GV-R545SL-1GI/
GV-R545D3-1GI/
GV-R545HM-1GI/
GV-R545SC-1GI/
GV-R545OC-512I/
GV-R545HM-512I
AMD Radeon
HD5450 Graphics Accelerator
TM
User's Manual
Rev. 104
12MM-R545S-104ER
Copyright
© 2011 GIGABYTE TECHNOLOGY CO., LTD
Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or trans-
mitted in any form without the expressed, written permission of GBT.
Trademarks
Third-party brands and names are the properties of their respective owners.
Notice
Please do not remove any labels on this graphics card. Doing so may void the warranty of this card.
Due to rapid change in technology, some of the specifications might be out of date before publication of this this
manual.The author assumes no responsibility for any errors or omissions that may appear in this document nor does
the author make a commitment to update the information contained herein.
Rovi Product Notice:
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual
property rights.Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended
for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering
or disassembly is prohibited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-R545SL-1GI and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte GV-R545SL-1GI

Summary of Contents for Gigabyte GV-R545SL-1GI

  • Page 1 User's Manual Rev. 104 12MM-R545S-104ER Copyright © 2011 GIGABYTE TECHNOLOGY CO., LTD Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. (“GBT”). No part of this manual may be reproduced or trans- mitted in any form without the expressed, written permission of GBT. Trademarks Third-party brands and names are the properties of their respective owners.

  • Page 6: Table Of Contents

    Table of Contents 1. Introduction ........................7 1.1. Features ......................... 7 1.2. Minimum System Requirements ..................7 2. Hardware Installation ....................8 2.1. Board Layout ........................8 2.2. Hardware Installation ....................15 3. Software Installation ....................16 3.1. Driver and Utility Installation ..................16 3.1.1.

  • Page 7: Introduction

    Powered by AMD Radeon HD 5450 Graphics Processing Unit (GPU) • • Supports PCI Express 2.1 • Integrated with 1 GB DDR3 memory (For GV-R545SC-1GI / GV-R545D3-1GI / GV-R545SL-1GI) • Integrated with 512MB DDR3 memory (For GV-R545OC-512I / GV-R545HM-1GI only) (*Note1) •...

  • Page 8: Hardware Installation

    2. Hardware Installation 2.1. Board Layout 1. GV-R545SC-1GI D-Sub Monitor Connector (15-pin) HDMI Connector DVI-I Connector D-Sub Monitor D-Sub Output Connector (15-pin) Analog LCD Monitor Analog Monitor HDMI Connector HDMI TV DVI-I DVI Output Connector Digital LCD Monitor D-Sub DVI-I to D-Sub Output Adapter Analog LCD Monitor Analog Monitor...
  • Page 9 2. GV-R545OC-512I D-Sub Monitor Connector (15-pin) HDMI Connector DVI-I Connector D-Sub Monitor D-Sub Output Connector (15-pin) Analog LCD Monitor Analog Monitor HDMI Connector HDMI TV DVI-I DVI Output Connector Digital LCD Monitor D-Sub DVI-I to D-Sub Output Adapter Analog LCD Monitor Analog Monitor - 9 - Hardware Installation...
  • Page 10 3. GV-R545HM-1GI D-Sub Monitor Connector (15-pin) HDMI Connector DVI-I Connector D-Sub Monitor D-Sub Output Connector (15-pin) Analog LCD Monitor Analog Monitor HDMI Connector HDMI TV DVI-I DVI Output Connector Digital LCD Monitor D-Sub DVI-I to D-Sub Output Adapter Analog LCD Monitor Analog Monitor GV-R5450 Series Graphics Accelerator - 10 -...
  • Page 11 4. GV-R545HM-512I D-Sub Monitor Connector (15-pin) HDMI Connector DVI-I Connector D-Sub Monitor D-Sub Output Connector (15-pin) Analog LCD Monitor Analog Monitor HDMI Connector HDMI TV DVI-I DVI Output Connector Digital LCD Monitor D-Sub DVI-I to D-Sub Output Adapter Analog LCD Monitor Analog Monitor - 11 - Hardware Installation...
  • Page 12 5. GV-R545D3-1GI D-Sub Monitor Connector (15-pin) HDMI Connector DVI-I Connector D-Sub Monitor D-Sub Output Connector (15-pin) Analog LCD Monitor Analog Monitor HDMI Connector HDMI TV DVI-I DVI Output Connector Digital LCD Monitor D-Sub DVI-I to D-Sub Output Adapter Analog LCD Monitor Analog Monitor GV-R5450 Series Graphics Accelerator - 12 -...
  • Page 13 6.GV-R545SL-1GI D-Sub Monitor Connector (15-pin) HDMI Connector DVI-I Connector D-Sub Monitor D-Sub Output Connector (15-pin) Analog LCD Monitor Analog Monitor HDMI Connector HDMI TV DVI-I DVI Output Connector Digital LCD Monitor D-Sub DVI-I to D-Sub Output Adapter Analog LCD Monitor Analog Monitor...
  • Page 14 DO NOT APPLY POWER TO YOUR SYSTEM IF THE GRAPHICS CARD IS DAMAGED. In order to ensure that your graphics card can work correctly, please use official GIGABYTE BIOS only. Using non-official GIGABYTE BIOS might cause problem(s) on the graphics card. GV-R5450 Series Graphics Accelerator - 14 -...

  • Page 15: Hardware Installation

    2.2. Hardware Installation Now that you have prepared your computer, you are ready to install your graphics card. Step 1. Locate the PCI Express x16 slot. If necessary, remove the metal cover from this slot; then align your graphics card with the PCI Express x16 slot, and press it in firmly until the card is fully seated.

  • Page 16: Software Installation

    3. Software Installation Notice the following guidelines before installing the drivers: 1. First make sure your system has installed DirectX 9 or later version. 2. Make sure your system has installed the appropriate motherboard drivers (for the motherboard drivers, please contact the motherboard manufacturer.) 3.1.
  • Page 17 Step 5: Click the Accept button. Setp 4: Click the Express or Custom icon and then click Next. The system is installing the components. Step 6: Click the Finish button to restart the computer. Then the driver installation is completed. - 17 - Software Installation...

  • Page 18: Taskbar Icon

    3.2. Taskbar Icon After installation of the display driver, you will find an ATI icon in the notification area. Right-click the icon to enter the ATI Catalyst Control Center. The ATI Catalyst Control Center is used to configure all your graphics card settings.
  • Page 19 Configuring Audio Output Configure the default audio output device based upon your needs. Step 1: Go to Start > Control Panel > Hardware and Sound > Manage audio devices. Figure 2 Figure 1 Figure 3 Step 2: In the Manage audio devices dialog box, click the Playback tab. Using the picture to the left as the example, to set HDMI audio to be the default Sound Playback device, select Digital Output Device (HDMI).

  • Page 20: Display Properties

    CRT+DVI Matrix (Note 1) CRT+CRT (Note 2) DVI +DVI HDMI+DVI HDMI+CRT Model GV-R545HM-1GI GV-R545HM-512I GV-R545SL-1GI D i s p l a y CRT+DVI Matrix CRT+CRT (Note 1) DVI +DVI (Note 2) HDMI+DVI HDMI+CRT (Note 1) By a DVI-to-D-Sub adapter.(optional) (Note 2) By a HDMI to DVI adapter.(optional)

  • Page 21: Avivo Video Converter

    ATI Catalyst ® Control Center Basic View : The Basic View is the default view when ATI Catalyst Control Center is launched for the first time. This in- terface provides access to the basic settings and advanced features of your ATI graphics products. You can switch between Basic View and Advanced View at any time.
  • Page 22 Step 4: The video file has been successfully converted. In the Output Video Format list, select a file format for the new file. If you wish to change the name of the new file, enter the new name in the Output File area.

  • Page 23: Display Setup

    Quick Settings: The Quick Settings page provides access to three main settings.  3D Quality 3D Performance and Quality Settings allows your 3D games and applications to get faster perfor- mance and better quality with a more balanced setting.  Video Playback Use this option to optimize video playback in dif- ferent room environment or to select how video playback appears on the second display.
  • Page 24 ATI Catalyst Control Center Advanced View The Advanced page allows you to configure all of the many available settings of your ATI graphics card. View Properties: The CATALYST Control Center dashboard supports three types of views. Hotkeys Properties: The Hotkeys Manager allows you to create shortcut key combinations to quickly perform tasks such as changing a graphics setting or opening an application.
  • Page 25 Profiles Properties: You can use profiles to create customized environments for your desktop, video, and 3D applications. Define and save your own personal video settings that can be quickly activated manually, through a Hotkey, or by file association. Note: A profile applies to a specific graphics card. If there is more than one graphics card installed in your computer, you need to select the appropriate card before creating, loading, or activating a Profile.
  • Page 26 Help Properties: The Catalyst Control Center Help feature allows you to access the comprehensive online help, register your product, or generate a problem report should you require technical support. The Catalyst Control Center Help feature offers the following options:  Help for this Page  Help Contents ...

  • Page 27: Displays Manager

    Displays Manager: Displays Manager is the central location for configuring your display devices and arranging your desktop. Use Displays Manager to change your display setup and arrange your desktop in a multi-monitor environment. Note: The stretch vertically and horizontally options are not supported on systems running Windows Vista.

  • Page 28: Monitor Properties

    Monitor Properties 1:  Attributes Monitor Attributes provides information about the attached monitor. You can also enable Extended Dis- play Identification Data (EDID). EDID uses the infor- mation provided by the attached monitor to determine the limits for the resolution and refresh rate. ...

  • Page 29: Standard Settings

     Standard Settings The Standard Settings page provides access to a universal slider control where you can simultane- ously adjust all of the standard 3D settings for any type of 3D application. The slider enables you to adjust for overall system performance, overall 3D image quality, or a balance between the two.

  • Page 30: Anisotropic Filtering

     Anisotropic Filtering Anisotropic Filtering is a technique that preserves detail on surfaces that have three-dimensional perspective and fade away into the background. It works best when used in conjunction with Mipmap- ping. Anisotropic Filtering can be set to favor either an increase in system processing performance or improved image quality: •...
  • Page 31 Avivo Video:  Presets To quickly adjust your video settings choose one of the video presets. Note: These settings will only affect applications with video overlay support.  Basic Color Use the Avivo Color: Basic option to manually set Gamma, Brightness, Contrast, Saturation, and Tint for video playback.

  • Page 32: All Settings

     Basic Quality You can control the deinterlacing settings by checking the Use automatic deinterlacing item. The bar determines how the two interlaced video fields are converted into a non-interlaced form. Note: These settings will only affect applications with video overlay support. ...
  • Page 33 ATI Overdrive: Use Overdrive to maximize your viewing experience by dynamically and safely overclocking the graphics pro- cessor and memory. Use the Automated clock configuration utility to obtain the ATI recommended speeds for the graphics processor clock and video memory clock. Alternatively, manually set these speeds to meet your specific requirements.

  • Page 34: Troubleshooting Tips

    4. Troubleshooting Tips The following troubleshooting tips may help if you experience problems. Contact your dealer or GIGABYTE for more advanced troubleshooting information.  Check that the card is seated properly in the PCI Express x16 slot.  Ensure that the display cable is securely fastened to the card's display connector.

  • Page 35: Appendix

    5. Appendix 5.1. Resolutions and Color Depth Tables Radeon HD 5450 Series 2D Single Display Modes Display Refresh Color Depth (bpp) Screen Rate 8bpp(256 color) 16bpp(65K color) 32bpp(16.7M) Resolution (Hz) Standard mode High mode True mode 640 x 480  ...

  • Page 36: Regulatory Statements

    Contravention will be prosecuted. We believe that the information contained herein was accurate in all respects at the time of printing. GIGABYTE cannot, however, assume any responsibility for errors or omissions in this text. Also note that the information in this document is subject to change without notice and should not be construed as a commitment by GIGA- BYTE.
  • Page 37 Finally, we suggest that you practice other environmentally friendly actions by understanding and using the energy-saving features of this product (where applicable), recycling the inner and outer packaging (including shipping containers) this product was delivered in, and by disposing of or recycling used batteries properly. With your help, we can reduce the amount of natural resources needed to produce electrical and electronic equipment, minimize the use of landfills for the disposal of "end of life"...
  • Page 38 GV-R5450 Series Graphics Accelerator - 38 -...
  • Page 39 - 39 - Appendix...
  • Page 40 GV-R5450 Series Graphics Accelerator - 40 -...
  • Page 41 - 41 - Appendix...
  • Page 42 GV-R5450 Series Graphics Accelerator - 42 -...
