SUPPLEMENTAL SERVICE MANUAL
R-401FW
This is a supplemental Service Manual for Microwave Oven models R-401FK and R-401FW. This model is quite similar
to the base models R-402FW/R-404FK; (S42M185R402FE).
This supplemental manual must be used in conjunction with the base model service manual for complete operation,
service, safety and replacement parts information.
In the interest of user-safety the oven should be restored to its original condition and only parts identical to those specified
should be used.
WARNING TO SERVICE PERSONNEL: Microwave ovens contain circuitry capable of producing very high voltage and
current, contact with following parts may result in a severe, possibly fatal, electrical shock. (High Voltage Capacitor,
High Voltage Power Transformer, Magnetron, High Voltage Rectifier Assembly, High Voltage Harness etc..)
BEFORE SERVICING ..................................................................................................... INSIDE FRONT COVER
WARNING TO SERVICE PERSONNEL .............................................................................................................. 1
MICROWAVE MEASUREMENT PROCEDURE .................................................................................................. 2
FOREWORD AND WARNING ............................................................................................................................. 3
PRODUCT SPECIFICATIONS ............................................................................................................................. 4
GENERAL INFORMATION ................................................................................................................................. 4
PARTS LIST ..........................................................................................................................................................6
PACKING AND ACCESSORIES ......................................................................................................................... 10
SHARP ELECTRONCS CORPORATION
Service Headquarters: Sharp Plaza, Mahwah, New Jersey, 07430-2135
MODELS

TABLE OF CONTENTS

This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
S13M204R401FE
MICROWAVE OVEN
R-401FK
R-401FW
R - 4 0 1 F K
R- 401FW
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R-401FK and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp R-401FK

Summary of Contents for Sharp R-401FK

  • Page 1: Table Of Contents

    R-401FW R-401FW This is a supplemental Service Manual for Microwave Oven models R-401FK and R-401FW. This model is quite similar to the base models R-402FW/R-404FK; (S42M185R402FE). This supplemental manual must be used in conjunction with the base model service manual for complete operation, service, safety and replacement parts information.

  • Page 2: Precautions To Be Observed Before And During Servicing To Avoid Possible Exposure To Excessive Microwave Energy

    ELECTRONICS CORPORATION immediately @1-800-237-4277. If the unit operates with the door open, service person should 1) tell the user not to operate the oven and 2) contact SHARP ELECTRONICS CORPORATION and Food and Drug Administration's Center for Devices and Radiological Health immediately.

  • Page 3: Warning To Service Personnel

    R-401FK R-401FW WARNING TO SERVICE PERSONNEL Microwave ovens contain circuitry capable of pro- ducing very high voltage and current, contact with following parts may result in a severe, possibly fatal, electrical shock. (Example) High Voltage Capacitor, High Voltage Power Trans- former, Magnetron, High Voltage Rectifier Assem- bly, High Voltage Harness etc..

  • Page 4: Microwave Measurement Procedure

    R - 4 0 1 F K R-401FW MICROWAVE MEASUREMENT PROCEDURE A. Requirements: 1) Microwave leakage limit (Power density limit): The power density of microwave radiation emitted by a microwave oven should not exceed 1mW/cm at any point 5cm or more from the external surface of the oven, measured prior to acquisition by a purchaser, and thereafter (through the useful life of the oven), 5 mW/cm at any point 5cm or more from the external surface of the oven.

  • Page 5: Foreword And Warning

    Corp. Service Personnel with Operation and Service Information for the PARTS LIST SHARP MICROWAVE OVENS, R-401FK and R-401FW. The model R-401FK/FW is quite similar to base models R-402FW/R- 404FK (Ref.# S42M185R402FE). It is recommended that service personnel carefully study the entire text of this manual so that they will be qualified to render satisfactory customer service.

  • Page 6: Product Specifications

    R - 4 0 1 F K R-401FW SPECIFICATION ITEM DESCRIPTION Power Requirements 120 Volts 13.0 Amperes, 1550 watts 60 Hertz Single phase, 3 wire grounded Power Output 1000 watts (IEC 705 TEST PROCEDURE) Operating frequency of 2450MHz Case Dimensions Width 21-11/16"...

  • Page 7: Oven Diagram

    R-401FK R-401FW a qualified electrician and have it replaced with a properly grounded Grounded Receptacle Box three-pronged wall receptacle or have a grounding adapter properly grounded and polarized. If the extension cord must be used, it should be a 3-wire, 15 amp. or higher rated cord. Do not drape over a countertop or table where it can be pulled on by children or tripped over accidentally.

  • Page 8: Parts List

    Buzzer RTRNPA110DRE0 Transformer VRS1 RH-VZA032DRE0 Varistor (10G471K) VHEHZ4C3///-1 Zener diode (HZ4C3) 3- 2 FPNLCB386/KIT Control panel sub assembly [R-401FK] 3- 2 FPNLCB387/KIT Control panel sub assembly [R-401FW] 3- 2-1 FUNTKB334/KIT Key unit [R-401FK] 3- 2-1 FUNTKB335/KIT Key unit [R-401FW] 3- 2-2...
  • Page 9 To have your order filled promptly and correctly, please furnish the following information. 1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION Order Parts from the authorized SHARP parts Distributor for your area. Defective parts requiring return should be returned as indicated in the Service Policy.
  • Page 10 R - 4 0 1 F K R-401FW OVEN AND CABINET PARTS 1-13 1-10 4-10 1-11 1-12 4-11...

  • Page 11: Control Panel Parts

    R-401FK R-401FW CONTROL PANEL PARTS 3 - 1 3 - 2 3 - 4 3 - 6 3 - 3 3 - 5 3-2-1 3-2-3 DOOR PARTS 3-2-2 Actual wire harness may be different from illustration.

  • Page 12: Packing And Accessories

    R - 4 0 1 F K R-401FW PACKING AND ACCESSORIES TOP PAD ASSEMBLY DOOR PROTECTION SHEET 6-5 TURNTABLE TRAY PLASTIC BAG TRAY HOLDER 6-7 OPERATION MANUAL BOTTOM PAD ASSEMBLY 6-4 TURNTABLE SUPPORT PACKING CASE...
  • Page 13 R-401FK R-401FW NOTES...
  • Page 14 R - 4 0 1 F K R-401FW NOTES...
  • Page 15 R-401FK R-401FW NOTES...
  • Page 16 No part of this publication may be repro- duced, stored in retrieval systems, or trans- mitted in any form or by any means, elec- tronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher. 2003 SHARP CORP. (1M2.20E) Printed in U.S.A...
