Toshiba Satellite A305D-SP6925A Manual

Satellite A305D Detailed Product Specification
Model Name: A305D-SP6925R
A305D-SP6925A
A305D-SP6925C
C1 2
Operating System
• Genuine Windows Vista
®
Home Premium (SP1, 32/64-bit version),
Spanish
Processor and Chipset
• AMD Turion™ 64 X2 Dual-Core Mobile Technology RM-72
o 2.1 GHz, 1MB L2 Cache, HyperTransport™ Technology @ up
to 3600MHz
• AMD M780V chipset
4
Memory
• Configured with 4GB PC6400 DDR2 SDRAM (both memory slots may
be occupied). Maximum capacity 4GB
5
Storage Drive
• 320GB (5400 RPM); Serial ATA hard disk drive
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
7
Display
• 15.4" diagonal widescreen TruBrite
native resolution (WXGA)
o Native support for 720p content
8
Graphics
• ATI Radeon™ 3100 Graphics 256MB-1406MB dynamically allocated
shared graphics memory
Sound
• Built-in harman/kardon ®
stereo speakers
• Sound volume control dial
• Built-in microphone
Input Devices
• 86 key Spanish keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Play/Pause, Stop, Prev Track, Next
Track)
Communications
• Webcam and microphone built into LCD bezel
• Modem 9
• 10/100 Ethernet
• Integrated Wi-Fi
®
compliant wireless:
®
o Atheros 802.11b/g wireless-LAN
• Bluetooth
®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™, Multi
Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
Part Number: PSAH8U-01FRL3
3
6
®
TFT LCD display at 1280x800
10
© Copyright 2008 – 2009 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
1
PSAH8U-01FAR2
PSAH8U-01FCB2
• Audio
o S/P DIF output port (shared with headphone port)
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports with USB Sleep and Charge
o 3 x USB v2.0
o 1 x eSATA/USB combo port
o RJ-45 LAN port
o RJ-11 modem port
Physical Description
• Fusion finish with Horizon pattern
• Dimensions (WxDxH Front/H Rear): 362mm x 267mm x 34.5mm
/38.5mm without feet
• Weight: Starting at 2.72 kgs depending upon configuration
Power
• 90W (19V 4.74A) 100-240V/50-60Hz AC Adapter.
o Dimensions (WxDxH): 133mm x 58mm x 30.7mm
o Weight: starting at 0.4 kgs
13
Battery
• 4000mAh (6 cell) Lithium Ion battery pack
C1
Software
• Toshiba Software and Utilities
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree
o TOSHIBA Assist
o TOSHIBA DVD Player
o TOSHIBA Disc Creator
o TOSHIBA Face Recognition
• Third-party Software
o Microsoft
®
o Sun Java™ 2 Runtime Environment
®
o Adobe
o Google™ Desktop
®
o Ulead
o PowerCinema for TOSHIBA
• Trial Software
o Microsoft Office Trial Home and Student 2007 Edition (60-day trial)
o Norton 360™ All-In-One Security
Environmental Specifications
15
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
• This product is RoHS
• Energy Star 4.0 compliant
Satellite A305D-SP6925
UPC: 883974217694
883974217656
883974217687
14
®
®
Works 9
®
Acrobat Reader
®
DVD MovieFactory 5 for TOSHIBA
Operating
5° to 35° C
(41° to 95° F)
15° C per hour (max)
20% to 80%
0 to 3,000 meters
10G
0.5G
16
compatible
11
12
Non-operating
-20° to 60° C
(-4° to 140° F)
20° C per hour (max)
10% to 95%
0 to 10,000 meters
60G
1.0G
Page 1 of 4
