE CONNECTOR
HDMI video/audio
Composite video and analog audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable
(GOOD)
MENU INPUT VOL- VOL+ CH CH POWER
How do I connect my TV to an antenna or cable wall jack?
(ARC)
B4 type (16mm)
(ARC)
Component cable option
AUDIO/VIDEO OUT
(ARC)
C
B4 type (18mm)
Multipurpose jacks: You can plug any
device that uses HDMI into any HDMI
jack. However,certain devices must be
connected to the HDMI/DVI (ARC) I jack.
See the instructions that came with
your ARC or DVI device for more
information.
Note: The HDMI/DVI (ARC) jack is a
shared jack. This means you can only
connect only one DVI or ARC device at
a time.
Note: The component video and AV
jacks are shared. This means you can
connect only one component video or
AV device at a time. We suggest using
HDMI if your device supports it.
Note: Connect the yellow video cable
AUDIO/ VIDEO
OUT
connector to the green VIDEO/Y jack
on the back of your TV.
AV cable option
CABLE
OVER
