D-Link DWL-7130AP - xStack - Wireless Access Point Overview page 2

IEEE 802.11g
Standard
Radio and Modulation Type
Operating Frequency
Channel Numbers
Data Rate
1
Media Access Protocol
Transmitter Output Power
Receiver Sensitivity
IEEE 802.11a
Standard
Radio and Modulation Type
Operating Frequency
Channel Numbers
Data Rate
1
Media Access Protocol
xStack™ Wireless Access Points
DWL-2130AP DWL-2230AP
IEEE 802.11g IEEE 802.11g
BPSK, QPSK, 16QAM, BPSK, QPSK, 16QAM,
64QAM, OFDM 64QAM, OFDM
2400 ~ 2483.5MHz ISM 2400 ~ 2483.5MHz ISM
band band
11 Channels 11 Channels
54, 48, 36, 24, 18, 12, 9 and 54, 48, 36, 24, 18, 12, 9 and
6Mbps 6Mbps
CSMA/CA with ACK CSMA/CA with ACK
+15dBm at 54Mbps +15dBm at 54Mbps
+16dBm at 48Mbps +16dBm at 48Mbps
+17dBm at 36Mbps +17dBm at 36Mbps
+18dBm at 24, 18, 12, 9, +18dBm at 24, 18, 12, 9,
and 6Mbps and 6Mbps
Typical Sensitivity @ Typical Sensitivity @
which frame (1000-byte which frame (1000-byte
PDUs) Error Rate=10% PDUs) Error Rate=10%
–85dBm at 6Mbps –85dBm at 6Mbps
–84dBm at 9Mbps –84dBm at 9Mbps
–82dBm at 12Mbps –82dBm at 12Mbps
–80dBm at 18Mbps –80dBm at 18Mbps
–77dBm at 24Mbps –77dBm at 24Mbps
–73dBm at 36Mbps –73dBm at 36Mbps
–69dBm at 48Mbps –69dBm at 48Mbps
–68dBm at 54Mbps –68dBm at 54Mbps
x
x
x
x
x
x
x
DWL-7130AP
IEEE 802.11g
BPSK, QPSK, 16QAM,
64QAM, OFDM
2400 ~ 2483.5MHz ISM
band
11 Channels
54, 48, 36, 24, 18, 12, 9 and
6Mbps
CSMA/CA with ACK
+15dBm at 54Mbps
+14 ~ 16dBm at 48Mbps
+17dBm at 36Mbps
+18dBm at 24, 18, 12, 9,
and 6Mbps
Typical Sensitivity @
which frame (1000-byte
PDUs) Error Rate=10%
–85dBm at 6Mbps
–84dBm at 9Mbps
–82dBm at 12Mbps
–80dBm at 18Mbps
–77dBm at 24Mbps
–73dBm at 36Mbps
–69dBm at 48Mbps
–68dBm at 54Mbps
x IEEE 802.11a
x BPSK, QPSK, 16QAM,
64QAM, OFDM
x 5.15 ~ 5.24GHz
x 5.745 ~ 5.805GHz
x 8 non-overlapping
channels
x 54, 48, 36, 24, 18, 12, 9 and
6Mbps
x CSMA/CA with ACK
DWL-7230AP
IEEE 802.11g
BPSK, QPSK, 16QAM,
64QAM, OFDM
2400 ~ 2483.5MHz ISM
band
11 Channels
54, 48, 36, 24, 18, 12, 9 and
6Mbps
CSMA/CA with ACK
+15dBm at 54Mbps
+14 ~ 16dBm at 48Mbps
+17dBm at 36Mbps
+18dBm at 24, 18, 12, 9,
and 6Mbps
Typical Sensitivity @
which frame (1000-byte
PDUs) Error Rate=10%
–85dBm at 6Mbps
–84dBm at 9Mbps
–82dBm at 12Mbps
–80dBm at 18Mbps
–77dBm at 24Mbps
–73dBm at 36Mbps
–69dBm at 48Mbps
–68dBm at 54Mbps
IEEE 802.11a
BPSK, QPSK, 16QAM,
64QAM, OFDM
5.15 ~ 5.24GHz
5.745 ~ 5.805GHz
8 non-overlapping
channels
54, 48, 36, 24, 18, 12, 9 and
6Mbps
CSMA/CA with ACK
